Table 33: High Frequency Balun (4-5 GHz) Part Number (cont'd)
High Frequency Balun (5-6 GHz)
Table 34: High Frequency Balun (5-6 GHz) Part Number
UG1390 (v1.1) July 10, 2020
ZCU216 Board User Guide
Appendix C: XM650/XM655 Balun Add-on Cards for RFSoC EVM
Parameter
Vendor
Description
Data Sheet
Figure 39: High Frequency Balun Specifications
Figure 40: High Frequency Balun Drawing
Parameter
Part Number
Manufacturer
Order P/N
Vendor
Description
Data Sheet
Value
Digikey
Balun 3.1 GHz-5 GHz 50/100 0404
See the
Anaren
website.
Value
BD4859N50100AHF
Anaren
1173-1070-2-ND
Digikey
BALUN 4.8 GHz-5.9 GHz 50/100 0404
See the
Anaren
website.
