USB-to-JTAG Bridge
○
PC4 2x7 2 mm JTAG pod flat cable header
○
• Clocks
GTR_REF_CLK_USB3 26 MHz
○
GTR_REF_CLK_SATA 125 MHz
○
CLK104 (various frequencies):
○
- CLK104_PL_CLK
- CLK104_PL_SYSREF
- CLK104_AMS_SYSREF
- CLK104_DDR_PLY_CAP_SYNC
- CLK104_ADC_REFCLK
- CLK104_DAC_REFCLK
8A34001 1588 eCPRI (various frequencies):
○
- 8A34001_Q1_OUT
- 8A34001_Q2_OUT
- 8A34001_Q3_OUT
- 8A34001_Q7_OUT
- 8A34001_Q8_OUT
- 8A34001_Q11_OUT
CLK_100 100 MHz
○
CLK_125 125 MHz
○
PS_REF_CLK 33.33 MHz
○
USER_MGT_SI570 (default 156.25 MHz)
○
USER_SI570_C0 (default 300 MHz)
○
USER_SI570_C1 (default 300 MHz)
○
ADC_CLK_225 (direct connect SMAs)
○
DAC_CLK_229 (direct connect SMAs)
○
USER_MGT_SMA_CLK (series capacitor connected SMAs)
○
• PS DDR4 4 GB 64-bit SODIMM
• PL DDR4 C0 I/F 2 GB 32-bit Component (4x8-bit)
