A.5.1 Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
A.5.2 LAN Interface
PROTOCOLS
PORTS
SPEED
CONNECTOR
A.5.3 WAN Base-T Interface
STANDARDS
SPEED
CONNECTOR
A.5.4 WAN SFP Interface
STANDARDS
SPEED
TYPES
CONNECTOR
M8-Smart
Freescale QorIQ.
1 Gbyte in SDRAM.
FLASH Memory (32 Mbytes).
Ethernet (802.3).
4 port switch managed with MDI/MDX auto-detection.
10/100/1000 Mbps (Base-T).
RJ45 female.
Ethernet (802.3).
10/100/1000 Mbps (Base-T).
RJ45 female.
802.1Q (VLAN).
1000-Base-X.
MSA and SFF 8472 compliant
1000 Mbps full duplex.
LX/LH (single-mode 1310 nm).
SX (multi-mode 850 nm).
ZX (single-mode 1550 nm).
Standard SFP connector.
