EZ-KIT Lite License Restrictions

For more detailed information about programming the ADSP-2191
processor, see "Related Documents"
EZ-KIT Lite License Restrictions
The license shipped with the EZ-KIT Lite imposes the following
restrictions.
• Program memory (PM) space is limited to 8K words (1/4 of the
ADSP-2191 PM space).
• No connections to simulator or emulator sessions are allowed.

Memory Map

The ADSP-2191 processor has 32K words of internal SRAM that can be
used for program storage or data storage. The configuration of internal
SRAM is detailed in the ADSP-219x/2191 DSP Hardware Reference.
The ADSP-2191 EZ-KIT Lite board contains 512K x 8 bits of external
Flash memory. This memory is connected to the processor's
memory select pins. The Flash memory can be accessed in either the boot
memory space or the external memory space.
Table 2-1. EZ-KIT Lite Evaluation Board Memory Map
Start Address
Internal
0x00 0000
Memory
0x00 8000
2-2
in the "Preface."
End Address
0x00 7FFF
0x00 FFFF
ADSP-2191 EZ-KIT Lite Evaluation System Manual
Page Content
0 24-Bit Program Memory (Internal)
0 16-Bit Data Memory (Internal)
and
~MS0 ~BMS
