Redirect Host Server Desktop or Storage Devices Using Oracle ILOM
Redirect Host Server Desktop or Storage Devices Using
Oracle ILOM
Before you begin, ensure that the following requirements are met:
The following user credentials are required:
■
■
■
■
The mouse mode is set correctly (see
■
Java Runtime Environment (JRE) 1.6 or later is installed. For IPv4 networks, a 32-bit or
■
64-bit JDK is required. For IPv6 networks, a 32-bit or 64-bit Java Development Kit (JDK)
170636 or higher is required.
The remote management client is connected to a network that has access to one of the
■
Ethernet management ports on the Oracle Server X6-2.
To launch the Oracle ILOM Remote System Console Plus application, follow these steps:
Log in to the Oracle ILOM web interface.
1.
For instructions, see
2. To launch the Oracle ILOM Remote System Console Plus application, click
Remote Control → Redirection, and then click the Launch Remote Console
button.
After clicking the Launch Redirection Console button, the following events can occur:
If this is the first time launching the Oracle ILOM Remote System Console Plus application,
■
a prompt to launch the Java web start program appears. Follow the instructions provided
in the prompt to continue launching the Oracle ILOM Remote System Console Plus
application.
If your system does not meet the Java security requirements for launching Oracle ILOM
■
Remote System Console Plus, a Java error message appears. Follow the instructions
provided in the Java error message to launch the Oracle ILOM Remote System Console
Plus application.
The Oracle ILOM Remote System Console Plus window for video redirection appears.
■
The redirected video console displays the remote host server in its present state. For
■
example, if the host server is powering on, a set of boot messages appears in the video
console.
90 Oracle Server X6-2 Installation Guide • July 2020
Console ( c ) user role privileges are required to use the Oracle ILOM Remote System
Console Plus.
A user account on the host server is required to log in to the redirected host desktop.
To exclusively control the storage media from the Oracle ILOM System Remote
Console Plus application, you must have root privileges on a Linux client or root
administrator privileges on a Windows client.
"Logging In to or Out of Oracle ILOM" on page
"Set the Mouse Mode" on page 89).
80.
