Ricoh Pro C7200 Operating Instructions Manual page 117

6. Did the image quality deteriorate?
Yes Reset the values in the following settings, and then proceed to Step 8.
• 1218: [Paper Transfer Output: Textured Paper Mode]
• 1231: [Print Speed]
No Go to the next step.
7. Has the problem of fainter prints been resolved?
Yes Finished!
No Go to the next step.
8. In the [Machine: Maintenance] group on the [Adjustment Settings for Operators] menu,
select 0506: [Execute Developer Refreshing], and then execute [Black].
9. Print the image. Has the problem been resolved?
Yes Finished!
No Contact your service representative.
• After performing the solution, it is recommended to perform the color calibration of the external
controller.
Voids: Condensation
Waves, irregular lines, or voids occur.
Waves, irregular lines
DXT853
Unprinted
115
