XM650: No Cable or SMAs on Module

Balun/Filter

XM655

Low Frequency Baluns

Table 30: Low Frequency Balun Part Number
UG1390 (v1.1) July 10, 2020
ZCU216 Board User Guide
Appendix C: XM650/XM655 Balun Add-on Cards for RFSoC EVM
Parameter
Part Number
Manufacturer
Order P/N
Vendor
Description
Data Sheet
Figure 35: Low Frequency Balun Specifications
Value
TCM2-33WX+
Minicircuits
TCM2-33WX+
Minicircuits
10 to 3 GHz RF Transformer
See the
Minicircuits
website.
