ID2000 Series Installation & Commissioning Manual
Appendix 2 - Specifications
ID2000 Series Panel Range
General:
The Fire Control Panel meets the requirements of EN 54-2/4. See
Section 1.1 CE Marking for further details.
Mechanical:
Construction:
Dimensions (mm):
Weights (Approx.)(no batteries):
Environmental:
Climatic classification:
Operating temperature: -5° C to +45° C,
Humidity:
Height above sea level: Maximum, 2000m
Panel sealing:
Vibration:
EMC:
Safety:
A2 - 1
Sheet steel enclosure with panel main
components supplied as separate
build modules. Electronic chassis
module door carries all displays and
controls under plastic fascia moulding.
Lockable, transparent user-interface
doors are optional features.
Standard:
500(w) X 400(h) x 153(d)
Extended - standard depth:
500(w) X 620(h) x 153(d)
Extended - extra depth:
500(w) X 620(h) x 251(d)
Double-extended - standard depth:
500(w) X 840(h) x 153(d)
Double-extended - extra depth:
500(w) X 840(h) x 251(d)
Back Box Extension - standard depth:
500(w) x 220(h) x 153(d)
Back Box Extension - extra depth:
500(w) x 220(h) x 251(d).
Standard 14kg
Extended - standard depth 18kg
Extended - extra depth 20kg
Double-extended - standard depth 22kg
Double-extended - extra depth 24kg
Back Box Extension - std depth 4kg
Back Box Extension - extra depth 5kg
3K5, (IEC 721-2-3)
(recommended +5° C to 35° C)
5% to 95% R.H.
IP 30, (EN 60529)
EN 60068-2-6, 10-150Hz at
0.981ms
-2
(Meets the requirements
of EN 54-2/4)
Emissions:
EN 61000-6-3
Immunity:
EN 50130-4
EN 60950
997-433-000-5, Issue 5
May 2010
