Ricoh Pro C7200 Operating Instructions Manual page 170

7. Image Quality Problem: Full Page
No
7. Decrease the line speed. This will decrease the throughput, but is it OK?
Yes
No
(a) Decreasing the printing speed
1. In [Advanced Settings] for the custom paper you are using, select 1231: [Print Speed],
and then set the value in the following corresponding settings to [Low].
• [BW/FC/FCS]
[BW/FC/FCS]
• [FCS]
[Clear/Special], [White]
• [S]
[Clear/Special], [White]
• [BW/FC/FCS: Fuser Setting HQ]
[BW/FC/FCS]
• [FCS: Fuser Setting HQ]
[Clear/Special], [White]
• [S: Fuser Setting HQ]
[Clear/Special], [White]
2. Select 1232: [Fusing Temperature], and then decrease the value in the following
corresponding settings by 20°C.
• [BW/FC/FCS]
[Heat Roller Temp]
• [FCS]
[Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White]
• [S]
[Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White]
• [BW/FC/FCS: Fuser Setting HQ]
[Heat Roller Temp]
• [FCS: Fuser Setting HQ]
[Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White]
• [S: Fuser Setting HQ]
168
Go to the next step.
Proceed to "(a) Decreasing the printing speed".
Proceed to "(b) Decreasing the fusing temperature".
