4. Print the image. Has the problem been resolved?
Yes Finished!
No Proceed to "(d) Print black using 4 colors".
(d) Print black using 4 colors
1. Launch Fiery Command WorkStation 6.
2. Click [Job Properties] corresponding to the image to be printed.
3. Click the [Color] tab.
4. Click [Color settings].
5. Select [Normal] in "Black Text and Graphics".
6. Print the image. Has the problem been resolved?
Yes Finished!
No Contact your service representative.
• After performing the solution, it is recommended to perform the color calibration of the external
controller.
Low Image Density: Color Patches
When printing in full color, horizontal, uneven lines may appear in small, solid fill images.
Cause:
This may occur if:
• Printing is done at high temperature or humidity
DXT848
Uneven Density
127
