Parameter setting at PLC
System parameter setting
Double click the "EX600-SPR1/2" symbol on the PROFIBUS: DP master system line. The system
properties window will be displayed.
Select the [Parameter Assignment] tab; the available parameter setting list will be displayed under
[Device-Specific parameters] folder.
Change the parameter value by clicking on the Value column of the selected parameter.
Press the OK button; after the configuration data is downloaded to the PLC, the setting will be completed.
The system parameters given below can be set at the STEP7™.
System parameters
Hold/Clear
Diag.mode
Setting value
Switch
Parameter
No diag.
Device diag
Device + Module diag.
Device + Module + Channel Diag
Double click here
- 62 -
No.EX##-OML0005
