7. Image Quality Problem: Full Page
Solution:
Carry out the following sequence of procedures. Terminate the sequence as soon as the problem is
resolved.
(a) Adjusting the paper transfer nip operation mode
1. In [Advanced Settings] for the custom paper you are using, check the present value in
1222: [Paper Transfer Nip Operation Mode].
[Off]
[Mode 1],
[Mode 2],
[Mode 3],
or [Mode
4]
2. In [Advanced Settings] for the custom paper you are using, select 1223: [Paper Transfer
Nip], and then increase the value in [Adjust Gap] by "8".
3. Print the image. Has the problem been resolved?
Yes
No
4. Set the value in 1222: [Paper Transfer Nip Operation Mode] to [Off].
5. Print the image. Has the problem been resolved?
Yes
No
(b) Adjusting the paper transfer current at the trailing edge
1. Measure the length (in mm) of the area from the trailing edge of the paper where the
print is faint.
2. In [Advanced Settings] for the custom paper you are using, select 1216: [Paper Transfer
Output Correction: Paper Edge], and then adjust the values in the following settings to
"area where the print is faint + 10 mm" according to the mode in use.
• [BW]
[Trailing Edge Length]
• [FC/FCS]
[Trailing Edge Length]
110
Proceed to "(b) Adjusting the paper transfer current at the trailing edge".
Go to the next step.
Finished!
Go to the next step.
Finished!
Proceed to "(b) Adjusting the paper transfer current at the trailing edge".
