Attach Tool-less Slide-Rail Assemblies

See "Attach Tool-less Slide-Rail Assemblies" on page 47.
Attach Tool-less Slide-Rail Assemblies
Use this procedure to attach tool-less slide-rail assemblies to the rack.
Right-angle AC power cables (part number 7079727 - Pwrcord, Jmpr, Bulk, SR2, 2m,
Note -
C14RA, 10A, C13) must be installed before slide-rails when installing the Oracle Server X6-2
into a Sun Rack II 1042 (1000-mm) system rack. The standard rail kit tool-less slide-rails
impede access to the 15kVA and 22kVA Power Distribution Unit (PDU) electrical sockets in the
1000-mm rack. If you use the standard AC power cables and then install the slide-rails into the
rack, you will be unable to disconnect or remove the AC power cables. Once the slide-rails have
been installed into the rack, you will be unable to disconnect or remove the AC power cables.
Installing the Server Into a Rack 47
