7. Image Quality Problem: Full Page
[BW/FC/FCS]
• [FCS]
[Clear/Special], [White]
• [S]
[Clear/Special], [White]
• [BW/FC/FCS: Fuser Setting HQ]
[BW/FC/FCS]
• [FCS: Fuser Setting HQ]
[Clear/Special], [White]
• [S: Fuser Setting HQ]
[Clear/Special], [White]
2. Print the image. Has the problem been resolved?
Yes
No
(c) Changing the paper direction
1. Change the vertical edge (parallel to the feed direction) of the paper to the horizontal
edge (perpendicular to the feed direction).
(d) Adjusting the image position
1. In [Advanced Settings] for the custom paper you are using, select 1101: [Image Position],
and move the image towards the leading edge based on the following.
<Toner appears on side 1>
[With Feed] of [Image Position: Side 1]
<Toner appears on side 2>
[With Feed] of [Image Position: Side 2]
2. Print the image. Has the problem been resolved?
Yes
No
• After performing the solution, it is recommended to perform the color calibration of the external
controller.
182
Finished!
Contact your service representative.
Finished!
Contact your service representative.
