Specifications

Model
Fieldbus
Device type
Communication speed
Configuration file
I/O occupation area
(Inputs/Outputs)
Terminal resistance
Internal current consumption
(Power supply for control and
input)
Output method
Output channel
Connected load
Supply voltage
Output for com. error
Protective function
Enclosure
Operating temp. range
Operating humidity range
Withstand voltage
Insulation resistance
Vibration resistance
Impact resistance
Standard
Weight
PROFIBUS DP function.
Model number
Address setting range
FREEZE function
SYNC function
FAIL SAFE function
ID number
EX600-SPR1
(512 points/512 points) max.
Internally implemented (For type A cable)
PNP (-COM.)
32 channels (8/16/24/32 channels selectable)
Solenoid valve with indicator lamp and surge voltage protection circuit.
35 – 85 %RH (no dew condensation)
500 VAC for 1 minute between external terminals and FE
500 VDC, 10 MΩ min. between external terminals and FE
10 – 57 Hz with constant amplitude of 0.75 mm p-p
57 – 150 Hz with constant acceleration of 49 m/s
for 2 hours in each direction of X, Y and Z direction (during de-energizing)
2
147 m/s 3 times in each direction of X, Y and Z (during de-energizing)
CE marking, UL recognition (CSA)
EX600-SPR1
- 21 -
PROFIBUS DP
(DP-V0)
DP slave
9.6/19.2/45.45/93.75/
187.5/500 kbps
1.5/3/6/12 Mbps
GSD (SMCA1411.gsd)
Less than 80 mA
24 VDC 1.5 W (SMC)
24 VDC +10/-5 %
HOLD/CLEAR/ Force ON
Short-circuit protective
IP67 (manifold assembly)
o
-10 – 50 C
300 g
1 – 125
Supported
Supported
Supported
1411 (Hex)
EX600-SPR2
NPN (+COM.)
2
EX600-SPR2
