External Memory Interface (P10, P11)
Two MICTOR board-to-board connectors provide all of the processor's
External Memory Interface signals. Contact AMP for information about
mating connectors. The location of these connectors is shown in
"Mechanical Dimensions" on page
Table 3-8. External Memory Connectors
Part Description
38-Position MICTOR
Host Port Interface (P12)
One MICTOR board-to-board connector provides all the processor's
Host Port Interface signals. Contact AMP for information about mating
connectors. The location of this connector is shown in
Dimensions" on page
Table 3-9. Host Port Connector
Part Description
38-Position MICTOR
Power Connector (P13)
The power connector provides all of the power necessary to operate the
EZ-KIT Lite board.
Part Description
2.5 mm Power Jack
ADSP-2191 EZ-KIT Lite Evaluation System Manual
EZ-KIT Lite Hardware Reference
3-20.
Manufacturer
AMP
3-20.
Manufacturer
AMP
Manufacturer
Switchcraft
Digi-key
Part Number
2-767004-2
"Mechanical
Part Number
2-767004-2
Part Number
RAPC712
SC1152-ND
3-17
