SMC Networks EX600-SPR Series Operation Manual page 51

SI unit parameters
No Parameter
Power supply
1 voltage monitor
(control/input)
Power supply
2 voltage monitor
(output )
Short circuit
3
detection
Restart after short
4
circuit
Open circuit
5
detection
Output setting
during
6
communication
fault
Output setting
during
7
communication
idle
Channel ON/OFF
8
counter
Contents
When power supply voltage for control/input goes above 26 V or falls below 21
V a diagnostic error will be generated.
When power supply voltage for output goes above 26 V or falls below 20 V a
diagnostic error will be generated.
If a short circuit or over current occurs when the valve output is ON a diagnostic
error will be generated.
The short circuit detection diagnostic can be set to automatic or manual reset.
If an open circuit is detected during valve output OFF, a diagnostic error will be
generated. This setting can be made for each channel.
When there is a communication fault, each channel's valve output can be set to
Hold, Clear or Force ON setting. This function will only be activated when the
Hold/Clear setting method at the system configuration is set to Handheld.
When communication is idle, each channel's valve output can be set to Hold,
Clear or Force ON setting. This function will only be activated when Hold/Clear
setting method at the system configuration is set to Handheld.
The number of times the valve is ON/OFF is recorded for each channel.
There is a set value for each channel and a diagnostic error is generated when
the set value is reached.
Recording the ON/OFF number is done in 30 s intervals (30 s per channel) from
CH0 to the channels, which have valve outputs.
If the power supply for control and input is turned OFF, the last recorded value
for each channel will become valid.
- 51 -
No.EX##-OML0005
