Digital output data
The table shows the relation between the connector position and the output data allocation.
Table for output signal (EX600-DY*B)
Connector
position
Connector №
Output Pin 2
signal
Pin 4
Outline Dimensions
10.7
0 1 2
Bit 1 Bit 3 Bit 5
Bit 0 Bit 2 Bit 4
52.5
47
3
Bit 7
Bit 6
- 32 -
No.EX##-OML0005
