Digital input unit parameters
Parameter
No
(GSD parameter)
Short circuit
1 detection
(Monitor short circuit)
Open circuit
detection
2
(Monitor open circuit)
Note)
Inrush current filter
3
(Inrush current filter)
Input filtering time
4
(Input filtering time)
Input extension time
5 (Input extension
time)
Input sensor
6 ON/OFF counter
(Counter)
Note) The open circuit detection parameter is only available on digital input units with open circuit detection
(P/N EX600-DXPC1 & EX600-DXNC1.)
Setting
Value
Enable sensor's power supply
Enable
short circuit detection
Disable sensor's power supply
Disable
short circuit detection
Enable input sensor open circuit
Enable
detection
Disable input sensor open circuit
Disable
detection
Enable Enable inrush current filter
Disable Disable inrush current filter
0.1/1/10/20
Set input signal filtering time.
ms
1/15/100/200
Set input signal's extension time
ms
If input sensor's ON/OFF counter
Enable exceeds set value, diagnostic
error will be generated.
Diagnostic error will not be
Disable
generated
Set maximum counter value.
Val Settable values are
(1 ~ 65000) x 1000 times
Contents
Channel
Channel
- 55 -
Setting Method
Setting Default
Level setting
By PLC By HT
O
Unit O
X
O
O
Unit O
Unit 1 ms O
Unit 15 ms O
O
X
65000
No.EX##-OML0005
O
O
O
O
O
O
