SMC Networks EX600-SPR Series Operation Manual page 30

Name and function of the parts
1
5
Mounting and installation
Pin assignments
Pin No.
EX600-DYPB
1
2 Output 2
3 0 V (for output)
4 Output 1
5
Note) Output equipment with 4 pin M12 connector can also be connected to M12 (5 pin) connector
Wiring Diagram
▪ EX600-DYPB
DigitalOutput unit
1pin
NC
Short/Open
circuit
detection
2pin
Output2
3pin
0V
Short/Open
circuit
detection
4pin
Output1
5pin
FE
Be sure to place a seal cap on any unused connectors.
Placing the seal cap appropriately enables the unit to achieve IP67 protection.
No.
2
3
1
2
3
4
5
4
Signal name
EX600-DYNB
NC 24 V (For output)
Output 2
NC
Output 1
FE FE
End
plate
Power supply
for output
24VDC
FE
Name
Indicates the unit status.
Status LED (Refer to the "Error display" section for
further details.)
Connector Connector for digital outputs.
(input) (M12, 5 pin, socket: SPEEDCON)
Marker
Groove to mount a marker.
groove
Joint bracket to join the adjacent unit,
Joint bracket
fixed with attached screws
Connector for Conveys the signals and power supplies
unit (plug) to the adjacent unit.
Configuration
1
4
▪ EX600-DYNB
DigitalOutput unit
1pin
24V
Short/Open
circuit
detection
2pin
Output2
3pin
Short/Open
NC
circuit
detection
4pin
Output1
5pin
FE
Note
- 30 -
Description
2
5
3
End
plate
Power supply
for output
24VDC
FE
No.EX##-OML0005
