Specifications
Model
Input type
Input connector
Input channels
Sensor supplied voltage
Maximum sensor supplied
voltage
Protection
Input signal
range
Max. input signal
Input impedance
Linearity
Repeatability
Absolute accuracy
Current consumption
Display
Enclosure
Operating temp. range
Operating humidity range
Withstand voltage
Insulation resistance
Vibration resistance
Impact resistance
Standard
Weight
24 VDC (Supplied from power supply for control and input)
12 bit
resolution
16 bit -10 ~ +10 V (factory default setting)
resolution
Max. ±0.5 %F.S.
Red LED on (Short circuit at sensor power supply)
(analogue input exceeds measurement range or user setting range)
500 VAC for 1 minute between external terminals and FE
500 VDC, Min. 10 MΩ between external terminals and FE
10 ~ 57 Hz with constant amplitude of 0.75 mm p-p
for 2 hours in each direction of X, Y and Z direction (during
2
147 m/s 3 times in each direction of X, Y and Z (during de-energizing)
EX600-AXA
Voltage input
M12 (5 pin), socket
2 channel (1channel/connector)
0.5 A/channel
Short circuit protection
0 ~ 10 V
1 ~ 5 V
0 ~ 5 V
-5 ~ +5 V
±15 V
100 kΩ
Max. ±0.05 %F.S
Max. ±0.15 %F.S.
Max. 70 mA
Green LED on (when input is ON)
Red LED flashing
IP67 (manifold assembly)
-10 ~ 50
35 ~ 85 %RH (no dew condensation)
57 ~ 150 Hz with constant acceleration of 49 m/s
de-energizing)
CE marking, UL recognition (CSA)
290 g
- 35 -
Current input
0 ~ 20 mA
4 ~ 20 mA
-20 ~ +20 mA
±40 mA
50 Ω
Max. ±0.6 %F.S.
o
C
2
