Address Setting

Note) If the address is set to 0 or number greater than 126, an error will result and "SF" and "BF" LEDs will
flash.
Setting 1 switch
V_SEL switch: A function to select the number of points occupied by valve outputs.
Select the output points (size) occupied by the SI unit.
Setting 1
No. 1 No. 2
OFF OFF
OFF ON
ON OFF
ON ON
Note) Please set the number of occupied valve points to more than the connected number of valves.
Baud Rate switch: Switches to set the baud rate of internal communication.
Note) 500, 250 & 125 kbps settings are for future extension. Please use 1 Mbps (factory default setting).
Setting2 Address SW
No. 8 x10
OFF
0
0
0
...
9
9
ON
0
0
...
2
ON
1 2 3 4
Setting 1 Terminator
Setting1 Terminator
ON
1 2 3
Setting 2
Setting2
Description
Occupied bit for valve output is 32
Occupied bit for valve output is 24
Occupied bit for valve output is 16
Occupied bit for valve output is 8
Setting 1
No. 3 No. 4
OFF OFF 1 Mbps (factory setting)
OFF ON
ON OFF
ON ON
Node address
x1
0 0 (factory default)
1 1
2 2
... ...
8 98
9 99
0 100
1 101
... ...
6 126
×10 ×1
0 0
Address
Address
4 5 6 7 8
SI unit output data size
4 byte (factory default)
Description
500 kbps
250 kbps
125 kbps
- 17 -
3 byte
2 byte
1 byte
