Table 3-11. Power Supply Specifications (Cont'd)
Input
Connector: IEC320 / C14 /3 Pin

Board Current Measurements

The ADSP-2191 EZ-KIT Lite board provides six zero-ohm resistors,
which you can remove to measure current draw.
resistor number, the voltage plane, and a description of each component
on the plane.
Table 3-12. Current Measurement Resistors
Resistor
R89
R85
R90
R87
R88
ADSP-2191 EZ-KIT Lite Evaluation System Manual
Output
Protection: Short Ckt, Over
Load, Over Volt
Connector: FB, 5.5 x 2.5 x
11 mm, CP
Voltage Plane
5V
A5V
3.3V
VDDINT
VDDEXT
EZ-KIT Lite Hardware Reference
General
Table 3-12
Description
Main power of the entire board except A5V
5V analog side of the AD1885
All 3.3V ICs, Pull-up Resistors, and LEDs
Core Voltage of the processor
IO Voltage of the processor
shows the
