X (x2)
X (x2)
997-433-000-5, Issue 5
May 2010
ID2000 Series Installation & Commissioning Manual
5 To re-align the paper exit path:
i
ii When satisfied that the paper is aligned correctly,
Note: Each press of the button advances the paper one
Instructions for fitting the serrated tear-off plate to the
front cover and cutting the printer paper to length are
given in the cover's installation instructions, 997-228.
The drawing at left shows the PRN-ID printer fitted
correctly.

5.6.2 Printer Used With Stainless Steel Cover

The following additional steps are required:
Y
1 Before you begin: Remove the two screws (X) that
THIS WAY
THIS WAY
UP
UP
2 Fitting the paper roll: Manually feed the paper
28
Locate the paper release control (Q) immediately to
the left of the paper exit slot and pull the top lug
outwards and down through approximately 90
the lug in this position the paper alignment can now
be adjusted. Re-align the paper by gently pulling it
left or right until centrally placed in the slot - make
sure that the slack in the paper is kept to a minimum
between the printer mechanism and paper roll. IF
USING A STAINLESS STEEL COVER ON THE
PANEL, SEE ADDITIONAL INFORMATION BELOW.
return the lug to its former position, i.e. locked. Press
the '
' pushbutton to feed the paper a number of
lines to check the paper re-alignment.
line
secure the paper guide in position. Rotate the plate
180
vertically to give the orientation shown as 'THIS
O
WAY UP' in the illustration, then use the two screws
(X) to re-attach it to the printer.
through the slot in the front cover.
O
. With
