Summary of Contents for Honeywell SILENT KNIGHT IFP-100

  • Page 1 MODEL IFP-100 Analog/Addressable Fire Control Panel Installation and Part Number 151280 Rev L Operations Manual...
  • Page 3: Installation Procedure

    Installation Procedure Adherence to the following will aid in problem-free installation with long-term reliability: Installation Precautions - Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be connected to the fire alarm control panel. Disconnect all sources of power before servicing. Control unit and associated equipment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized.
  • Page 4 While installing a fire alarm system may make lower insurance rates possible, it is not a substitute for fire insurance! An automatic fire alarm system - typically made up of smoke detectors, heat detectors, manual pull stations, audible warning devices, and a fire alarm control with remote notification capability - can provide early warning of a developing fire.
  • Page 5: Table Of Contents

    Contents Section 1 Introduction .............................. 1-1 Overview of Basic System ........................1-1 1.1.1 Hardware Features ..........................1-1 1.1.2 Software Features ..........................1-2 About this Manual ............................ 1-2 1.2.1 Terms Used in this Manual ....................... 1-2 Compatible Products ..........................1-3 How to Contact Silent Knight ........................1-4 Limitations of Fire Alarm Systems ..................
  • Page 6 IFP-100 Installation Manual Section 4 Control Panel Installation ...................... 4-1 Mounting the Control Panel Cabinet ....................... 4-1 4.1.1 Preventing Water Damage ........................ 4-1 4.1.2 Removing the IFP-100 Assembly from the Housing ................ 4-1 AC Connection ............................4-2 Battery Connection ..........................4-3 4.3.1 RBB Accessory Cabinet ........................
  • Page 7 Contents 4.15 Remote Station Applications ......................... 4-33 4.15.1 Keltron Model 3158 Installation ..................... 4-33 4.15.2 City Box Connection Using the 5220 Module ................4-34 4.15.3 NFPA 72 Polarity Reversal ......................4-35 4.15.3.1 Using the 5220 Module ......................4-35 4.15.3.2 Using the 7644 Module ......................4-37 4.15.4 Using the SD500-ARM Addressable Relay Module ..............
  • Page 8 IFP-100 Installation Manual Programming ............................7-1 UL 864 Programming Requirements ....................... 7-1 SLC Family .............................. 7-2 Modules ..............................7-2 7.3.1 Edit Modules ............................. 7-2 7.3.1.1 Naming Modules ........................7-3 7.3.1.2 Module, Wiring Class ......................7-3 7.3.2 Adding a Module ..........................7-3 7.3.3 Deleting a Module ..........................
  • Page 9 Contents 7.7.2 Phone Lines ............................. 7-36 7.7.2.1 Dialing Prefix ........................7-36 7.7.2.2 Number of Answer Rings ....................7-37 7.7.2.3 Dial Option (TouchTone or Pulse) ..................7-37 7.7.2.4 Rotary Format ........................7-37 7.7.2.5 Line Monitor ........................7-37 7.7.2.6 Ground Start Relay ....................... 7-38 7.7.2.7 Answering Machine Bypass ....................
  • Page 10 IFP-100 Installation Manual 8.4.5 Clear Event History .......................... 8-5 8.4.6 Conduct a Fire Drill .......................... 8-5 8.4.7 Conduct an Indicator Test ......................... 8-5 8.4.8 Conduct a Walk Test ......................... 8-6 8.4.9 Conduct a Dialer Test ........................8-6 8.4.10 Silence alarms or troubles ......................... 8-7 8.4.11 Reset alarms ............................
  • Page 11 Contents 11.2 IDP SLC Device Point Record ....................... 11-3 Appendix A Compatible Devices ........................A-1 Two-Wire Smoke Detectors ........................A-12 Appendix B Special Characters Lists ......................B-1 Characters used for Naming ........................B-1 Silent Knight Fire Product Warranty and Return Policy Model IFP-100 Basic Operating Instructions 151280...
  • Page 12 IFP-100 Installation Manual viii 151280...
  • Page 13: Section 1 Introduction

    Section 1 Introduction The IFP-100 Fire Alarm Control / Communicator is an analog/addressable fire control system that meets the requirements of UL 864. Overview of Basic System The IFP-100 base system is an addressable system with a built-in annunciator that can also be used to program the system.
  • Page 14: Software Features

    IFP-100 Installation Manual 1.1.2 Software Features • Advanced smoke detector features: –Automatic drift compensation –Automatic day/night sensitivity adjustment –Maintenance alert region –Point status eliminates calibrated smoke test requirements for NFPA 72 • “JumpStart” feature for easy programming • Non-volatile event history stores 1000 events •...
  • Page 15: Compatible Products

    Introduction Compatible Products The chart below lists the products available from Silent Knight for use with the IFP-100. Type of Model Description Device Addressable See Section 5.1 for a list of compatible devices. SLC Devices Hochiki Addressable See Section 5.2 for a list of compatible devices. SLC Devices Other 5211 Ground Start Relay...
  • Page 16: How To Contact Silent Knight

    IFP-100 Installation Manual The following modems have been tested by Silent Knight for compatibility with the IFP-100 and the Silent Knight Software Suite software packages: Table 1-1: Compatible Modems Manufacturer Model US Robotics 28.8 LifeStyle Motorola 28.8, 3400 series Premier 33.6 MultiTech MT19321ZDX How to Contact Silent Knight...
  • Page 17: Limitations Of Fire Alarm Systems

    Introduction Limitations of Fire Alarm Systems Manufacturer recommends that smoke and/or heat detectors be located throughout a protected premise following the recommendations of the current edition of the National Fire Protection Association Standard 72 (NFPA 72), manufacturer’s recommendations, State and local codes, and the recommendations contained in Guide for the Proper Use of System Smoke Detectors, which is made available at no charge to all installing dealers.
  • Page 18 IFP-100 Installation Manual • Warning devices (including horns, sirens, and bells) may not alert people or wake up sleepers who are located on the other side of closed or partially open doors. A warning device that activates on a different floor or level of a dwelling or structure is less likely to awaken or alert people.
  • Page 19: Requirements And Recommendations For Proper Use Of Fire Alarm Systems Including Smoke Detectors And Other Fire Alarm Devices

    Introduction Requirements and recommendations for proper use of fire alarm systems in- cluding smoke detectors and other fire alarm devices: Early fire detection is best achieved by the installation and maintenance of fire detection equipment in all rooms and areas of the house or building in accordance with the requirements and recommendations of the current edition of the National Fire Protection Association Standard 72, National Fire Alarm Code (NFPA 72), the manufacturer’s recommendations, State and local codes and the recommendations contained in Guide for the Proper Use of...
  • Page 20 IFP-100 Installation Manual 151280...
  • Page 21: Section 2 Agency Listings, Approvals, And Requirements

    Section 2 Agency Listings, Approvals, and Requirements Federal Communications Commission (FCC) The following information must be provided to the telephone company before the IFP-100can be connected to the phone lines: Manufacturer: Silent Knight Model Number: IFP-100 FCC registration number: AC6 USA-34758-AL-E Ringer equivalence: 0.8B Type of jack:...
  • Page 22 IFP-100 Installation Manual If trouble is experienced with the IFP-100, for repair or warranty information, please contact Silent Knight at 1-800-328-0103 or www.silentknight.com. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the IFP- 100until the problem has been resolved.
  • Page 23: Underwriters Laboratories (Ul)

    Agency Listings, Approvals, and Requirements Underwriters Laboratories (UL) 2.2.1 Requirements for All Installations General requirements are described in this section. When installing an individual device, refer to the specific section of the manual for additional requirements. The following subsections list specific requirements for each type of installation (for example, Central Station Fire Alarm systems, Local Protected Fire Alarm systems, and so on).
  • Page 24: Requirements For Local Protected Fire Alarm Systems

    IFP-100 Installation Manual 4. The AC Loss Hours option must be set from 1-3 hours. 5. The Attempts to Report option must be set for 5. 2.2.3 Requirements for Local Protected Fire Alarm Systems At least one UL listed supervised notification appliance must be used. Minimum system requirements are one Silent Knight addressable initiating device.
  • Page 25: Section 3 Before You Begin Installing

    Section 3 Before You Begin Installing This section of the manual is intended to help you plan your tasks to facilitate a smooth installation. Please read this section thoroughly, especially if you are installing a IFP-100 panel for the first time. What’s in the Box? The IFP-100 ships with the following hardware: •...
  • Page 26: Electrical Specifications

    IFP-100 Installation Manual Electrical Specifications Table 3-1 list the terminal block on the IFP-100 as well as a description of the each individual terminal and their respective electrical rating. For location of the terminals refer to Table 3-1. Table 3-1: Terminal Descriptions and Electrical Specifications Label Rating Terminal No.
  • Page 27: Wiring Specifications

    Before You Begin Installing Wiring Specifications Induced noise (transfer of electrical energy from one wire to another) can interfere with telephone communication or cause false alarms. To avoid induced noise, follow these guidelines: • Isolate input wiring from high current output and power wiring. Do not pull one multi- conductor cable for the entire panel.
  • Page 28: Board Assembly Diagram

    IFP-100 Installation Manual Board Assembly Diagram Phone lines On-board Annunciator In/Out Form C Trouble Relay Form C Relays Programming Port NAC/Aux Power Circuits SBUS Connections Battery Connections AC Power Input Figure 3-2 Model IFP-100 Assembly Figure 3-2 shows the circuit boards and annunciator that attach the IFP-100 assembly to the cabinet.
  • Page 29: Calculating Current Draw And Standby Battery

    Before You Begin Installing Calculating Current Draw and Standby Battery This section is for helping you determine the current draw and standby battery needs if you are using IDP addressable devices (Table 3-2) or Hochiki addressable devices (Table 3-3). 3.6.1 Current Draw Worksheet Requirements The following steps must be taken when determining IFP-100 current draw and standby battery requirements.
  • Page 30: Current Draw Worksheet For Idp Slc Devices

    IFP-100 Installation Manual 3.6.1.1 Current Draw Worksheet for IDP SLC Devices Use Table 3-2 to determine current requirements during alarm/battery standby operation when IDP SLC devices are installed. You can install up to 99 IDP detectors and 99 IDP modules. (Copy the page if additional space is required.) Table 3-2: Current Draw Worksheet for IDP Devices Standby...
  • Page 31 Before You Begin Installing Table 3-2: Current Draw Worksheet for IDP Devices Standby Alarm Device # of Devices Current per Device Current Current SLC Accessories Standby: 1 mA Aux Pwr SSB501BHT Sounder Base Alarm: 15 mA Alarm: 0.7 mA (99 max.) SSB224RB Relay Base Standby/Alarm: 0.5 mA...
  • Page 32 IFP-100 Installation Manual Table 3-2: Current Draw Worksheet for IDP Devices Standby Alarm Device # of Devices Current per Device Current Current Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) Multiply lines E and H. Total alarm AH Total ampere hours Add lines G and I.
  • Page 33: Current Draw Worksheet Hochiki For Slc Devices

    Before You Begin Installing 3.6.1.2 Current Draw Worksheet Hochiki for SLC Devices Use Table 3-3 to determine current requirements during alarm/battery standby operation when Hochiki SLC devices are installed. (Copy the page if additional space is required.) Table 3-3: Current Draw Worksheet for Hochiki Devices Standby Alarm Device...
  • Page 34 IFP-100 Installation Manual Table 3-3: Current Draw Worksheet for Hochiki Devices Standby Alarm Device # of Devices Current per Device Current Current Standby: 20 mA RA-100 Remote Fire Alarm Annunciator Alarm: 25 mA (8 max.) Standby: 20 mA RA-1000 Remote Fire Alarm Annunciator Alarm: 25 mA...
  • Page 35: Maximum Battery Standby Load

    Before You Begin Installing Table 3-3: Current Draw Worksheet for Hochiki Devices Standby Alarm Device # of Devices Current per Device Current Current Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) Multiply lines E and H. Total alarm AH Total ampere hours Add lines G and I.
  • Page 36 IFP-100 Installation Manual 3-12 151280...
  • Page 37: Section 4 Control Panel Installation

    Section 4 Control Panel Installation Caution! To avoid the risk of electrical shock and damage to the unit, power should be OFF at the control panel while installing or servicing. Mounting the Control Panel Cabinet Read the environmental specifications in Section 3.2 before mounting the IFP-100 panel. The IFP-100 cabinet dimensions are: 16"...
  • Page 38: Ac Connection

    IFP-100 Installation Manual AC Connection At installation, connect the AC terminals to the power source as shown in Figure 4-1. It may be necessary for a professional electrician to make this connection. The AC terminals are rated at 120 VAC, 60 Hz, 3.6A. Figure 4-1 120VAC Power Connection 151280...
  • Page 39: Battery Connection

    Control Panel Installation Battery Connection The control panel battery charge capacity is 7.0 to 35 AH. The main control cabinet can house batteries up to 18 AH, larger capacity batteries can be housed in a RBB (see Section 4.3.1 for details).
  • Page 40: Rbb Accessory Cabinet

    IFP-100 Installation Manual 4.3.1 RBB Accessory Cabinet The Model RBB Accessory cabinet can be used when your backup batteries requirements use backup batteries that are too large to fit into the main control panel cabinet. The RBB cabinet holds batteries up to the 35 AH size. The RBB dimensions are 16" W x 10" H x 6" D (40.64 cm W x 25.4 cm H x 15.24 cm D).
  • Page 41 Control Panel Installation 3. Run extended battery cable from control panel cabinet through conduit to RBB cabinet. See Figure 4-5. RBB Cabinet Cover Screws Conduit Coupler Conduit RBB Cabinet Cover Screws Figure 4-5 Battery Connections in the RBB Cabinet Note: Figure 4-5 is an example of how the wire connections can be routed. However, any other cabinet knock- outs (on either the main control panel or the RBB cabinet), that are not previously being used may be uti- lized to connect conduit between the two cabinets.
  • Page 42: Sbus Wiring

    IFP-100 Installation Manual SBUS Wiring This section contains information on calculating SBUS wire distances and the types of wiring configurations (Class B). 4.4.1 Calculating Wiring distance for SBUS modules The following instructions will guide you in determining the type of wire and the maximum wiring distance that can be used with control panel SBUS accessory modules.
  • Page 43 Control Panel Installation These cases are marked in the chart with an asterisk (*). Maximum length can never be more than 6,000 feet, regardless of gauge used. (The formula used to generate this chart is shown in the note below). Table 4-2: Wiring Distances Per Wire Gauge Using Copper Wire Wiring Distance: SBUS Modules to Panel Total Worst Case...
  • Page 44: Wiring Distance Calculation Example

    IFP-100 Installation Manual Wiring Distance calculation example: Suppose a system is configured with the following SBUS modules: 2 - Module RA-1000 Fire Annunciator 1 - 5496 Notification Power Expander 1 - 5865 LED Fire Annunciator 1 - 5824 Serial/Parallel Printer Interface Module The total worst case current is calculated as follows: RA-1000 Current Draw = 2 x .100 amps...
  • Page 45: Remote Annunciator Installation

    Control Panel Installation RA-100 Remote Annunciator Installation The optional Model RA-100 Remote Annunciator, shown in Figure 4-14, performs the same functions as the on-board annunciator. Operation is identical. The RA-100 can be surface or flush mounted. Up to 8 RA-100s can be added to the IFP-100 system. Figure 4-8 Model RA-100 Remote Annunciator, Front View RA-100 installation involves the following steps: 1.
  • Page 46: Mounting The Ra-100

    IFP-100 Installation Manual 4.5.1 Mounting the RA-100 This section of the manual describes mounting the remote annunciator. The annunciator can be flush- or surface-mounted. 4.5.1.1 Flush Mounting This section of the manual describes flush mounting. Follow these steps to flush mount the RA-100 1.
  • Page 47 Control Panel Installation 2. Remove knockout holes as needed for wires. See Figure 4-10 for backbox knockout loca- tions Wire Knockouts Wire Knockouts Wire Knockouts Figure 4-10 Back Box Knockout Locations 3. Wire the Annunciator board to the main control panel. See Figure 4-7. 4.
  • Page 48: Surface Mounting

    IFP-100 Installation Manual 4.5.1.2 Surface Mounting The optional Model RA-100TG/TR trim ring kit is available for use when surface mounting. 1. Remove the desired knock out. See Figure 4-10. 2. To properly mount the back box, insert a single screw into the key shaped mounting hole. Do not tighten all the way.
  • Page 49: Ra-1000 Remote Annunciator Installation

    Control Panel Installation RA-1000 Remote Annunciator Installation The optional Model RA-1000 is a remote annunciator that utilizes a fireman’s key or access code to reset or silence. Up to 8 annunciators can be added to the IFP-100 system. Figure 4-14 Model RA-1000 Remote Annunciator, Front View RA-1000 installation involves the following steps: 1.
  • Page 50: Mounting The Ra-1000

    IFP-100 Installation Manual 4.6.1 Mounting the RA-1000 This section of the manual describes mounting the remote annunciator. The annunciator can be flush- or surface-mounted. Figure 4-15 shows the parts of the annunciator. Instructions for disassembling and mounting appear on the following pages. Figure 4-15 Annunciator Parts 4-14 151280...
  • Page 51: Flush Mounting

    Control Panel Installation The RA-1000 comes from the factory fully assembled. You must disassemble it for mounting. To disassemble the annunciator, use a 5/64 hex wrench to remove the set screws, located on the bottom of the annunciator bezel. (See Figure 4-16 for location of the set screws.) Figure 4-16 Annunciator Back Box and Bezel Details 4.6.1.1 Flush Mounting This section of the manual describes flush mounting.
  • Page 52: Flush Mounting With An Electrical Box

    IFP-100 Installation Manual Flush Mounting with an Electrical Box The RA-1000 annunciator can be used with the following types of electrical boxes: 4S, single- gang, and double-gang. If an electrical box is used, the box must be 1-3/8” back from the face of the wall to accommodate the annunciator.
  • Page 53: Surface Mounting

    Control Panel Installation 4. After the annunciator wiring to the panel has been completed (described in Section 4.6.2), replace the electronic assembly in the back box. Place the bezel over the back box and tighten the set screws on the bezel. Figure 4-18 Flush Mounting the Back Box 4.6.1.2 Surface Mounting The RA-1000 can be mounted directly to a surface or can be attached to a single, double, or...
  • Page 54: Connecting The Ra-1000 To The Panel

    IFP-100 Installation Manual 4.6.2 Connecting the RA-1000 to the Panel Connect the RA-1000 to the panel as shown in Figure 4-19. Supervised Power Limited Class B Figure 4-19 Model RA-1000 Connection to the Panel 5824 Serial/Parallel Printer Interface Module Installation The 5824 serial/parallel printer interface module allows you to connect a printer to the panel, so you can print a real-time log of system events, a report of detector status, and event history.
  • Page 55 Control Panel Installation 5. Connect a printer to the 5824 as shown in Figure 4-21. Supervised Power Limited Class B Wiring Figure 4-20 5824 Connection to the Panel To Parallel Printer To Serial Printer Figure 4-21 Printer Connection 151280 4-19...
  • Page 56: Selecting 5824 Options

    IFP-100 Installation Manual 4.7.1 Selecting 5824 Options Configuring the 5824 includes the following steps: • Add the module to the system. JumpStart will add the module automatically (see Section 6.1). You can also add it manually (see Section 7.3.2). • Select a name, if desired (see Section 7.3.1.1).
  • Page 57: 5880 Led I/O Module

    Control Panel Installation 5880 LED I/O Module The 5880 is an LED driver board that can be used in a wide variety of applications, including as an interface with most customized floor plan annunciator boards. The 5880 can drive up to 40 LEDs and has one PZT controller.
  • Page 58: Facp Connection

    IFP-100 Installation Manual 4.8.2 FACP Connection The 5880 connects to the panel via the SBUS. Make connections as shown in Figure 4-24. After the 5880 is connected to the panel, it must be added to the system. This programming step is described in Section 4.10. Supervised Power Limited Figure 4-24 5880 Connection to Main Control Panel Assembly...
  • Page 59: Led Wiring

    Control Panel Installation 4.8.3 LED Wiring There are four 12-pin connectors on the 5880 board for connecting LEDs. Each LED gets its power from Pin 11. Internal resistors are sized so that there is approximately 10 mA of current for each LED, no series resistors are required. LED outputs can be mapped to output circuits. See Section 6 for programming details.
  • Page 60: Dry Contact Wiring

    IFP-100 Installation Manual 4.8.4 Dry Contact Wiring The 8 input circuits on the 5880 board are for monitoring switch inputs-any type of switch supported by the control panel can be used with the 5880. For example, you can use a 5880 to monitor pull stations, water flow, tamper, reset, or silence switches.
  • Page 61: 5865-3 / 5865-4 Led Annunciator Installation

    Control Panel Installation 5865-3 / 5865-4 LED Annunciator Installation The 5865-3 and 5865-4 are LED annunciators. The 5865-4 has 30 mappable LEDs, remote silence and reset key switches, and a general system trouble LED. The 5865-3 has 30 mappable LEDs only. These are arranged as 15 pairs of red (typically used for alarm) and yellow (typically used for trouble) LEDs.
  • Page 62: 5865 Mounting

    IFP-100 Installation Manual 4.9.2 5865 Mounting Mount the 5865-4 to a standard 4-gang electrical box. Mount the 5865-3 to a standard 3-gang electrical box. In Figure 4-29, the 5865-4 attached to a 4-gang box is used as an example. Figure 4-29 5865 Mounting Example The 5865 ships with a set of zone description labels that can be inserted into the 5865 board assembly.
  • Page 63: Configuring Modules

    Control Panel Installation 4.10 Configuring Modules This section describes how to configure any system hardware modules that have been added to the system. 4.10.1 Assigning Module IDs When installing a hardware module (such as, 5824, RA-1000, RA-100, 5496, RPS-1000, 5865-3 or 5865-4), you must use the dipswitches on the module to assign an ID# to the module.
  • Page 64: Telephone Connection

    IFP-100 Installation Manual 4.11 Telephone Connection Connect the telephone lines as shown in Figure 4-32. The Model 7860 phone cord is available from Silent Knight for this purpose. A number of programmable options are available for customizing telephone lines. These options are described in Section 7.7.
  • Page 65: Conventional Notification Appliance

    Control Panel Installation 4.13.1 Conventional Notification Appliance This sub-section of the manual explains how to install conventional notification appliances for Class A (Style Z) and Class B (Style Y) configurations. 4.13.1.1 Class B Notification Wiring You must use an appliance from the list of compatible appliances in Appendix A. To install a Class B notification appliance circuit: 1.
  • Page 66: Class A Notification Wiring

    IFP-100 Installation Manual 4.13.1.2 Class A Notification Wiring You must use an appliance from the list of compatible appliances in Appendix A. To install a Class A notification appliance circuit: 1. Wire the Class A notification appliances as shown in Figure 4-34. Caution For proper system supervision do not use looped wire under terminals marked + and –...
  • Page 67: Auxiliary Power Installation

    Control Panel Installation 4.13.2 Auxiliary Power Installation NAC Circuits 1-4 on the control panel can be used as auxiliary power circuits. The three types of auxiliary power available are: • Door Holder (see section 4.13.2.1) • Constant (see section 4.13.2.2) •...
  • Page 68: Constant Power

    IFP-100 Installation Manual 4.13.2.2 Constant Power Use constant power for applications that require a constant auxiliary power source. Power is always present at Constant circuits. 4.13.2.3 Resettable Power Resettable power is typically used to power beam detectors, flame detectors and conventional 4-wire smoke detectors.
  • Page 69: Remote Station Applications

    Control Panel Installation 4.15 Remote Station Applications 4.15.1 Keltron Model 3158 Installation The control panel is compatible with Keltron Model 3158, used for direct connection to a Keltron receiver. The 3158 reports alarms, supervisories, and troubles. The steps for connecting the 3158 to the control panel. Refer to the 3158 installation instructions for complete information.
  • Page 70: City Box Connection Using The 5220 Module

    IFP-100 Installation Manual 4.15.2 City Box Connection Using the 5220 Module This section describes how to connect the control panel to a municipal fire alarm box or “city box” as required by NFPA 72 Auxiliary Protected Fire Alarm systems for fire alarm service. The city (master) box is an enclosure that contains a manually operated transmitter used to send an alarm to the municipal communication center which houses the central operating part of the fire alarm system.
  • Page 71: Nfpa 72 Polarity Reversal

    Control Panel Installation 4.15.3 NFPA 72 Polarity Reversal Note: Intended for connection to a polarity reversal circuit of a control unit at the protected premises having compatible rating. 4.15.3.1 Using the 5220 Module When the 5220 is wired and programmed for polarity reversal, it reports alarm and trouble events to a remote site.
  • Page 72 IFP-100 Installation Manual 5. If necessary, adjust loop current using the potentiometer (R10) on the 5220 board. Normal loop current is 2-to-8 mA with a 1k ohm remote station protected premise unit. Maximum loop resistance is 3k ohm. Note: NAC circuit 1 and Relay 1 used as examples.
  • Page 73: Using The 7644 Module

    Control Panel Installation 4.15.3.2 Using the 7644 Module When the 7644 is used for polarity reversal, it allows alarm and trouble events to be reported to a remote site. Alarms will override trouble conditions and it will not be possible to reset the remote indicator until the condition is cleared and the control panel is reset.
  • Page 74: Using The Sd500-Arm Addressable Relay Module

    IFP-100 Installation Manual 4.15.4 Using the SD500-ARM Addressable Relay Module When the SD500-ARM is wired for polarity reversal, it reports alarm and trouble events to a remote site. Alarms will override trouble conditions and it will not be possible to reset the remote indicator until the condition is cleared and the control panel is reset.
  • Page 75: Using A Mr-201/T Control Relay From Air Products

    Control Panel Installation 4.15.5 Using a MR-201/T Control Relay From Air Products When the MR-201/T control relay is wired for polarity reversal, it reports alarm and trouble events to a remote site. Alarms will override trouble conditions and it will not be possible to reset the remote indicator until the condition is cleared and the control panel is reset.
  • Page 76: Transmitter Activated By Dry Contacts

    IFP-100 Installation Manual 4.15.6 Transmitter Activated by Dry Contacts This section describes the connection of a UL 864 listed remote station transmitter to the IFP- 100 FACP dry contacts. The FACP contacts must be supervised by the remote station transmitter module using end-of-line resistors (ELRs) with a value determined by the transmitter manufacturer.
  • Page 77: Section 5 Idp And Hochiki Slc Device Installation

    Section 5 IDP and Hochiki SLC Device Installation Caution! To avoid the risk of electrical shock and damage to the unit, power should be OFF at the control panel while installing or servicing. List of IDP SLC Devices The following IDP SLC devices can be used with the control panel. See the device installation instructions for more information (packaged with the device).
  • Page 78: List Of Hochiki Slc Devices

    IFP-100 Installation Manual List of Hochiki SLC Devices The following Hochiki SLC devices can be used with the control panel. See the appropriate section number in this manual or the device installation instructions (packaged with the device) for more information. Note: The control panel supports the use of either Hochiki SLC devices or IDP SLC devices.
  • Page 79: Maximum Number Of Devices

    IDP and Hochiki SLC Device Installation Maximum Number of Devices The IFP-100 supports IDP or Hochiki devices on one IFP system. The maximum number of devices per system varies depending on device protocol. Device support is as follows: • IDP Devices–An IFP system can support a total of 99 IDP detectors and 99 IDP modules. •...
  • Page 80 IFP-100 Installation Manual Figure 5-1 and Figure 5-2 show how wire length is determined for out-and-back tap and T-tap style wiring. Figure 5-1 Calculating wire run length for a simple out and back tap When using T-taps, the total length of all taps and the main bus must not exceed 40,000 feet. This requirement must be met in addition to the maximum distance requirements for the various wire gauges.
  • Page 81: Wiring 5815Xl In Style 6 & 7 (Class A) Configuration

    IDP and Hochiki SLC Device Installation 5.4.2 Wiring 5815XL in Style 6 & 7 (Class A) Configuration Figure 5-3 illustrates how to wire the SLC loop for Style 6 or Style 7 Class A installations. Note: Style 6 does not use short circuit isolator devices. Figure 5-3 Class A SLC Configuration Note: No t-taps allowed on class A SLC loops.
  • Page 82: Wiring Idp Slc Detectors

    IFP-100 Installation Manual Wiring IDP SLC Detectors This section describes how to install IDP heat and smoke detectors. All detectors ship with installation instructions. Refer to the detector’s installation instructions for more detailed information. This information applies to the following IDP models: •...
  • Page 83 IDP and Hochiki SLC Device Installation rotary dial to set the tens place in a two digit number. IDP device addresses are handled differently than Hochiki device addresses. The control panel recognizes when an IDP detector or IDP module is installed. For this reason, IDP detectors can be assigned any unique address from 1 to 99, and IDP modules can be assigned any unique address from 1 to 99.
  • Page 84: Wiring Hochiki Detectors

    IFP-100 Installation Manual Wiring Hochiki Detectors The information in this section applies to the following Hochiki models: SD505-AHS Heat Detector, SD505-AIS Ionization Smoke Detector, and SD505-APS Photoelectric Smoke Detector. To wire SD505-APS, SD505-AHS, or SD505-AIS detectors: 1. Wire device bases as shown in Figure 5-6. 2.
  • Page 85: Addressing Hochiki Devices

    IDP and Hochiki SLC Device Installation Addressing Hochiki Devices This section tells how to address detectors and modules. 5.8.1 SD505-APS, SD505-AHS, & SD505-AIS The SD505-APS photoelectric smoke detector, SD505-AHS heat detector, and SD505-AIS ionization smoke detector are easily addressed at the FACP. The Installer Code is required to perform this task.
  • Page 86 IFP-100 Installation Manual 8. To exit press left arrow until fully exited. 5-10 151280...
  • Page 87: Hochiki Slc Devices With Dip Switches

    IDP and Hochiki SLC Device Installation 5.8.2 Hochiki SLC Devices with Dip Switches Input and relay module addresses are set using the dip switches on the module board. The chart below shows the available addresses. For example, to select address 3, place dip switches 1 and 2 in the up position.
  • Page 88 IFP-100 Installation Manual address. Figure 5-8 Hochiki SLC Device Addressing Using Dip Switches 5-12 151280...
  • Page 89: Section 6 Programming Overview

    Section 6 Programming Overview This section of the manual is intended to give you an overview of the programming process. Please read this section of the manual carefully, especially if you are programming the control panel for the first time. The JumpStart feature automates many programming tasks and selects default options for the system.
  • Page 90: Input Points

    IFP-100 Installation Manual 6.1.1 Input Points JumpStart will determine the number and type of input points (detectors or contact monitor modules) on each SLC loop. JumpStart assigns the correct detector type (heat, ionization or photoelectric), so the installer does not need to edit device type for detectors. Any contact monitor modules on the system will be assigned type "Manual Pull."...
  • Page 91 Programming Overview 4. The message "WARNING Will DELETE all system options" displays on the LCD. Select Yes to continue. A series of messages displays for the next several seconds. JumpStart scans the SLC loops for devices. This can take several minutes, depending on the number of devices attached.
  • Page 92: Mapping Overview

    IFP-100 Installation Manual Mapping Overview This section of the manual is an overview of mapping. Details about how to select mapping options appear in the appropriate subsections in Section 7. Mapping is an important concept with the control panel. In general terms, mapping is assigning or linking events to outputs that should activate when events occur.
  • Page 93: Input Point Mapping

    Programming Overview 6.2.1 Input Point Mapping Input points are assigned to input zones. Any input point can be assigned to any input zone. (Input points can be assigned to one zone only. An input point can be designated as "Unused," which means it has not been assigned to a zone.) Figure 6-2 Input Point Assignment Example 151280...
  • Page 94: Output Circuit Mapping

    IFP-100 Installation Manual 6.2.2 Output Circuit Mapping Figure 6-3 is a simple example showing how to assign notification and relay output circuits to groups. For an example of a simple floor above/floor below application, see Figure 6-5. Figure 6-3 Assigning Output Circuits to Groups (Example) 151280...
  • Page 95: Zone Event Mapping

    Programming Overview 6.2.3 Zone Event Mapping There are 8 types of events that can occur in zones (see below). For each event type, you can activate up to 8 output groups and patterns. If it is necessary to map to more than 8 output groups, an output group template may be used (see Section 7.5.5 for information on output group templates).
  • Page 96 IFP-100 Installation Manual Figure 6-5 Example of Zone Events Mapped to Output Groups and Patterns 151280...
  • Page 97: Mapping Led Points

    Programming Overview 6.2.4 Mapping LED Points Figure 6-6 is a simple example showing how LED points are mapped to zones and output groups. Typically you would create two output groups for each zone, one for alarms and one for troubles. (LED points are available when Models 5865-3/4 and/or 5880 are used with the system.) Figure 6-6 Example of LED Points Mapped to Output Groups (applies to Models 5865-3/4 and 5880)
  • Page 98: Programming Using The 5650/5651 Silent Knight Software Suite

    IFP-100 Installation Manual Programming Using the 5650/5651 Silent Knight Software Suite You can use the 5650/5651 Silent Knight Software Suite (SKSS) to program the control panel onsite or remotely. SKSS is an optional software package that lets you easily program the control panel using a Windows-based computer and a modem* (not sold by Silent Knight).
  • Page 99: Entering / Exiting The Programming Menu

    Programming Overview 6.4.1 Entering / Exiting the Programming Menu To enter the Programming Menu: 1. Press the key to bring up the Main Menu (see Figure 6-7). 2. Enter the Installer Code (factory programmed default code is 123456) if prompted. Figure 6-7 Keypad Enabled Screen 3.
  • Page 100: Selecting Options And Entering Data

    IFP-100 Installation Manual 6.4.3 Selecting Options and Entering Data There are several ways to make programming selections using the control panel depending on which screen you are currently using. The chart below is a generic explanation. Table 6-1 Press Select from a menu. Enter the number of the option.
  • Page 101: Programming Menu Quick Reference

    Programming Overview Programming Menu Quick Reference This section of the manual lists all Program Menu options in the order they appear on the sub- menus. Default settings are indicated in text or marked with an asterisk. The comments column provide quick information and a reference to a section (if applicable) which has more detailed information.
  • Page 102 IFP-100 Installation Manual Menu Options/Defaults Comments Supervisory (Group 249, Section 7.4.1 Zone Outputs (SU) Pattern 00) (cont.) Edit Zone Select Zone to Edit Trouble (TR) no group (cont.) (cont.) Cadence 00-20 Zone Zone Accessry Opt (cont.) Local Zone Yes or No Add Zone Adds next available zone number.
  • Page 103 Programming Overview Menu Options/Defaults Comments UNUSED PHOTO HEAT DETECTOR Select zone PHOT DUCT ION DUCT 2WIRE SMK SUP PHOTO LATCH NLATCH SUP DET SUP ION LATCH NLATCH MAN_PULL LATCH WATERFLOW NLATCH SUPERVSY LATCH NLATCH FIREDRILL SILENCE RESET Point Hochiki SLC Loop Enter Pt Section 7.6 PAS_ACK LATCH...
  • Page 104 IFP-100 Installation Manual Menu Options/Defaults Comments UNUSED PHOTO Select Zone HEAT PHOT DUCT Enter Pt DETECTOR 2WIRE SMK Section 7.6.1. Acclimate Heat HT Photo-Heat Beam SUP DET SUP PHOTO MAN_PULL LATCH WATERFLOW NLATCH SUPERVSY LATCH NLATCH FIREDRILL SILENCE RESET Point PAS_ACK IDP SLC Loop (cont.)
  • Page 105 Programming Overview Menu Options/Defaults Comments UNUSED Section 7.6.2 B NOTIF Select Group A NOTIF Select Type CONSTANT Internal Pwr and AUX PWR RESETABLE External Power DOOR Select Group or Group or Zone selection will Zone Number appear depending on the type is selected.
  • Page 106 IFP-100 Installation Manual Menu Options/Defaults Comments Switch attempts 1 - 5 Section 7.7.1.1 Edit Acct. (cont.) Edit Phone #1 up to 24 digits blank Section 7.7.1.1 Reporting Accounts Set the Hour (cont.) Auto Test Time Set the Minutes *02:00 AM Section 7.7.1.2 Select AM/PM For each phone line (1 &...
  • Page 107 Programming Overview Menu Options/Defaults Comments Section 7.7.4 Enable/Disable *N = Disabled Day/Night Sense. Day Start enter time Night Start enter time Days of the Week Select days Holidays Holidays 1 to 9 Enter dates Section 7.7.5 0 - 90 Seconds *30 sec Water Flow delay is the number of Water Flow Delay...
  • Page 108 IFP-100 Installation Manual Menu Options/Defaults Comments Section 7.8 JumpStart AutoPrg Computer Account *123456 Computer Computer Access Section 7.9 Account Code Computer Phone # Up to 24 digits Edit Name Edit Access Code System Reset System Silence System Event Ack. Fire Drill Key System Tests Fire Drill Menu Indicator Test...
  • Page 109: Section 7 Programming

    Section 7 Programming This section of the manual describes how to manually program the control panel from the built-in annunciator. Each subsection discusses these menu options in detail. All options described in this section can be performed using the Silent Knight Software Suite 5650/5651. Important! Before any customized programming is done, Jump-start should be run first.
  • Page 110: Slc Family

    IFP-100 Installation Manual SLC Family The IFP-100 supports the use of either Hochiki protocol SLC devices or Intelligent Device Protocol (IDP) SLC devices. You must configure the IFP-100 to accept the protocol you are installing. You cannot mix SLC devices of different protocols. 1.
  • Page 111: Naming Modules

    Programming 5. Press to edit a module. 6. Use the arrow to select the module you wish to edit. 7.3.1.1 Naming Modules You can assign an English name to a system hardware module to make it easier to recognize on a display. 7.
  • Page 112: Deleting A Module

    IFP-100 Installation Manual Please wait . . . 4. Press to enter module menu. 5. Press to add a module. 6. From the next screen, select the number that corresponds to the type of module you are adding from the <New Module Type> screen. The screen will display “Adding module [#]...”...
  • Page 113: Edit Zone Name

    Programming 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait . . . 4. Press to enter zone menu. 5. Press to edit a zone. 6. Enter the zone number, then press 7.4.1.1 Edit Zone Name 7.
  • Page 114: Edit Zone Properties

    IFP-100 Installation Manual 8. Select the characters for the zone name by pressing the arrow until the desired character is shown then press Enter the Numerical Designator for the character you want, then press . See Appendix B of this manual for a list of available characters and their numeric designators. 9.
  • Page 115: Alarm Delay Characteristics

    Programming Alarm Delay Characteristics 3. Select the alarm delay characteristics by pressing the arrow. Table 7-1 list the delay choices and a description of each. Table 7-1: Alarm Delay Types Type of Delay Description One Count (No Delay). When this option is enabled, an alarm occurs immediately when a single device of any of the following types goes into alarm: detector, manual pull, water 1-Count flow, Aux1 or Aux2.
  • Page 116 IFP-100 Installation Manual Table 7-1: Alarm Delay Types Type of Delay Description Alarm verification is an optional false alarm prevention feature that verifies an alarm condition by resetting the smoke detector. If the alarm condition still exists by the time the reset cycle has completed, the detector will go into alarm.
  • Page 117: Heat Detector Sensitivity

    Programming Heat Detector Sensitivity Use this feature to set the temperature at which high temperature detectors will respond. All detectors in the zone will respond in the same way. The range for the SD505-AHS heat detector is from 135°F to 150°F. The range for IDP-Heat-HT heat detector is from 135°F to 190°F.
  • Page 118: Then Press

    IFP-100 Installation Manual Table 7-2: Hochiki & IDP Detector Sensitivity Choices* Detector Type of Smoke Choices Comments Protocol Detector Low (3.5% obscurity) If the day/night sensitivity option is selected, you can have IDP-Photo, different sensitivity settings during the day and at night. You IDP-Acclimate, &...
  • Page 119: Mapping To Zone Events

    Programming Note: Use of multiple notification groups may not synchronize with each other. Mapping to Zone Events Eight types of events can occur in zones. For each event type, you can activate up to 8 output groups or output group template, specifying a pattern for each. The following is a list of all event types: Note: Abbreviations in parentheses are the characters that are displayed in programming.
  • Page 120: Zone Mapping Example

    IFP-100 Installation Manual Zone Mapping Example Suppose you want to program Zone 1 so that: • Any alarm (detector, water flow or manual pull) would activate Output Group 1 using the ANSI cadence pattern. • Manual pull alarm would activate Output Group 3 using constant output. •...
  • Page 121: Cadence Patterns

    Programming 7.4.1.4 Cadence Patterns The cadence patterns shown in Figure 7-5 are available for use with the control panel. Cadence patterns can be selected by event type for each zone or for the entire system. Special cadence patterns can be selected for fire drills and any auxiliary system switches used with the system.
  • Page 122: Add Zone

    IFP-100 Installation Manual ADHRs. Single or Multi-station cadence pattern (choose from Patterns 00 to 21). Local Zone (choose Y or N, for Yes or No). 7.4.2 Add Zone To add a zone, follow these steps: 1. Press to display the main menu. 2.
  • Page 123 Programming 5. Press to delete a zone. A warning screen will display. If you want to proceed with deleting the zone, select Yes. To cancel, select No. 151280 7-15...
  • Page 124: View Zone Points

    IFP-100 Installation Manual 7.4.4 View Zone Points To view the points in a zone, follow these steps: 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait . . . 4.
  • Page 125: Group

    Programming Group An output group is made up of output points that have been programmed to respond in the same way. Output groups simplify programming because you have to program the output characteristics that are common to all of the group points once, instead of programming each individual point.
  • Page 126: Edit Group Name

    IFP-100 Installation Manual 7.5.1.1 Edit Group Name 7. To edit the group name, press . A screen similar to the one shown in Figure 7-7 displays. Figure 7-7 Selecting Character for Zone Name 8. Select the characters for the zone name by pressing the arrow until the desired character is shown then press Enter the Numerical Designator for the character you want, then press...
  • Page 127: Latching / Non-Latching Outputs

    Programming Figure 7-8. Figure 7-8 Group Properties Screen Programming Options Latching / Non-latching Outputs Outputs that are programmed as Latching remain active until the system has been manually reset. Non-latching outputs stop activating automatically when the condition clears. Silencing Options The following silencing options are available for each output group.
  • Page 128 IFP-100 Installation Manual (See Figure 7-8 for location of this field.) Table 7-5: Output Group Response Choices Option Description ManPull Manual Pull Activation. Select Yes if you want this group to activate for all manual pull alarms that occur in the system. Note: Even though manual pull switches are assigned to zones, activation selected here for manual pull will override zone-programmed activation.
  • Page 129: Define Output Group Type

    Programming Define Output Group Type Each output group is defined as either a voice output group or a non-voice output group. Output points that are audio circuits (all circuits on the VIP-50 and VIP-CE4) can only be assigned to voice output groups. Output points that are non-voice circuits (all other points and circuits that are on all modules except the VIP-50 and VIP-CE4) are assigned to non-voice output groups.
  • Page 130: Delete Group

    IFP-100 Installation Manual 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait . . . 4. Press to enter group menu. 5. Press to add a group. The system will assign the next available group number.
  • Page 131: View Group Points

    Programming 7.5.4 View Group Points 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait . . . 4. Press to enter group menu. 5. Press to view group points. 6.
  • Page 132: Point

    IFP-100 Installation Manual To create Output Group Templates: 1. From the Main Menu, select for Program Menu. 2. From the Program Menu, select for Group. 3. At the next screen, select for Edit OPG Template. 4. Select the template number (01 - 08). 5.
  • Page 133 Programming 151280 7-25...
  • Page 134 IFP-100 Installation Manual Table 7-6: Point Programming Type Latching Module Type Function Comments Selection Option UNUSED PHOTO HEAT PHOT DUCT ION DUCT Hochiki devices only DETECTOR 2WIRE SMK Acclimate IDP devices only Heat HT Photo-Heat Beam SUP PHOTO Latching SUP DET SUP ION Non Latching Hochiki devices only...
  • Page 135 Programming Table 7-6: Point Programming Type Latching Module Type Function Comments Selection Option Positive acknowledge switch. This switch must be used in zones programmed as Positive Alarm Sequence (see Table 7-1). If an acknowledge switch closes when an alarm or trouble condition is not already in progress, a trouble PAS_ACK will occur.
  • Page 136: Point Programming For Internal Or External Power Module

    IFP-100 Installation Manual 7.6.2 Point Programming For Internal or External Power Module (5496) To program for an internal or external power module points, follow these steps: 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait .
  • Page 137: Point Programming For 5880, 5865, Vip-50, And Vip-Ce4 Modules

    Programming 7.6.3 Point Programming For 5880, 5865, VIP-50, and VIP-CE4 Modules To program 5880, 5865, VIP-50, or VIP-CE4 module points: 1. Enter the installer code. 2. Press to display the main menu. 3. Select for Program Menu. Display reads: Initializing Please wait .
  • Page 138: Assigning A Name To A Point

    IFP-100 Installation Manual 7.6.3.1 Assigning a Name to a Point You can assign a name to a point to make it easier to recognize on a display. If you wish to edit the name of a point, follow these instructions: 1.
  • Page 139: System Options

    Programming System Options This section of the manual explains how to customize software options that affect general operation of the system. This includes such items as: AC loss hours, system clock options, holidays schedule, telephone and reporting account options. Refer to each individual subsection for complete instructions.
  • Page 140: Edit Accounts

    IFP-100 Installation Manual 7.7.1.1 Edit Accounts 6. From the next menu, select for Edit Account. A screen similar to one shown in Figure 7-13 will display. The following subsections describe the options on each field. Figure 7-13 Reporting Account Editing Screen Select Account (ID) The control panel provides up to 4 reporting accounts.
  • Page 141 Programming 9. Press the arrow to select the reporting format, then press 151280 7-33...
  • Page 142: Events To Report

    IFP-100 Installation Manual Events to Report The next six options select which types of events (or event families) will be reported to this account. (See Figure 7-13 for location of these options on the screen.) Events are reported by zone. Event Family Events Included in this Family Alarms...
  • Page 143: Telephone Number

    Programming Telephone Number Enter up to 24 characters for phone number for this account. The following special characters are available: Table 7-7: Special Dialing Characters Pound (or number) key on the telephone Star key on the telephone Comma (character for 2-second pause) Use the number buttons on the annunciator or the up- and down-arrow keys to select special characters.
  • Page 144: Phone Lines

    IFP-100 Installation Manual 7.7.2 Phone Lines To access the phone lines screen: 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait . . . 4. From the Program Menu, select for System Options.
  • Page 145: Number Of Answer Rings

    Programming 7.7.2.2 Number of Answer Rings This option is used in conjunction with the Silent Knight Software Suite 5650/5651. Use the option to determine the number of rings before the panel answers a call from the computer. Range is 00-15 rings. This option is factory-programmed as 06 rings, which should be compatible for most installations where the answering machine bypass feature is used.
  • Page 146: Ground Start Relay

    IFP-100 Installation Manual 7.7.2.6 Ground Start Relay If using the 5211 ground start relay, you must enable the ground start relay programming option. See Figure 7-14 for the location of this field on the phone lines screen. This option is disabled by default.
  • Page 147: Sys. Event Outputs

    Programming 7.7.3 Sys. Event Outputs 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait . . . 4. From the Program Menu, select for System Options. 5. From the System Options Menu, select for Sys.
  • Page 148: Trouble Events

    IFP-100 Installation Manual 7.7.3.1 Trouble Events You can map certain system trouble events to an output group. To access the screen for selecting output groups and cadence patterns for system trouble events. 6. Press for Trouble Events. A screen similar to the one in Figure 7-15 will display. Select a group and a cadence pattern for each event as needed for your application.
  • Page 149: System Alarm Cadence

    Programming 7.7.3.2 System Alarm Cadence Fire drill and system auxiliary alarm events can have special cadence patterns to distinguish them from other types of alarms. See Section 7.4.1.4 for available cadence patterns. A typical use of the System Aux1 and Aux2 patterns is to distinguish fire emergencies from other types of emergencies.
  • Page 150: Day/Night Sensitivity Time

    IFP-100 Installation Manual 7.7.4 Day/Night Sensitivity Time If you need to change the time that sensitivity levels take effect (that is, the time that "Day" and "Night" begin), follow these steps. 1. Press to display the main menu. 2. Select for Program Menu.
  • Page 151: Holiday Days

    Programming 7.7.5 Holiday Days Up to 18 dates can be designated as holidays. When day/night sensitivity is enabled, all photoelectric smoke detectors in the system will use night sensitivity for the entire day on days designated as holidays (see Section 7.7.4). To add or change a holiday, follow these steps.
  • Page 152: Miscellaneous Options 1

    IFP-100 Installation Manual 7.7.6 Miscellaneous Options 1 Through this programming option you can set the water flow delay time, low AC report delay, enable or disable automatic daylight savings time adjustment, clock format, and AC clock frequency. 7.7.6.1 Water Flow Delay You can program a delay of 0-90 seconds (zero means no delay) to be used in conjunction with a water flow switch.
  • Page 153: Automatic Daylight Saving Time Adjustment

    Programming Note: Steps continued from step 6 of Section 7.7.6.1. Low AC Report Delay in Hours (00 - 30) Figure 7-21 Low AC Report Delay Programming Screen 7. Enter the number of hours before a low AC report will be sent to the central station, then press .
  • Page 154: Miscellaneous Options 2

    IFP-100 Installation Manual To change the AC line frequency, continue programming from step 9 above: 10. Select 50, 60 or Neither, by pressing the arrow, then press 7.7.7 Miscellaneous Options 2 Through this programming option you can turn the strobe synchronization during silence feature On or Off, and select the control panel to report events by zone or by point.
  • Page 155: Miscellaneous Options 3

    Programming 10. Press the arrow to toggle this selection between Zone or Point. 11. Then press . See Section 9 for reporting codes. 7.7.8 Miscellaneous Options 3 From Miscellaneous Options 3, you set the alarm verification time and set the start and end week and month of Daylight Saving Time.
  • Page 156 IFP-100 Installation Manual 10. Press the arrow to select the week (1st, 2nd, etc.) Daylight Saving Time ends, then press to make your selection and move to the month setting. 11. Press the arrow to select the month (January – December) Daylight Saving Time ends, then press two times to make your selection and exit Misc.
  • Page 157: Edit Banner Message

    Programming 7.7.9 Edit Banner Message The banner is the message that displays on the panel LCD when the system is normal, that is, when no alarms or troubles exist and no one is currently using system menus. You can create a customized message, which can be up to 40 characters, two lines of 20 characters each.
  • Page 158: Edit Voice Commands

    IFP-100 Installation Manual 7.7.10 Edit Voice Commands When a voice output group is selected to be activated by a zone, the cadence pattern choices listed in Section 7.4.1.4 do not apply. For voice output groups, one of six system-wide voice commands will activate instead of the cadence pattern.
  • Page 159: Jumpstart Autoprogramming

    Programming JumpStart Autoprogramming IMPORTANT! JumpStart is intended to be used prior to performing any custom programming. Each time JumpStart is executed, all options will be reset to their default values. Do not run JumpStart after you have configured the system through programming. To run JumpStart: 1.
  • Page 160 IFP-100 Installation Manual 4. Select for System Options. 5. Enter the computer account number, then press 6. Enter the computer code (up to 7-digits), then press 7. Enter the phone number the panel will dial to connect to a downloading computer (up to 24-digits), then press .
  • Page 161: Access Codes

    Programming 7.10 Access Codes Access codes provide the user access to the control panel functions. Each access code can be customized for each user. This allows some users the ability to access programming and other higher level panel functions, while other users may only need access to lower level functions such as preforming fire drills, or acknowledging trouble conditions.
  • Page 162 IFP-100 Installation Manual Table 7-8: User Profile Selectable Panel Functions Type of Function Selectable Functions System Test Fire Drill Indicator Test Walk Test no Report Walk Test with Report Dialer Test Clear History Buffer Point Functions Disable/Enable Point Point Status Set SLC Device Address SLC Device Locator Panel Menus...
  • Page 163: Profile Edit Menu

    Programming To change an access code: 1. Press to display the main menu. 2. Select for Program Menu. 3. Enter code if prompted. Display reads: Initializing Please wait . . . 4. Select for System Options. Display reads: Select Profile 01 Fire Fighter’s Key 5.
  • Page 164: Vip-Vcm Maintenance

    IFP-100 Installation Manual 15. Then press to move to Y (yes) or N (no) selection column. 16. Press the arrow to select Y or N. 17. Press 18. Repeat steps 14 through 17 until user profile is complete. 7.11 VIP-VCM Maintenance This programming menu option enables the user to add and edit the user message stored in the VIP-VCM.
  • Page 165 Programming 13. Record your the user message. 151280 7-57...
  • Page 166 IFP-100 Installation Manual 7-58 151280...
  • Page 167: Section 8 System Operation

    Section 8 System Operation Operation of the control panel is simple. Menus guide you step-by-step through operations. This section of the manual is an overview of the operation menus. Please read this entire section carefully before operating the panel. Press to view Main Menu: Select the desired menu option.
  • Page 168: Lcd Displays

    IFP-100 Installation Manual 8.2.1 LCD Displays The control panel LCD displays system messages, annunciates alarms, supervisories and troubles; provides status information; and prompts for input. These messages can be up to 80 characters, displaying over four lines of 20 characters each. Annunciator keys beep when they are pressed.
  • Page 169: Menu System

    System Operation Menu System The control panel is easy to operate from the Main Menu. To view the Main Menu press the button on the control panel or remote annunciator. The Main Menu will appear as shown in Section 8.3.1. Select the desired option and enter your access code if prompted. The control panel supports up to 20 access codes.
  • Page 170: Using The Menus

    IFP-100 Installation Manual 8.3.2 Using the Menus To move through the menus: to move through the options in a menu. Use to move to a previous menu. To select an option: Enter the number of the option. –OR– ENTER Press (Enter key) if the option appears at the top of the menu (= symbol displays after the option number in this case).
  • Page 171: View Event History

    System Operation 8.4.4 View Event History Use the View Event History feature to display events on LCD. From the Main Menu, press to select Event History. Events will begin displaying with most recent events first. The panel can store up to 1000 events. When it reaches its 1000-event capacity, it begins deleting, starting with the oldest events.
  • Page 172: Conduct A Walk Test

    IFP-100 Installation Manual 8.4.8 Conduct a Walk Test 1. From the Main Menu, press for System Tests. IMPORTANT! If any alarm verification zones are being used, the user will be asked if they wish to disable alarm verification during walk test. This occurs for either walk test option. 2.
  • Page 173: Silence Alarms Or Troubles

    System Operation 8.4.10 Silence alarms or troubles Press and enter your code. If an external silence switch has been installed, activating SILENCE the switch will silence alarms or troubles. Note: Alarm and trouble signals that have been silenced but the detector remains un-restored will un-silence every 24 hours until it is restored.
  • Page 174: View Status Of A Point

    IFP-100 Installation Manual 5. A screen similar to those shown in Figure 8-3 will display. Figure 8-3 Checking Detector Sensitivity Compliance If a printer is attached to the system (via a Module 5824 serial/parallel printer interface module), you can print detector status (see Section 8.4.18). 8.4.13 View Status of a Point 1.
  • Page 175: Communicating With A Remote Computer

    System Operation 8.4.17 Communicating with a Remote Computer An installer at the panel site can initiate communications between the panel and a computer running the Silent Knight Software Suite 5650/5651. You can use this feature to upload a panel configuration. For example, if you have made programming changes to an installation on site using an annunciator, you can send your changes to the computer, so that the central station will have the latest data about the installation.
  • Page 176: Working With A Printer

    IFP-100 Installation Manual 8.4.18 Working with a Printer If you are using the Model 5824 serial/parallel printer interface module, several printing options are available. See Section 4.7 for information about installing the 5824. 1. From the Main Menu, select Printer Options. 2.
  • Page 177: Operation Mode Behavior

    System Operation Operation Mode Behavior The control panel can be in one of seven conditions at any given moment: Normal, Alarm, Prealarm, Supervisory, Trouble, Silenced, and Reset. Table 10-1 describes the behavior of the panel in each of these modes. Table 8-1: Operation Mode Behavior Operation Occurs When...
  • Page 178 IFP-100 Installation Manual Table 8-1: Operation Mode Behavior Operation Occurs When System Behavior In This Mode You Can Mode Supervisory The system The dialer seizes control of the phone line Press (down arrow) to view the supervisory detects a and calls the central station. condition.
  • Page 179 System Operation Table 8-1: Operation Mode Behavior Operation Occurs When System Behavior In This Mode You Can Mode Prealarm A single detector Touchpad PZT beeps. Press (down arrow) to view the prealarm. A trips in a 2- The LCD displays a screen similar to this screen similar to this one displays.
  • Page 180: Releasing Operations

    IFP-100 Installation Manual Releasing Operations This control panel supports two types of releasing: Double Interlock Zone and Single Interlock Zone. The Double Interlock Zone operation requires an interlock switch input in the system, and the Single Interlock does not. An interlock switch is typically a dry-contact pressure switch.
  • Page 181: Single Interlock Zone Releasing

    System Operation 8.6.1 Single Interlock Zone Releasing A single interlock zone utilizes a minimum of two addressable detectors, and a designated manual release switch. Important! Only addressable detectors can be used. No conventional detectors can be used. Each Single Interlock Zone input requires at least one manual release switch. Conditions Required for an Pre-Alert Output Activation If any single addressable detector is activated, the "Pre-Alert"...
  • Page 182: Double Interlock Zone Releasing

    IFP-100 Installation Manual 8.6.2 Double Interlock Zone Releasing A Double Interlock Zone uses a minimum of two Addressable detectors, a designated manual release switch, and an interlock switch input. An interlock switch is typically a dry-contact pressure switch and will be referred to as an interlock/pressure switch in this document. Important! Only addressable detectors can be used.
  • Page 183: Smoke Alarm Verification

    System Operation Smoke Alarm Verification Figure 8-5 illustrates how the Smoke Alarm Verification cycle operates. Figure 8-5 Smoke Verification Cycle During the Confirmation Period if there is no alarm indication then the system will return to normal operation. 151280 8-17...
  • Page 184 IFP-100 Installation Manual 8-18 151280...
  • Page 185: Section 9 Reporting

    Section 9 Reporting This section lists receivers that are compatible with this control panel, and the reporting codes sent by the control panel for SIA and Contact ID formats. Receivers Compatible with the Control Panel Table 9-1 shows receivers compatible with the control panel. Table 9-1: Receivers Compatible with the Control Panel Manufacturer Model...
  • Page 186 IFP-100 Installation Manual SIA Reporting Format Contact ID Reporting Format Event Class Module Event Parameter Event Group Contact Event Description (System, Zone, ID # Event Qualifier Family (if any) Code or Point) (if any) Code Phone line 2 trouble detected Trouble System Event Local programming aborted or ended with errors...
  • Page 187 Reporting SIA Reporting Format Contact ID Reporting Format Event Class Module Event Parameter Event Group Contact Event Description (System, Zone, ID # Event Qualifier Family (if any) Code or Point) (if any) Code Supervisory/Tamper switch trouble restore Trouble Zone Event Zone Zone Supervisory condition restore...
  • Page 188 IFP-100 Installation Manual SIA Reporting Format Contact ID Reporting Format Event Class Module Event Parameter Event Group Contact Event Description (System, Zone, ID # Event Qualifier Family (if any) Code or Point) (if any) Code Point Enabled Disable Point Event pi Exp.
  • Page 189: Testing And Troubleshooting

    Section 10 Testing and Troubleshooting 10.1 Troubleshooting This section of the manual offers suggestions for troubleshooting hardware problems. Please read this section if you encounter a problem when installing the control panel. If these suggestions do not solve your problem or if you encounter a problem that is not listed here, contact Silent Knight Technical Support at 800-328-0103 for assistance.
  • Page 190: Event History

    IFP-100 Installation Manual Problem Possible Cause / Suggested Actions SLC devices are not being recognized Check that SLC loop impedance is within the required range. (trouble message "Missing" displays on To measure impedance, use the following procedure. the annunciator). 1. Disconnect both wires from the terminal block at the panel (SLC devices can remain connected).
  • Page 191: Built-In Troubleshooting And Testing Tools

    Testing and Troubleshooting 10.3 Built-in Troubleshooting and Testing Tools The fire control panel has several built-in testing and troubleshooting tools that can be utilized to save time while testing and troubleshooting points and SLC devices. 10.3.1 SLC Device Locator SLC device locator can be used to locate a device on a SLC loop. Follow these steps to locate a particular SLC device: 1.
  • Page 192: Slc Multi Locator

    IFP-100 Installation Manual 10.3.2 SLC Multi Locator This feature is the same as SLC Device Locator, except you can locate up to 8 devices on a single search. Follow these instructions to locate multiple SLC devices: 1. Select (Point Functions) from the Main Menu. 2.
  • Page 193: I/O Point Control

    Testing and Troubleshooting 10.3.3 I/O Point Control This feature allows you to toggle any output on or off and trip any input device. This can be useful to test a point’s output mapping. Follow these steps to control a I/O point: 1.
  • Page 194 IFP-100 Installation Manual 10-6 151280...
  • Page 195: Section 11 Installation Records

    Section 11 Installation Records This section of the manual is for you to use if you wish to track of how points, zones, and groups have been programmed. 11.1 Hochiki SLC Device Point Record You can use Table 11-1 to keep track of Hochiki SLC device points. Default addresses for ID:On-board: = 33 Table 11-1: Hochiki Installation Record Zone /...
  • Page 196 IFP-100 Installation Manual Table 11-1: Hochiki Installation Record Zone / Zone/ Module Addr Description Module Addr Description Group Group On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board On-board...
  • Page 197: Appendix A Compatible Devices

    Appendix A Compatible Devices Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type SH24W-153075 Horn/Strobe SAD24-153075 Strobe SAD24-75110 Strobe SL24W-75110 Strobe SL24C-3075110 Strobe SLB24-75 Strobe RSD24-153075 Strobe RSD24-75110 Strobe AMSECO SH24W-75110 Horn/Strobe SH24W-3075110 Horn/Strobe SHB24-75 Horn/Strobe SCM24W-153075 Chimes/Strobe SCM24W-75110 Chimes/Strobe SCM24C-3075110 Chimes/Strobe...
  • Page 198 IFP-100 Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Vibrating Bell Vibrating Bell Single Stroke Bell 2700 -M. -R, -T, -Y, -Z Strobe 2701 Series Strobe 2705 Series Strobe 2820 Snyc Temporal Horn/Strobe 2821 Snyc Temporal Horn/Strobe 2824 Horn Strobe 5333...
  • Page 199 Compatible Devices Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Faraday 5388 8-Tone Horn/Strobe with Sync Strobe 5508 Single Gang Sync Strobe 5509 Strobe 5510 Strobe 5511 Strobe 5512 Strobe 5516 Strobe 5517 Strobe 5518 Strobe 5519 Strobe 5521 4”...
  • Page 200 IFP-100 Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type S2415-FC Strobe S241575-FC Strobe S2430-FC Strobe 130-3117C Mini Horn 130-3147C Mini Horn BLV-6 Vibrating Bell BLV-10 Vibrating Bell BLVCH Vibrating Chime H12/24-FC Horn H12/24W-FC Horn H12/24K-FC Horn HC12/24-FC Horn HC12/24W-FC...
  • Page 201 Compatible Devices Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type GEC-24-15 Horn/Strobes GEC-24-30 Horn/Strobes GEC-24-60 Horn/Strobes GEC-24-75 Horn/Strobes GEC-24-177 Horn/Strobes GX91 MiniHorn Steady Tone GX93 MiniHorn Temporal Tone HG124 Horn HS24-15 Horn/Strobe HS24-30 Horn/Strobe HS24-60 Horn/Strobe HS24-75 Horn/Strobe HS24-110 Horn/Strobe HS24-1575...
  • Page 202 IFP-100 Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type ST24-60 Strobe ST24-75 Strobe ST24-110 Strobe ST24-1575 Strobe WGEC24-75W Weatherproof Horn/Strobe WGES24-75W Weatherproof Strobe Gentex con’t WGMS-24-X Horn/Strobe SSPKWR Speaker SSPKWW Speaker SSPK-15WR Speaker/Strobe SSPK-15WW Speaker/Strobe SSPK-15/75WR Speaker/Strobe SSPK-15/75WW Speaker/Strobe...
  • Page 203 Compatible Devices Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Chime Chime CHSR 2-Wire Chime/Strobe CHSW 2-Wire Chime/Strobe Horn Horn Horn 2-Wire Horn/Strobe P2R-P 2-Wire Horn/Strobe PC2R 2-Wire Horn/Strobe PC2R-P 2-Wire Horn/Strobe P2RH 2-Wire Horn/Strobe High Candela P2RH-P 2-Wire Horn/Strobe High Candela PC2RH 2-Wire Horn/Strobe High Candela...
  • Page 204 IFP-100 Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type 4-Wire Horn/Strobe PC4W 4-Wire Horn/Strobe P4WH 4-Wire Horn/Strobe High Candela PC4WH 4-Wire Horn/Strobe High Candela P4RK 4-Wire Horn/Strobe PC4RK 4-Wire Horn/Strobe P4RHK 4-Wire Horn/Strobe High Candela PC4RHK 4-Wire Horn/Strobe High Candela PC4RH 4-Wire Horn/Strobe High Candela...
  • Page 205 Compatible Devices Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type AH-12 Horn AH-24 Horn AH-12WP Horn Weatherproof AH-24WP Horn Weatherproof AMT-241575W Multi-Tone Horn Strobe AMT-24MCW Mutli-Tone Horn Strobe AMT-241575W-NYC Multi-Tone Horn Strobe AMT-12/24 Multi-tone Horn Wheelock AMT-12/24 NYC Multi-tone Horn AS-121575W Horn/Strobe...
  • Page 206 IFP-100 Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Wheelock ASWP-2475W Horn/Strobe Weatherproof ASWP-2475C Horn/Strobe Weatherproof (cont.) ASWP-24MCWH Horn/Strobe ASWP-24MCCH Hor/Stroben CH70-241575W Chime/Strobe CH70-24MCW Chime/Strobe CH70-24MCWH Chime/Strobe CH90-24MCC Chime/Strobe CH90-24MCCH Chime/Strobe HS-24 Horn HS4-241575W Horn/Strobe HS4-24MCW Horn/Strobe HS4-24MCWH Horn/Strobe...
  • Page 207 Compatible Devices Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type NS-24MCCH Horn/Strobe ZNS-MCW Horn/Strobe ZNS-MCWH Horn/Strobe ZNS-24MCC Horn/Strobe Wheelock ZNS-24MCCH Horn/Strobe Con’t RSS-121575W Strobe RSS-241575W Strobe RSS-24MCC Strobe RSS-24MCCR Strobe RSS-24MCCH Strobe RSS-24MCCHR Strobe RSS-24MCW Strobe RSS-24MCWH Strobe RSSP-121575W Strobe RSSP-241575W...
  • Page 208 IFP-100 Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type RSSWPA-2475W Strobe Weatherproof RSSWPA-24MCCH Strobe Weatherproof RSSWPG-24MCCH Strobe Weatherproof RSSWPR-24MCCH Strobe Weatherproof RSSWP-2475W Strobe Weatherproof Wheelock RSSWP-2475C Strobe Weatherproof Con’t RSSWP-24MCWH Strobe Weatherproof ZRS-MCWH Strobe ZRS-24MCC Strobe ZRS-24MCCH Strobe CH-70...
  • Page 209 Compatible Devices Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Wheelock Speaker con’t E60-24MCW Speaker/Strobe E60-24MCHW Speaker/Strobe E60-24MCC Speaker/Strobe E60-24MCCH Speaker/Strobe Speaker E70-MCW Speaker/Strobe E70-24MCWH Speaker/Strobe E70-24MCC Speaker/Strobe E70-24MCCH Speaker/Strobe E70-241575W Speaker/Strobe MB-G6-24 Motor Bell MB-G10-24 Motor Bell MB-G6-12 Motor Bell MB-G10-12...
  • Page 210: Two-Wire Smoke Detectors

    IFP-100 Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Wheelock ET80-24MCW Speaker/Strobe (con’t) ET80-24MCWH Speaker/Strobe ET80-241575W Speaker/Strobe ET90 Speaker ET90-24MCW Speaker/Strobe ET90-24MCCH Speaker/Strobe ET90-24MCC Speaker/Strobe ET90-24MCWH Speaker/Strobe ET70WP-2475W Speaker/Strobe / weatherproof ET70WP-2475C Speaker/Strobe / weatherproof ET70WP-24115C Speaker/Strobe / weatherproof ET70WP-24135C Speaker/Strobe / weatherproof...
  • Page 211 Compatible Devices reset time of the smoke detector. Table A-2: Compatible Two-Wire Smoke Detectors Model Name or Number Compatibility ID Manufacturer (Base model name or number in # per Loop Head Base parentheses.) 55000-350 (45681-200) 55000-350 45681-200 24 / loop Apollo 55000-250 (45681-200) 55000-250...
  • Page 212 IFP-100 Installation Manual Table A-2: Compatible Two-Wire Smoke Detectors Model Name or Number Compatibility ID Manufacturer (Base model name or number in # per Loop Head Base parentheses.) 1400 20 / loop 1451 (B401B) 20 / loop 2100 20 / loop 2100T 20 / loop 2151 (B401)
  • Page 213: Appendix B Special Characters Lists

    Appendix B Special Characters Lists This section contains tables of programmable characters that may be used for device, module, and zone names or phone numbers. Characters used for Naming Table B-1 list the available character and their associated numeric designator. When programming these numbers can be entered as a short cut to using the up or down arrow keys, to select characters when naming a point or zone.
  • Page 214 IFP-100 Installation Manual 151280...
  • Page 215: Silent Knight Fire Product Warranty And Return Policy

    Silent Knight Fire Product Warranty and Return Policy General Terms and Conditions • All new fire products manufactured by Silent Knight have a limited warranty period of 18 months from the date of manufacture against defects in materials and workmanship. See limited warranty statement for details.
  • Page 216 No credit will be issued if the returned board was damaged due to misuse or abuse. • Repairs and returns should be sent to: Silent Knight / Honeywell Attn: Repair Department 7550 Meridian Circle N., Suite 100 Maple Grove, MN 55369-4927...
  • Page 217: Limited Warranty

    Limited Warranty SILENT KNIGHT warrants products manufactured by it to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date stamped at time of manufacture. The sole and exclusive obligation of SILENT KNIGHT is to repair or replace, at its option, free of charge for parts and labor, any part that is defective in materials or workmanship under normal use and service.
  • Page 219 Model IFP-100 Basic Operating Instructions These Instructions must be framed and displayed next to the IFP-100 panel in accordance with NFPA 72 fire code for Local Protected Fire Alarm Systems. Test the system in accordance to NFPA 72. Operation Task to Perform Silence Alarms and Troubles Press then enter a code if prompted.
  • Page 222 7550 Meridian Circle, Ste 100 Maple Grove, MN 55369-4927 763-493-6455 or 800-328-0103 Fax: 763-493-6475 www.silentknight.com © 2007 Honeywell International Inc.

Table of Contents

Save PDF
