Jumper and DIP Switch Settings
JTAG Emulation Port
The JTAG emulation port allows an emulator to access the processor's
internal and external memory, as well as the special function registers.
See
"JTAG (P8)" on page 3-16
connector. To learn more about available emulators, contact Analog
Devices (see
"Product Information"
Jumper and DIP Switch Settings
This section describes the function of all the jumpers and DIP switches.
The following figure shows the location of all the jumpers and DIP
switches.
Figure 3-2. Jumper and Switch Locations
3-6
for more information about the JTAG
in the "Preface").
ADSP-2191 EZ-KIT Lite Evaluation System Manual
JP3: Telephony Codec Disable
JP2: AD1803 Comm Mode
JP1: Audio Input Select
JP4: Audio Codec Disable
SW4: Clock Multiply Select
JP7: Bypass
JP6: Boot Mode
