Analog input unit parameters
No Parameter
Short circuit
1
detection
Analogue input
2 measurement
range
Analogue data
3
format
Analogue
4
averaging filter
Range upper
5
limit error
Range lower
6
limit error
User settable
7
value upper limit
User settable
8
value lower limit
Factory set parameters (default)
System parameters
Parameter
No.
(GSD parameter)
Diagnostic mode
Device + module
1
(Diag. mode)
Device + module
+ channel diag.
Hold/Clear
2 setting method
(Hold/Clear)
If a short circuit or over current occurs at the sensor power supply, a diagnostic
error will be generated.
Selection of analogue input range, The settable measurement ranges are:
0 ~ 10 V, 1 ~ 5 V, 0 ~ 5 V, -10 ~ +10 V, -5 ~ +5 V, 0 ~ 20 mA, 4 ~ 20 mA or
–20 ~ +20 mA.
Select data format, which is output to the PLC from the analog input unit.
Available selections are: Offset Binary, Signed Binary, 2's Complements.
Selection of analogue averaging filter. The sampling cycle is about 2 seconds.
Selectable values are: No filter, 2 average (average between the last 2 input
values), 4 average, and 8 average.
If the input signal exceeds the upper limit value of the input range (0.5 %), a
diagnostic error will be generated.
If the input signal exceeds the lower limit value of the input range (0.5 %), a
diagnostic error will be generated.
If the input signal exceeds the upper limit value of the user settable range, a
diagnostic error will be generated. This setting can be made for each channel.
If the input signal exceeds the lower limit value of the user settable range, a
diagnostic error will be generated. This setting can be made for each channel.
Setting value
No diag.
Device diag. System diagnostic data only
System and unit diagnostic data
diag.
System, unit and channel diagnostic
Hold/Clear setting is made at the SI
Switch
Hold/Clear setting is made at
Handheld
Contents
Contents
No diagnostic data
data
unit setting switch.
hand-held terminal
- 53 -
Setting method
Setting Default
level setting By PLC By HT
System O
O
O
System O
No.EX##-OML0005
O
O
