  • Page 1 Shared Maintenance Offering: Adjustment Item Menu Guide Original Instructions For safe and correct use, be sure to read Safety Information separately provided before using the machine.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Paper Feed Direction of Printed Copies (Side 1/Side 2)................5 1. Adjustment Settings for Skilled Operators Accessing the Adjustment Settings for Skilled Operators Menu..............7 2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Image Position]..........................9 0101 [Perpendicularity Adjustment]......................9 0102 [Auto Adjust Image Position: Number of Printed Sheets]..............
  • Page 4 0507 [Execute ITB Manual Lubrication]....................20 0508 [Manually Smooth Fusing Belt]......................20 0509 [Fusing Belt Manual Smoothing Adjustment]..................20 0510 [Fusing Belt Auto Smoothing Setting]....................21 0511 [Fusing Belt Smoothing Adjustment]....................21 0512 [Fuser Unit Speed Adjustment]......................22 0513 [Wind Fuser Cleaning Unit at Replacement].................. 22 0514 [Temperature/Humidity Inside].......................
  • Page 5 0620 [Paper Alignment for Stapling: Weight: With Feed: 2nd Time]............ 45 0621 [Punch Skew Correction]........................46 0622 [Z-fold Skew Correction]........................46 0623 [Amount of Z-fold Skew Correction]....................47 0624 [Amount of Z-fold Skew Correction: Reverse]................47 0625 [Amount of Punch Skew Correction]....................48 0626 [Paper Alignment in Shift Tray Setting]....................48 0627 [Paper Alignment in Shift Tray Setting: Stapled Signature]............
  • Page 6 0708 [Letter Fold-in Position 1: 1 sheet Fold]................... 63 0709 [Letter Fold-in Position 1: Multi-sheet Fold]..................64 0710 [Letter Fold-in Position 2: 1 sheet Fold]................... 64 0711 [Letter Fold-in Position 2: Multi-sheet Fold]..................65 0712 [Folding Unit Tray Full Detection]....................66 [Finishing: Perfect Binder]..........................67 0801 [Cover Sheet Position for Perfect Binding: Across Feed]...............

  • Page 7: Paper Feed Direction Of Printed Copies (Side 1/Side 2)

    Paper Feed Direction of Printed Copies (Side 1/Side 2) Depending on the setting, printed copies are fed as follows: Side 1 is the surface of the paper printed during one-sided printing, or the surface of the first print during duplex printing. Side 2 is the surface of the paper printed on the back side of Side 1 during duplex printing.
  • Page 8 Single-sided printing: Printed side face up DFP408 A. Side 1 B. Paper feed direction of Side 1 Duplex printing: Printed side face up DFP409 A. Side 1 B. Paper feed direction of Side 1 C. Side 2 D. Paper feed direction of Side 2...

  • Page 9: Adjustment Settings For Skilled Operators

    1. Adjustment Settings for Skilled Operators Accessing the Adjustment Settings for Skilled Operators Menu The Adjustment Settings for Skilled Operators menu can be accessed only by the machine administrator. To have Adjustment Settings for Skilled Operators appear in [Operator Adjust.], perform the following steps to log in.
  • Page 10 1. Adjustment Settings for Skilled Operators...

  • Page 11: Details Of Menu Items In Adjustment Settings For Skilled Operators

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Image Position] 0101 [Perpendicularity Adjustment] Correct the perpendicularity of image. • Execute [Color Registration] in 0201 [Execute Image Quality Adjustment] after configuring this item. Default Max. Min. Setting Item Step Unit Value...

  • Page 12: [Machine: Image Quality]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Image Quality] 0201 [Execute Image Quality Adjustment] Execute the following adjustment manually: image density /reduce density diff. in across direction / reduce density diff. in feeding direction / reduce color dispersion. Setting Items Remarks [Adjust Image Density]...

  • Page 13: 0203 [Line Width]

    [Machine: Image Quality] Default Max. Min. Setting Items Step Unit Value Value Value [Black] None [Cyan] [Magenta] [Yellow] [Special] *1 To use special colors, 5th Station Upgrade Kit is required. 0203 [Line Width] Adjust the laser beam for image data writing. Halftone dot and fine line becomes thicker when the laser beam increases.

  • Page 14: 0204 [Density Difference: Across Feed]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0204 [Density Difference: Across Feed] Adjust the image density difference in the vertical direction. Use [+] or [-] to increase or decrease the density of lower part of image. •...

  • Page 15: [Machine: Paper Feed/Output]

    [Machine: Paper Feed/Output] [Machine: Paper Feed/Output] 0301 [Detect JAM048] Set ON/OFF for JAM048 (detect paper jam by detection error of image position correction mark). Setting Item Values Default Value [Setting] [Off] [On] [On] 0302 [Registration Gate: Paper Buckle Amount] To correct skew, adjust the paper bending allowance at registration. Use [+] or [-] to increase or decrease the bending allowance.

  • Page 16: 0304 [Nip Width Of Pressure Position 3 & 4]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators • The effectiveness of the cooling function degrades upon the fan stopping. It may cause the printed sheets not to get dry, and stick together forming a bundle. Setting Item Values Default Value [Setting]...

  • Page 17: 0306 [Paper End Setting When Near End]

    [Machine: Paper Feed/Output] 0306 [Paper End Setting When Near End] Specify whether to detect paper running out when remaining paper is low. Setting Items Values Default Value [2-Tray LCIT: Tray 3] [Off] [Off] [On] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8]...

  • Page 18: [Machine: Productivity]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Productivity] 0401 [Number of Sheets for Auto Color Selection] Set number of sheets to switch color mode. When large number is set, switching frequency will be low and productivity can be kept, but life of units and parts may be shorter. Default Max.

  • Page 19: 0404 [Pressure Roller Cooling Fan Level]

    [Machine: Productivity] Default Max. Min. Setting Items Step Unit Value Value Value [Heat Roller: On Standby] [Heat Roller: On Panel Off] [Heat Roller: Before Process] [Pressure Roller: On Standby] [Pressure Roller: On Panel Off] [Pressure Roller: On Low Power] [Pressure Roller: Before Process] [Reload Temperature: Pressure Roller] [Reload Permit: Pressure Roller]...

  • Page 20: [Machine: Maintenance]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Machine: Maintenance] 0501 [Execute Process Adjustment] Execute following multiple adjustments for printing at once: image density /color deviation / charge roller cleaning / charge bias /transfer current correction. It takes 1 to 2 minutes. Setting Item Remarks [Execute]...

  • Page 21: 0504 [Execute Cleaning Initial Setting For Pcu]

    [Machine: Maintenance] 0504 [Execute Cleaning Initial Setting for PCU] When the photoconductor cleaning unit is replaced, [Execute Cleaning Initial Setting for PCU] is automatically executed when the counter is reset, so there is no need to execute it manually. If you have cleaned the photoconductor cleaning unit, execute [Execute Cleaning Initial Setting for PCU] after attaching the photoconductor cleaning unit.

  • Page 22: 0506 [Execute Developer Refreshing]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0506 [Execute Developer Refreshing] Replace some part of developer inside the Development Unit. Setting Items Remarks [KCMY] Press [Execute]. [Black] [Special] *1 To use special colors, 5th Station Upgrade Kit is required. 0507 [Execute ITB Manual Lubrication] Apply lubricant to the Intermediate Transfer Belt.

  • Page 23: 0510 [Fusing Belt Auto Smoothing Setting]

    [Machine: Maintenance] Default Max. Min. Setting Items Step Unit Value Value Value [Smoothing Time (Belt Scratches)] 60000 [Smoothing Time (Uneven Gloss)] 0510 [Fusing Belt Auto Smoothing Setting] Set the conditions for automatic Fusing Belt smoothing. Setting Items Values Default Value [Auto Execute Belt Smoothing: For Belt Scratches] [Normal] [Normal]...

  • Page 24: 0512 [Fuser Unit Speed Adjustment]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0512 [Fuser Unit Speed Adjustment] In [Nip Setting], select the fusing nip for adjusting the rotating speed of the fuser unit. If you press [Execute], adjustment of the selected fusing nip is executed. Setting Item Remarks [Execute]...

  • Page 25: 0515 [Display System Message For When Outside Optimal Range]

    [Machine: Maintenance] Setting Items Remarks [Temperature] Value display only. [Humidity] 0515 [Display System Message for When Outside Optimal Range] Specify whether or not to display a message when using the machine in conditions outside the recommended operating environment, namely in high or low temperature or humidity. Setting Items Values Default Value...

  • Page 26: 0518 [Counter Setting For Operating Multiple Fuser Units]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Item Values Default Value [Sub Hopper/Development Unit Position] [Print Special Toner [Print Special Toner Last] Last] [Print Special Toner First] 0518 [Counter Setting for Operating Multiple Fuser Units] If set to [Coordinate (Switch Counter Value )], the counters of the cleaning unit and fusing belt smoothing roller are each reset when the fuser unit is replaced.

  • Page 27: [Finishing: Finisher]

    [Finishing: Finisher] [Finishing: Finisher] 0601 [Staple Position for Booklet] Adjust the position of the Saddle Stitch Staple. In left and right spread status, move to right with [+] and to left with [-]. This function can be used with Booklet Finisher.

  • Page 28: 0602 [Folding Position For Booklet]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 ×...
  • Page 29 [Finishing: Finisher] This function can be used with Booklet Finisher.
  • Page 30 2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 ×...

  • Page 31: 0603 [Staple Position: Across Feed 1]

    [Finishing: Finisher] 0603 [Staple Position: Across Feed 1] Adjust the position of the staple in the vertical direction at the time of Edge Stapling. Use [+] or [-] to expand or reduce the distance to the paper side end. This function can be used with Finisher or Booklet Finisher. Default Max.

  • Page 32: 0604 [Staple Position: Across Feed 2]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0604 [Staple Position: Across Feed 2] Adjust the space of the two staples in the vertical direction. Use [+] or [-] to expand or shrink the space. This function can be used with Finisher or Booklet Finisher. Default Max.

  • Page 33: 0605 [Staple Position: With Feed]

    [Finishing: Finisher] 0605 [Staple Position: With Feed] Adjust the position of the staple in the horizontal direction. Use [+] or [-] to expand or reduce the distance to the back end of paper. This function can be used with Finisher or Booklet Finisher. Default Max.

  • Page 34: 0606 [Punch Position: Across Feed]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0606 [Punch Position: Across Feed] Adjust the position (top and bottom) of the punch holes in the vertical direction. Use [+] or [-] to move punch hole up or down. This function can be used with Finisher or Booklet Finisher.

  • Page 35: 0608 [Paper Alignment For Booklet: Across Feed]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [2 Holes JP/EU] -4.0 [3 Holes US] [4 Holes EU] [4 Holes NE] [2 Holes US] 0608 [Paper Alignment for Booklet: Across Feed] Adjust the width of the staple jogger. It reduces dispersion of paper alignment in the vertical direction for each paper size.

  • Page 36: 0609 [Set Number Of Folds For Booklet]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -0.5 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 ×...

  • Page 37: 0610 [Feed Amount Of Folding Roller For Booklet]

    [Finishing: Finisher] You can adjust the paper folding strength by changing the number of folds per the booklet. When you select "0", the default value, the finisher folds the booklet according to the number of sheets in the booklet, as shown below. •...
  • Page 38 2. Details of Menu Items in Adjustment Settings for Skilled Operators This function can be used with Booklet Finisher.

  • Page 39: 0612 [Paper Alignment For Stapling: Across Feed: 1St Time]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 × 310 mm SEF] [13 × 19 SEF] [13 ×...

  • Page 40: 0613 [Paper Alignment For Stapling: Across Feed: 2Nd Time]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators It reduces dispersion of paper alignment in the vertical direction for each paper size. Use [+] or [-] to expand or reduce the width. This function can be used with Finisher or Booklet Finisher. Default Max.

  • Page 41: 0614 [Paper Alignment For Stapling: Weight: Across Feed: 1St Time]

    [Finishing: Finisher] It reduces dispersion of paper alignment in the vertical direction for each paper size. Use [+] or [-] to expand or reduce the width. This function can be used with Finisher or Booklet Finisher. Default Max. Min. Setting Items Step Unit Value...

  • Page 42: 0615 [Paper Alignment For Stapling: Weight: Across Feed: 2Nd Time]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [Paper/Ream Weight 1] -1.0 [Paper/Ream Weight 2] [Paper/Ream Weight 3] [Paper/Ream Weight 4] [Paper/Ream Weight 5] [Paper/Ream Weight 6] [Paper/Ream Weight 7] [Paper/Ream Weight 8] 0615 [Paper Alignment for Stapling: Weight: Across Feed: 2nd Time]...

  • Page 43: 0616 [Paper Alignment In Shift Tray: Across Feed]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [Paper/Ream Weight 1] -1.0 [Paper/Ream Weight 2] [Paper/Ream Weight 3] [Paper/Ream Weight 4] [Paper/Ream Weight 5] [Paper/Ream Weight 6] [Paper/Ream Weight 7] [Paper/Ream Weight 8] 0616 [Paper Alignment in Shift Tray: Across Feed] Adjust the width of the paper alignment jogger on the Shift Tray.

  • Page 44: 0617 [Paper Alignment For Stapling: With Feed: 1St Time]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 SEF] [11 ×...

  • Page 45: 0618 [Paper Alignment For Stapling: With Feed: 2Nd Time]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.5 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] × 11 SEF] [8K SEF] [16K LEF] [16K SEF]...

  • Page 46: 0619 [Paper Alignment For Stapling: Weight: With Feed: 1St Time]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.5 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] ×...

  • Page 47: 0620 [Paper Alignment For Stapling: Weight: With Feed: 2Nd Time]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [Paper/Ream Weight 1] -2.5 [Paper/Ream Weight 2] [Paper/Ream Weight 3] [Paper/Ream Weight 4] [Paper/Ream Weight 5] [Paper/Ream Weight 6] [Paper/Ream Weight 7] [Paper/Ream Weight 8] 0620 [Paper Alignment for Stapling: Weight: With Feed: 2nd Time] Adjust the amount of movement of the tip stopper when using edge stapling.

  • Page 48: 0621 [Punch Skew Correction]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [Paper/Ream Weight 1] -2.5 [Paper/Ream Weight 2] [Paper/Ream Weight 3] [Paper/Ream Weight 4] [Paper/Ream Weight 5] [Paper/Ream Weight 6] [Paper/Ream Weight 7] [Paper/Ream Weight 8] 0621 [Punch Skew Correction]...

  • Page 49: 0623 [Amount Of Z-Fold Skew Correction]

    [Finishing: Finisher] 0623 [Amount of Z-fold Skew Correction] Adjust the striking amount of paper during Z-folding skew correction. [-] reduces the striking amount. Specify this setting if the skew correction for z-folding causes a problem. At the default value of "0.0", the sheets are brought against the guide at a distance of 7 mm. You can reduce this value down to [-7.0] (0 mm) using [-].

  • Page 50: 0625 [Amount Of Punch Skew Correction]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0625 [Amount of Punch Skew Correction] Adjust the punch skew level. It reduces the punch skew due to paper size, thickness and curl. When the punch hole is skewed, set [+] to increase the correction amount.

  • Page 51: 0627 [Paper Alignment In Shift Tray Setting: Stapled Signature]

    [Finishing: Finisher] 0627 [Paper Alignment in Shift Tray Setting: Stapled Signature] Set the alignment precision of output sheets during shift sorting. Select [Accuracy Priority] to reduce the skew. This function can be used with Finisher or Booklet Finisher. Setting Item Values Default Value [Setting]...

  • Page 52: 0630 [Output Tray Descending Position]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] None [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] ×...

  • Page 53: 0631 [Output Trail Edge Press Setting]

    [Finishing: Finisher] 0631 [Output Trail Edge Press Setting] Set whether or not to hold the trailing edge of sheets when ejected on the Shift Tray. Setting it [On] reduces the dispersion of paper due to the paper type and paper condition. This function can be used with Finisher or Booklet Finisher.

  • Page 54: 0635 [Max Number Of Stacked Sheets In Output Tray: Stapled Signature]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Items Values Default Value [Paper Length 216] [Default] [Default] [Decrease by a Small Amount] [Decrease by a Large Amount] [216<Paper Length 432] [Default] [Default] [Decrease by a Small Amount] [Decrease by a Large Amount]...

  • Page 55: 0636 [Maximum Number Of Stacked Sheets In Output Tray: Envelope]

    [Finishing: Finisher] 0636 [Maximum Number of Stacked Sheets in Output Tray: Envelope] Set the number of envelopes for each envelope size to be output and stacked on the Shift Tray. This function can be used with Finisher or Booklet Finisher. Setting Item Values Default Value...

  • Page 56: 0639 [Accuracy Priority For Booklet]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0639 [Accuracy Priority for Booklet] Set the accuracy priority for a booklet. This function can be used with Booklet Finisher. Setting Item Values Default Value [Setting] [Speed Priority] [Speed Priority] [Accuracy Priority] 0640 [Convert Number of Sheets for Booklet] Set the convert number of sheets for a booklet.

  • Page 57: 0642 [Paper Alignment Angle On Shift Tray]

    [Finishing: Finisher] Adjust it when sheets are not aligned due to type, condition or number of sheets. This function can be used with Finisher or Booklet Finisher. Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF]...

  • Page 58: 0643 [Prevent Misdetection Of Punched Hole]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Item Step Unit Value Value Value [Setting] 0643 [Prevent Misdetection of Punched Hole] Activate the function if roller marks or a jam occurs when prepunched paper is fed. Setting it [On] solves the jam problems, but it may lower the productivity.

  • Page 59: [Finishing: Fold]

    [Finishing: Fold] [Finishing: Fold] 0701 [Z-fold Position 1] Adjust the edge of Z-folding when Z-folding is done by the Paper Folding Unit. Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [11 ×...

  • Page 60: 0703 [Half Fold Position]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [8K SEF] ×...

  • Page 61: 0704 [Letter Fold-Out Position 1: 1 Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [12 × 18 SEF] [8K SEF] [B5 JIS SEF] [13 × 19 SEF] ×...

  • Page 62: 0705 [Letter Fold-Out Position 1: Multi-Sheet Fold]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators • [B4 JIS SEF], [A4 SEF], [8 × 14 SEF], [8 × 11 SEF], [8 × 13 SEF] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF]...

  • Page 63: 0706 [Letter Fold-Out Position 2: 1 Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A4 SEF] -4.0 × 11 SEF] [Other Paper Sizes] 0706 [Letter Fold-out Position 2: 1 sheet Fold] Adjust the outer frame size when Outside 3 Folding is done by the Paper Folding Unit. It is applied when Single Folding is selected.

  • Page 64: 0707 [Letter Fold-Out Position 2: Multi-Sheet Fold]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] × 13 SEF] [Other Paper Sizes] 0707 [Letter Fold-out Position 2: Multi-sheet Fold]...

  • Page 65: 0708 [Letter Fold-In Position 1: 1 Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A4 SEF] -4.0 × 11 SEF] [Other Paper Sizes] 0708 [Letter Fold-in Position 1: 1 sheet Fold] Adjust the edge of folding when Inside 3 Folding is done by the Paper Folding Unit. It applies when Single Folding is selected.

  • Page 66: 0709 [Letter Fold-In Position 1: Multi-Sheet Fold]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators 0709 [Letter Fold-in Position 1: Multi-sheet Fold] Adjust the edge of folding when Inside 3 Folding is done by the Paper Folding Unit. It applies when Overlap Folding is selected. •...

  • Page 67: 0711 [Letter Fold-In Position 2: Multi-Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [A4 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] × 13 SEF] [Other Paper Sizes] 0711 [Letter Fold-in Position 2: Multi-sheet Fold] Adjust the fold size when Inside 3 Folding is done by the Paper Folding Unit.

  • Page 68: 0712 [Folding Unit Tray Full Detection]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A4 SEF] -4.0 × 11 SEF] [Other Paper Sizes] 0712 [Folding Unit Tray Full Detection] Set whether to detect if Folding Unit Tray is full of output sheets. If [On] is set, the machine detects when Folding Unit Tray is full, then shows a message.

  • Page 69: [Finishing: Perfect Binder]

    [Finishing: Perfect Binder] [Finishing: Perfect Binder] 0801 [Cover Sheet Position for Perfect Binding: Across Feed] Adjust the positional deviation in the vertical direction (top and bottom) of the cover sheet and middle paper bundle when using Perfect Binding. Default Max. Min.
  • Page 70 2. Details of Menu Items in Adjustment Settings for Skilled Operators • [Tail Edge] • [Fore Edge] Apply this adjustment if the three edges of the deck of paper cut by the perfect binder are not square. Enter the distance from the square part at each edge. Fore Edge Tail Edge Head Edge...

  • Page 71: 0804 [Applying Binding Glue]

    [Finishing: Perfect Binder] 0804 [Applying Binding Glue] Adjust the amount of glue for Perfect Binding. Default Max. Min. Setting Item Step Unit Value Value Value [Setting] 0.00 0.30 -0.30 0.05...

  • Page 72: [Finishing: Stacker]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators [Finishing: Stacker] 0901 [Paper Alignment in Stacker Tray: Across Feed 1] Adjust the alignment width in Main Jogger at the Stacker to reduce dispersion of sheets at right angles due to paper size, thickness, curl, etc.

  • Page 73: 0902 [Paper Alignment In Stacker Tray: Across Feed 2]

    [Finishing: Stacker] 0902 [Paper Alignment in Stacker Tray: Across Feed 2] Adjust the alignment width in Sub Jogger at the Stacker to reduce dispersion of sheets at right angles due to paper size, thickness, curl, etc. Default Max. Min. Setting Items Step Unit Value...

  • Page 74: 0904 [Paper Alignment In 2Nd Stacker Tray: Across Feed 1]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 SEF] [11 ×...

  • Page 75: 0905 [Paper Alignment In 2Nd Stacker Tray: Across Feed 2]

    [Finishing: Stacker] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] ×...

  • Page 76: 0906 [Paper Alignment In 2Nd Stacker Tray: With Feed]

    2. Details of Menu Items in Adjustment Settings for Skilled Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [11 × 17 SEF] × 14 SEF] [Other Paper Sizes] *1 If the stacker is attached, this guide is located in the stacker and aligns the printed sheets. 0906 [Paper Alignment in 2nd Stacker Tray: With Feed] Adjust the alignment position of the Tip Stopper of the Second Stacker.

  • Page 77: 0907 [Maximum Stack Quantity In Stacker Tray]

    [Finishing: Stacker] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] ×...
  • Page 78 2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Items Selections Default Value [Small Size] [100%] [50%] [75%] [50%] [25%]...

  • Page 79: [Finishing: Interposer]

    [Finishing: Interposer] [Finishing: Interposer] 2101 [Detect JAM573] Set ON / OFF for JAM573 (detection of multi feed). Specify whether or not to detect special paper (two-ply paper, such as label paper) as a paper jam. If set to [Off], you can prevent such erroneous detection. Setting Items Values Default Value...
  • Page 80 2. Details of Menu Items in Adjustment Settings for Skilled Operators Setting Items Values Default Value [Interposer Upper Tray] [Auto] [Auto] [Interposer Lower Tray] [On] [Off]...
  • Page 81 MEMO...
  • Page 82 MEMO M0EB-Z075...
  • Page 83 © 2023...
  • Page 84 M0EB-Z075...
