Ricoh Pro C7200 Operating Instructions Manual page 179

5 mm (0.2 in.)
Cause:
This may occur when lines on coated or other slippery paper is printed.
• To adjust the following settings, pre-register the type of paper in use as a custom paper. For details
about registering custom papers, see "Specifying a Custom Paper", Preparation.
Solution:
Proceed to "(a) Increasing the image transfer output" or "(e) Adjusting the paper transfer pressure".
If toner appears along the leading edge of the paper, proceed to "(d) When toner appears on the edge
of the paper".
(a) Increasing the image transfer output
1. In [Advanced Settings] for the custom paper you are using, select 1212: [Image Transfer
Output], and then check the present value in the following corresponding settings.
• [BW]
[Black]
• [FC/FCS]
[Black]
2. Is it lower than 10?
Yes Go to the next step.
1.5 - 5 mm (0.06 - 0.2 in.)
CEZ546
Dirtied Printouts
177
