Hardware Configuration; Unit Identification - SMC Networks EX600-SPR Series Operation Manual

User set value range
Analogue input measurement
range
-10 ~ +10 V
-5V ~ +5 V
-20 ~ +20 mA
0 ~ +10 V
0 ~ +5 V
1 ~ 5 V
0 ~ 20 mA
4 ~ 20 mA

Hardware Configuration

This section will explain hardware configuration, implementation and parameter allocation methods for the
EX600 series.
GSD and symbol file
GSD file is required to configure the EX600 with a DP master. The GSD file contains ID number, version
and unit information. Furthermore, a symbol file is necessary for the display microcontroller of the EX600 on
the DP master software. The GSD file and symbol file can be downloaded from the URL given below.
URL : http://www.smcworld.com
GSD file : SMCA1411.gsd
Symbol file : EX600_1N.bmp (standard type)
: EX600_1D.bmp (diagnostic type)
: EX600_1S.bmp (special operating mode)

Unit identification

Each unit of the EX600 series has a unique identification number.
Unit Part Number
EX600-SPR# (32 Ch)
(#:1/2)
EX600-SPR# (24 Ch)
(#:1/2)
EX600-SPR# (16 Ch)
(#:1/2)
EX600-SPR# (8 Ch)
(#:1/2)
EX600-DX#B (#:P/N)
EX600-DX#C (#:P/N)
EX600-DX#C1 (#:P/N)
EX600-DX#D (#:P/N)
EX600-DY#B (#:P/N)
EX600-AXA
(2 channel)
Upr_Lmt
-10.5 ~ +10.45 V
-5.25 ~ +5.22 V
-21 ~ +20.9 mA
0 ~ +10.45 V
0 ~ +5.22 V
0.75 ~ 5.22 V
0 ~ 20.9 mA
3 ~ 20.9 mA
Unit Name
SI unit (32 Ch)
SI unit (24 Ch)
SI unit (16 Ch)
SI unit (8 Ch)
Digital input unit
Digital input unit
Digital input unit
(with open circuit detection)
Digital input unit
Digital output unit
Analog input unit
(2 channel)
User set value range
Occupied byte
Input Output
0 4
0 3
0 2
0 1
1 0
1 0
1 0
2 0
0 0
4
(1 channel 0
is 2 bytes)
- 58 -
Lwr_Lmt
-10.45 ~ +10.5 V
-5.22 ~ +5.25 V
-20.9 ~ +21 mA
0.05 ~ +10.5 V
0.02 ~ +5.25 V
0.77 ~ 5.25 V
0.1 ~ 21 mA
3.1 ~ 21 mA
DP ID number
Siemens IEC61158
32DO 23h
24DO 22h
16DO 21h
8DO 20h
8DI 10h
8DI 10h
8DI 10h
16DI 11h
8DO 20h
2AI 51h
No.EX##-OML0005
