Ricoh Pro C7200 Operating Instructions Manual page 125

No Repeat Steps 1 and 2. If the problem persists even if you decrease the value to
-0.5, proceed to "(b) Adjusting the paper transfer feed pressure" or "(d) Adjusting
the environment".
(d) Adjusting the environment
Perform the following solution within the permissible range:
• Lower the temperature and humidity.
• Change to non-slippery paper.
• In [Advanced Settings] for the custom paper you are using, select 1237: [Print Speed (Sheet
Interval Adj)], decrease the value in the following corresponding settings.
• [BW/FC/FCS]
[BW/FC/FCS]
• [FCS]
[Clear/Special], [White]
If the problem persists, contact your service representative
• Lowering the maximum image density may affect the hues of the image.
• Adjusting the pressure for the paper transfer may cause a rough image or jitter to occur.
• Lowering the roller value for the paper transfer may shrink the subscan-directional image. If this
occurs, select 1101: [Image Position], and then set the following values to [ ].
• [With Feed] of [Image Magnification: Side 1]
• [With Feed] of [Image Magnification: Side 2]
• Decreasing the process speed may produce either or both of the following side effects:
• Reduction in yields
• Occurrence of fusing blisters
• After performing the solution, it is recommended to perform the color calibration of the external
controller.
• Special color mode is available for Pro C7200X, Pro C7210X, Pro C7200SX, and Pro C7210SX.
Unprinted
123
