• Display and description
Mounting and installation
Connection
Pin No.
Signal name
1
2
RXD/TXD-N
3
4
RXD/TXD-P
5
Shield
The branch connection is arranged in the EX600-SPR1/2 as illustrated on the circuit below.
When connecting other PROFIBUS DP products, connect using the BUS OUT connector, to increase the
number of PROFIBUS DP slave stations.
Label
ST(M)
PWR
PWR(V)
SF
BF
Wire colour
NC
NC
Description
Unit diagnostic status
Displays the control and input power supply
voltage status
Displays the output power supply voltage
status
System fault
Bus fault
-
2
Green
-
Red
3
Shield
- 15 -
Configuration
BUS IN
BUS OUT
1
1
5
5
4
4
Note
Be sure to place a seal cap
on any unused connectors.
Placing the seal cap
appropriately enables the
unit to achieve IP67
protection.
No.EX##-OML0005
2
3
