Specifications
Model
Power connector
Control, input
power supply
Output power
Enclosure
Operating temp. range
Operating humidity
Withstand voltage
Insulation resistance
Vibration resistance
Impact resistance
Standard
Outline Dimensions
EX600-ED2
85.1
EX600-ED2
M12 (5 pin) plug
24 VDC ±10 %
Maximum 2 A
24 VDC +10 % / -5 %
supply Maximum 2 A
range
500 VAC for 1 minute between external terminals and FE
500 VDC, Min. 10 MΩ between external terminals and FE
10 ~ 57 Hz with constant amplitude of 0.75 mm p-p
57 ~ 150 Hz with constant acceleration of 49 m/s
for 2 hours in each direction of X, Y and Z direction (during
2
147 m/s 3 times in each direction of X, Y and Z (during de-energizing)
Weight
IP67 (manifold assembly)
-10 ~ 50
35 ~ 85 %RH (no dew condensation)
de-energizing)
CE marking, UL recognition (CSA)
170 g
20.5 5.5
- 43 -
EX600-ED3
7/8 inch (5 pin) plug
24 VDC ±10 %
Maximum 8 A
24 VDC +10 % / -5 %
Maximum 8 A
o
C
2
175 g
No.EX##-OML0005
