b.
Gently tug on the right side of the front slide bar to verify that connector B is
properly seated.
Callout
1
2
8.
To install the CMA's connector C into the right slide-rail:
Description
Connector B tab
Right slide-rail front slot
Install the Cable Management Arm
Installing the Server Into a Rack
59
