Handling care.
Please note the following points when using the open circuit detection function.
Open circuit detection setting can only be carried out by using a hand-held terminal. Setting cannot be
carried out using a PLC.
This function detects an open circuit only when the output is OFF. Therefore if the output is turned ON, an
open circuit cannot be detected.
Error display
Status LED displays the power supply and operation status. These can be checked according to the following:
LED
Specifications
Model
Output style
Output connector
Output channel
Rated load voltage
Max. load current
Protection
Current consumption
Display
Enclosure
Operating temp. range
Operating humidity range
Withstand voltage
Insulation resistance
Vibration resistance
Impact resistance
Standard
Weight
Note 1) M12 (4 pin) connector can be connected.
Status Descriptions
Power supply for control and input is OFF, or output device is
OFF
OFF.
Output device is ON.
Green light ON
Output is short circuited.
Red light ON
Either of the following:
Flashing red
All LEDs flashing Component failure inside the digital output unit.
Stop using the product and contact SMC.
red/green alternately
EX600-DYPB
24 VDC (Supplied from power supply for output)
Green LED on (when output ON), Red LED on (short circuit at load)
Red LED flashing (ON/OFF counter is exceeded, or open circuit detected)
500 VAC for 1 minute between external terminals and FE
500 VDC, Min. 10 MΩ between external terminals and FE
10 ~ 57 Hz with constant amplitude of 0.75 mm p-p
57 ~ 150 Hz with constant acceleration of 49 m/s
for 2 hours in each direction of X, Y and Z direction (during de-energizing)
2
147 m/s 3 times in each direction of X, Y and Z (during de-energizing)
Output device contact operations count has exceeded the
set value.
Output device is not connected.
PNP
M12 (5 pin), Socket
8 channels (2 channels/connector)
0.5 A/1 channel, 2 A/unit
Short circuit protection
Max. 50 mA
IP67 (manifold assembly)
-10 ~ 50
35 ~ 85 %RH (no dew condensation)
CE marking, UL recognition (CSA)
300 g
- 31 -
EX600-DYNB
NPN
Note1
o
C
2
