Page 1 Power Systems Temple's Zeppelin procedures for install, remove, replace...
Page 3: Table Of Contents
Contents Control panel......................1 Removing or replacing the control panel....................1 Preparing the system..........................1 Removing the control panel........................3 Replacing the control panel........................4 Preparing the system for operation....................... 5 Removing or replacing the control panel display..................6 Preparing the system..........................6 Removing the control panel display.......................8 Replacing the control panel display.......................9 Preparing the system for operation.....................
Page 4 Preparing the system to remove and replace the SAS cables............79 Removing the SAS cables........................84 Replacing the SAS cables........................101 Preparing the system for operation....................116 Removing internally-secured SAS cables and replacing with externally-secured SAS cables..... 117 Memory modules and memory risers..............185 Memory modules.............................
Page 5: Control Panel
Control panel and control panel display for the 9040- ® Find information about removing and replacing the control panel and control panel display in the IBM ® Power System E950 (9040-MR9) server. The following figure shows the control panel (A) and the control panel display (B).
Page 6 must be removed with the system operating, ensure that all such loose material is secured away from the fan area, to prevent any loose material from being pulled into the fan. Figure 2: Removing the front cover 3. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 7: Removing The Control Panel
Removing the control panel from the 9040-MR9 To remove a control panel, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface. If not, do so now. 2.
Page 8: Replacing The Control Panel
Replacing the control panel in the 9040-MR9 To replace a control panel, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface. If not, do so now. 2.
Page 9: Preparing The System For Operation
Preparing the system for operation after removing and replacing the control panel in the 9040-MR9 To prepare the system for operation after removing and replacing a control panel, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 10: Removing Or Replacing The Control Panel Display
Removing and replacing the control panel display in the 9040-MR9 Find information about removing and replacing the control panel display in the IBM Power System E950 (9040-MR9) server. Note: Removing or replacing this feature is a customer task. You can complete this task yourself, or contact a service provider to complete the task for you.
Page 11 Figure 7: Removing the front cover 3. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced. Attention: •...
Page 12: Removing The Control Panel Display
Removing the control panel display from the 9040-MR9 To remove a control panel display, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface. If not, do so now. 2.
Page 13: Replacing The Control Panel Display
Replacing the control panel display in the 9040-MR9 To replace a control panel display, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface. If not, do so now. 2.
Page 14: Preparing The System For Operation
Press the tabs (C) to snap the cover into position. Figure 10: Installing the front cover 3. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 10 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 15: Fans
Removing and replacing a fan in the 9040-MR9 Find information about removing and replacing a fan in the IBM Power System E950 (9040-MR9) server. Note: Removing or replacing this feature is a customer task. You can complete this task yourself, or contact a service provider to complete the task for you.
Page 16 Use the blue identify LED on the enclosure to locate the system. Ensure that the serial number of the system matches the serial number to be serviced. 2. Place your fingers on the indentations and pull the latches (B) located on both sides of the cover as shown in the following figure.
Page 17 5. If you can complete the procedure with the system power turned on, continue with step “7” on page 6. If you need to power off the server to complete the repair operation, complete the following steps: a) Stop the system. For instructions, see Stopping a system (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/crustopsys.htm).
Page 18 Figure 13: Removing the power cords (L003) 14 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 19 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 7. Attach the electrostatic discharge (ESD) wrist strap. Fans for the 9040-MR9 15...
Page 20: Removing A Fan
The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced. Attention: • Attach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack, or to an unpainted metal surface of your hardware to prevent the electrostatic discharge from damaging your hardware.
Page 21: Replacing A Fan
Figure 14: Removing a fan from the system Replacing a front fan in the 9040-MR9 To replace a fan in the system, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 22: Preparing The System For Operation
4. Verify that the amber fault LED on the replaced fan is not lit. 5. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 6. Position the cover (A) on the front of the system unit as shown in the following figure, so that the four pins (B) on the system match the four holes at the rear of the cover.
Page 23 Figure 16: Installing the front cover 7. If applicable, close the rack front door. Fans for the 9040-MR9 19...
Page 24 20 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 25: Power Supplies
MR9) server. Removing a power supply from the 9040-MR9 system Find information about removing and replacing a power supply in the IBM Power System E950 (9040- MR9) server. Note: Removing or replacing this feature is a customer task. You can complete this task yourself, or contact a service provider to complete the task for you.
Page 26 Figure 17: Location of the power supplies and LEDs The power supply has the following LEDs that indicate the status of the power supply: • An AC power-on LED (green) • A DC power-on LED (green) • An error and identify function LED (amber) The following table describes the states of the power supply LEDs and helps to identify whether the power supplies are working or have a failure.
Page 27 6. If you can complete the procedure with the system power turned on, continue with step “8” on page 7. If you need to power off the server to complete the repair operation, complete the following steps: a) Stop the system. For instructions, see Stopping a system (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/crustopsys.htm).
Page 28 Figure 19: Removing the power cords (L003) 24 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 29 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 8. Attach the electrostatic discharge (ESD) wrist strap. Power supplies for the 9040-MR9 25...
Page 30: Removing A Power Supply
The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced. Attention: • Attach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack, or to an unpainted metal surface of your hardware to prevent the electrostatic discharge from damaging your hardware.
Page 31: Replacing A Power Supply
Figure 20: Removing a power supply Note: The locking-tab (B) might be terracotta instead of blue. 3. To remove the power supply; complete the following steps. See the previous figure. a) To unseat the power supply from its position in the system, push the locking-tab (B) in the direction shown.
Page 32: Preparing The System For Operation
Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 4. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 5. Note the state of LEDs on the replaced power supply; see the following figure.
Page 33 • The AC power-on LED is turned on (solid). • The DC power-on LED is turned on (solid). • The amber fault LED is turned off. Figure 22: LEDs for a working power supply 6. Verify that the amber fault LED on the replaced power supply is not lit. 7.
Page 34 30 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 35: Front Usb Cable
Front USB cable for the 9040-MR9 Find information about removing and replacing a front USB cable in the IBM Power System E950 (9040- MR9) servers. Removing and replacing the front USB cable in the 9040-MR9 Find information about removing and replacing the front USB cable in the IBM Power System E950 (9040- MR9) server.
Page 36 Figure 23: Removing the power cords (L003) 32 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 37 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 5. Label and disconnect all external cables that are attached to the PCIe adapters. 6.
Page 38 7. Remove the front cover. For instructions, see Removing the front cover (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_950_front_bezel_off.htm). 8. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 39 Loosen the two screws (A) as shown in the following figure. b) Loosen the two recessed screws (B) as shown in the following figure. Use a 4 mm ball-end hex driver (130 mm long, IBM part number 02EA546) to loosen the screws. Front USB cable for the 9040-MR9 35...
Page 40 Figure 25: Loosening the disk drive backplane screws c) Grasp the disk drive backplane with two hands as indicated by the blue squares in the following figure. Pull the disk drive backplane approximately 2.5 cm (1 in) straight out from the front of the system.
Page 41 Figure 26: Partially removing the disk drive backplane d) Pull the entire system unit out of the rack at most 20.3 cm (8 in), enough to access and disconnect the SAS cables and to remove the disk drive backplane. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 42 Figure 27: Partially sliding the system from the rack e) Label and unplug the SAS cables from the rear of the disk drive backplane as shown in the following figure. Press in on the clip to release the cable. Hold the disk drive backplane while you remove the SAS cables to prevent the disk drive backplane from tipping forward and out of the system.
Page 43 Figure 28: Unplugging the SAS cables f) After the SAS cables are disconnected from the rear of the disk drive backplane, using two hands, push the disk drive backplane back into place, ensuring that the alignment pins at (A) insert into the slots at (B).
Page 44 Figure 29: Replacing the disk drive backplane g) Push the system unit (A) back into the rack until both release latches of the system unit lock into position. Ensure that any cables do not catch or bind as you push in the system. 40 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 45 Figure 30: Pushing the system back into the rack h) Using two hands, fully remove the disk drive backplane from the system. Front USB cable for the 9040-MR9 41...
Page 46: Removing The Front Usb Cable
Figure 31: Fully removing the disk drive backplane i) Place the disk drive backplane on an ESD surface. Removing the front USB cable from the 9040-MR9 To remove the front USB cable from the server, complete the steps in this procedure. 1.
Page 47: Replacing The Front Usb Cable
Figure 32: Removing the front USB port connector Replacing the front USB cable in the 9040-MR9 To replace the front USB cable in the server, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 48: Preparing The System For Operation
Figure 33: Replacing the front USB port connector Preparing the system for operation after removing or replacing the front USB cable in the 9040-MR9 To prepare the system for operation after removing or replacing the front USB cable, complete the steps in this procedure.
Page 49 a) Using two hands, grasp the disk drive backplane where indicated by the blue squares in the following figure. Partially insert the disk drive backplane straight into the front of the system. Do not yet fully insert the disk drive backplane; leave about a 2.5 cm (1 in) gap at the rear of the disk drive backplane.
Page 50 Figure 35: Partially sliding the system from the rack c) Using the connector labels near the ends of the SAS cables, attach the SAS cables to the rear of the disk drive backplane as shown in the following figure. Hold the disk drive backplane while you attach the SAS cables to prevent the disk drive backplane from tipping forwards out of the system.
Page 51 Figure 36: Attaching the SAS cables d) Again using two hands, push the disk drive backplane back into place, ensuring that the alignment pins at (A) insert into the slots at (B). Front USB cable for the 9040-MR9 47...
Page 52 Figure 37: Replacing the disk drive backplane e) Push the system unit (A) back into the rack until both release latches of the system unit lock into position. Ensure that any cables do not catch or bind as you push in the system. 48 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 53 Secure the disk drive backplane with two recessed screws at (A). Use a 4 mm ball-end hex driver (130 mm long, IBM part number 02EA546) to tighten the screws. First, set the screw threads on one side, then the other. Then, evenly tighten the screws on both sides until both sides are seated.
Page 54 Figure 39: Fastening the screws for the disk drive backplane 3. Replace all the fans in the disk drive backplane. a) Ensure that the fan handle (A) is open as shown in the following figure. b) Hold on to the fan handle and by using your hand to support the bottom of the fan, push the fan into its slot as shown in the following figure.
Page 55 7. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 8. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 9. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 10. Verify the installed part.
Page 56 52 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 57: Rear Usb Cable
Rear USB cable for the 9040-MR9 Find information about removing and replacing a rear USB cable in the IBM Power System E950 (9040- MR9) server. Removing and replacing the rear USB cable in the 9040-MR9 Find information about removing and replacing the rear USB cable in the IBM Power System E950 (9040- MR9) server.
Page 58 Figure 41: Removing the power cords (L003) 54 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 59 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 5. Attach the electrostatic discharge (ESD) wrist strap. Rear USB cable for the 9040-MR9 55...
Page 60 The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced. Attention: • Attach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack, or to an unpainted metal surface of your hardware to prevent the electrostatic discharge from damaging your hardware.
Page 61 Figure 42: Removing the service processor card and PCIe cassettes 8. Place the system into the service position. For instructions, see Placing a system into the service position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/ p9haj_950_service_position.htm). 9. Remove the service access cover. Attention: Operating the system without the cover for more than 10 minutes might damage the system components.
Page 62 Figure 43: Removing the service access cover 10. Remove the memory riser or filler that is nearest to the where the rear USB cable plugs into the system backplane. • For a memory riser, lift up and rotate open the two latches at (A) to release the memory riser from the system backplane as shown in the following figure.
Page 63: Removing The Rear Usb Cable
Figure 44: Removing a memory riser • For a memory riser filler, unclip the riser and lift it out. Removing the rear USB cable from the 9040-MR9 system To remove the rear USB cable from the system, complete the steps in this procedure. 1.
Page 64 Figure 45: Removing the rear USB cable from the system backplane 3. Place the rear USB cable into the channel along the inside of the system. 4. Slide the system back into the rack to continue removing the rear USB cable. a.
Page 65 Figure 46: Placing the system into the operating position 5. Remove the rear USB cable by completing the following steps: a) Press the latch releases (A) and disconnect the USB connector (B) from the rear of the system as shown in the following figure. b) Push the USB connector (B) into the side area of the system.
Page 66: Replacing The Rear Usb Cable
Figure 47: Removing the rear USB port connector Replacing the rear USB cable in the 9040-MR9 system To replace the rear USB cable in the system, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 67 Figure 48: Replacing the rear USB port connector 3. Slide the system out of the rack to continue replacing the rear USB cable. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 68 Figure 49: Placing the system in service position 4. Plug the rear USB cable (A) into the USB socket on the system backplane as shown in the following figure. Ensure that the rear USB cable passes through the groove in the side of the chassis. 64 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 69: Preparing The System For Operation
Figure 50: Replacing the rear USB cable into the system backplane Preparing the 9040-MR9 system for operation after removing or replacing the rear USB cable To prepare the system for operation after removing or replacing the rear USB cable, complete the steps in this procedure.
Page 70 Figure 51: Installing a memory riser 3. If you removed a memory riser filler, replace it. 4. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis.
Page 71 Figure 52: Installing the service access cover 5. Place the system into the operating position. For instructions, see Placing a rack-mounted model into the operating position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/ p9haj_950_operating_position.htm). 6. Using your labels, replace the PCIe cassettes that you removed. a) Replace the service processor card assembly (A) as shown in the following figure.
Page 72 8. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 9. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 10. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 11. Verify the installed part.
Page 73: Time-Of-Day Battery
Time-of-day battery for the 9040-MR9 Find information about removing and replacing the time-of-day battery in the IBM Power System E950 (9040-MR9) server. Removing and replacing the time-of-day battery in the 9040-MR9 Find information about removing and replacing the time-of-day battery in the IBM Power System E950 (9040-MR9) server.
Page 74: Removing The Time-Of-Day Battery
• Exchange the battery only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call.
Page 75 Figure 54: Removing the time-of-day battery cover b) Slide the hook side of the battery removal tool (A) along the negative or left side of the time-of-day battery (B). When you hear or feel a click, the tool is secured to the time-of-day battery. Time-of-day battery for the 9040-MR9 71...
Page 76 Figure 55: Connecting the battery removal tool to the time-of-day battery c) Pull the tool and the time-of-day battery (A) from the service card. 72 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 77: Replacing The Time-Of-Day Battery
Figure 56: Removing the time-of-day battery Replacing the time-of-day battery in the 9040-MR9 To replace the time-of-day battery, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 78: Preparing The System For Operation
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface. If not, do so now. 2. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm).
Page 79 • To access the ASMI by using the HMC, complete the following steps: a. Select the system on which you are working. b. Click Tasks. c. Click Operations > Launch Advanced System Management (ASM). 4. Reset the time-of-day settings by using the ASMI. To set the time-of-day, complete the following steps: a) In the navigation area of the ASMI, click System Configuration >...
Page 80 Figure 58: Removing the power cords (L003) 76 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 81 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) c) Using your labels, reconnect the power cords (A) to the system unit as shown in the following figure.
Page 82 Verify that the content pane displays the current date (month, day, and year) and time (hours, minutes, and seconds). 6. If applicable, close the rack front and rear doors. 7. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 78 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 83: Sas Cables
SAS cables in the 9040-MR9 Find information about removing and replacing the SAS cables in the IBM Power System E950 (9040- MR9) server. Removing and replacing externally-secured SAS cables in the 9040-MR9 Learn how to remove and replace the externally-secured SAS cables in the IBM Power System E950 (9040-MR9) server.
Page 84 Figure 60: Identifying the internally-secured SAS cables 2. If the system has externally-secured SAS cables as shown in the following figure, follow the steps in this procedure. The externally-secured SAS cables have a screw at (A) and a housing at (B). 80 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 85 5. Use the blue LED to identify the server. Ensure that the serial number of the system matches the serial number to be serviced. 6. Stop the system. For instructions, see Stopping a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustopsys.htm). 7. Label and disconnect the power cords from the system unit as shown in the following figure.
Page 86 Figure 62: Removing the power cords (L003) 82 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 87 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 8. Label and disconnect all non-SAS external cables that are attached to the PCIe adapters. Leave the rear SAS cables connected for now.
Page 88: Removing The Sas Cables
9. If applicable, open the rack front door. 10. Remove the front cover. For instructions, see Removing the front cover (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_950_front_bezel_off.htm). 11. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 89 Loosen the two screws (A) as shown in the following figure. b) Loosen the two recessed screws (B) as shown in the following figure. Use a 4 mm ball-end hex driver (130 mm long, IBM part number 02EA546) to loosen the screws. SAS cables in the 9040-MR9 85...
Page 90 Figure 64: Loosening the disk drive backplane screws c) Grasp the disk drive backplane with two hands as indicated by the blue squares in the following figure. Pull the disk drive backplane approximately 2.5 cm (1 in) straight out from the front of the system.
Page 91 Figure 65: Partially removing the disk drive backplane d) Pull the entire system unit out of the rack at most 20.3 cm (8 in), enough to access and disconnect the SAS cables and to remove the disk drive backplane. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 92 Figure 66: Partially sliding the system from the rack e) Label and unplug the SAS cables from the rear of the disk drive backplane as shown in the following figure. Press in on the clip to release the cable. Hold the disk drive backplane while you remove the SAS cables to prevent the disk drive backplane from tipping forward and out of the system.
Page 93 Figure 67: Unplugging the SAS cables f) After the SAS cables are disconnected from the rear of the disk drive backplane, using two hands, push the disk drive backplane back into place, ensuring that the alignment pins at (A) insert into the slots at (B).
Page 94 Figure 68: Replacing the disk drive backplane g) Push the system unit (A) back into the rack until both release latches of the system unit lock into position. Ensure that any cables do not catch or bind as you push in the system. 90 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 95 Figure 69: Pushing the system back into the rack h) Using two hands, fully remove the disk drive backplane from the system. SAS cables in the 9040-MR9 91...
Page 96 Figure 70: Fully removing the disk drive backplane i) Place the disk drive backplane on an ESD surface. 4. Move the system unit out of the rack at most 79 cm (31 in), enough to remove the top cover. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 97 Figure 71: Partially sliding the system from the rack 5. Remove the service access cover by completing the following. Attention: Operating the system without the cover for more than 10 minutes might damage the system components. For proper cooling and airflow, replace the cover before turning on the system.
Page 98 Figure 72: Removing the service access cover 6. Remove the SAS cable support (A) by lifting it straight up as shown in the following figure. 94 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 99 Figure 73: Removing the SAS cable support 7. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis. b) Slide the cover (A) onto the system unit.
Page 100 Figure 74: Installing the service access cover 8. Loop and push the SAS cables (A) from the front of the system, into the side channel inside the system. This enables the cables to be pulled through the system to the rear. Do not fold the cables back onto themselves;...
Page 101 Figure 75: Looping and pushing the SAS cables inside the system 9. Complete the following steps to place the system in the operating position. a. If needed, unlock the blue rail safety latches (A) by pushing them towards the front as shown in the following figure.
Page 102 Figure 76: Placing the system into the operating position 10. Note the positions and label the rear SAS cables. See the following figures. Complete the following steps to remove the SAS cables. a) Slightly push in the SAS cable. b) While pushing the SAS cable, gently pull the blue tab (A) straight back from the system to release the latches that secure the SAS cable to the PCIe adapter.
Page 103 Figure 77: Disconnecting the SAS cables for the base configuration SAS cables in the 9040-MR9 99...
Page 104 Figure 78: Disconnecting the SAS cables for the split configuration 11. Loosen the screw (A) that secures the SAS cable holder (B) to the rear of the system. Remove the SAS cable holder and SAS cables from the rear of the system. 100 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 105: Replacing The Sas Cables
Figure 79: Removing the SAS cable holder and SAS cables Replacing the SAS cables in the 9040-MR9 To replace the SAS cables in the server, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 106 Figure 80: Inserting the SAS cables and SAS cable holder 3. Using the labels on the cables, based on your configuration, remove the protective SAS cable covers, and insert the SAS cables into the PCIe cards as shown in the following figure. 102 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 107 Figure 81: Plugging the SAS cables for the base configuration SAS cables in the 9040-MR9 103...
Page 108 Figure 82: Plugging the SAS cables for the split configuration 4. Move the system unit out of the rack at most 79 cm (31 in), enough to remove the top cover. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 109 Figure 83: Partially sliding the system from the rack 5. Remove the service access cover by completing the following. Attention: Operating the system without the cover for more than 10 minutes might damage the system components. For proper cooling and airflow, replace the cover before turning on the system.
Page 110 Figure 84: Removing the service access cover 6. Place the SAS cables (A) against the foam of the SAS cable support (B) as shown in the following figure. With your fingers holding the SAS cables against the foam, lower the SAS cable support (B) and SAS cables straight down between the alignment pins (C).
Page 111 Figure 85: Replacing the SAS cable holder 7. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis. b) Slide the cover (A) onto the system unit.
Page 112 Figure 86: Installing the service access cover 8. Route the SAS cables around to the front of the system. 108 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 113 Figure 87: Routing the SAS cables 9. To replace the disk drive backplane, complete the following steps: Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack. Do not pull out more than one drawer at a time. The rack might become unstable if you pull out more than one drawer at a time.
Page 114 Figure 88: Partially replacing the disk drive backplane b) Move the system unit (A) to be at most 20.3 cm (8 in) from the rack as shown in the following figure. Ensure that any cables do not catch or bind as you move the system. 110 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 115 Figure 89: Partially sliding the system into the rack c) Using the connector labels near the ends of the SAS cables, attach the SAS cables to the rear of the disk drive backplane as shown in the following figure. Hold the disk drive backplane while you attach the SAS cables to prevent the disk drive backplane from tipping forwards out of the system.
Page 116 Figure 90: Attaching the SAS cables d) Again using two hands, push the disk drive backplane back into place, ensuring that the alignment pins at (A) insert into the slots at (B). 112 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 117 Figure 91: Replacing the disk drive backplane e) Push the system unit (A) back into the rack until both release latches of the system unit lock into position. Ensure that any cables do not catch or bind as you push in the system. SAS cables in the 9040-MR9 113...
Page 118 Secure the disk drive backplane with two recessed screws at (A). Use a 4 mm ball-end hex driver (130 mm long, IBM part number 02EA546) to tighten the screws. First, set the screw threads on one side, then the other. Then, evenly tighten the screws on both sides until both sides are seated.
Page 119 Figure 93: Fastening the screws for the disk drive backplane 10. Replace all the fans in the disk drive backplane. a) Ensure that the fan handle (A) is open as shown in the following figure. b) Hold on to the fan handle and by using your hand to support the bottom of the fan, push the fan into its slot as shown in the following figure.
Page 120: Preparing The System For Operation
3. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 4. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 5. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 6. If applicable, close the rack front door.
Page 121: Removing Internally-Secured Sas Cables And Replacing With Externally-Secured Sas Cables
• If you replaced the part because of a service action, verify the installed part. For instructions, see https://www.ibm.com/support/knowledgecenter/POWER9/p9ect/ pxect_verifyrepair.htm (www.ibm.com/support/knowledgecenter/POWER9/p9ect/ pxect_verifyrepair.htm). • If you installed the part for any other reason, verify the installed part. For instructions, see https:// www.ibm.com/support/knowledgecenter/POWER9/p9haj/pxhaj_hsmverify.htm (www.ibm.com/...
Page 122 Figure 95: Identifying the externally-secured SAS cables 2. If the system has internally-secured SAS cables as shown in the following figure, complete the steps in this procedure; continue with the next step. The internally-secured SAS cables do not have a screw at (A). The area at (B) is an open slot containing the SAS cables.
Page 123 Figure 96: Identifying the internally-secured SAS cables 3. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced. Attention: •...
Page 124 b) While pushing the SAS cable, gently pull the blue tab (A) straight back from the system to release the latches that secure the SAS cable to the PCIe adapter. Do not pull the blue tab to the side, you might break the tab and prevent the cable from being removed.
Page 125 Figure 98: Disconnecting the SAS cables for the split configuration 5. Remove all the fans from the disk drive backplane as shown in the following figure. a) Put your thumb against the latch (A) in the following figure, and put your index finger against the latch (B).
Page 126 Loosen the two recessed screws (B) as shown in the following figure. Use a 4 mm ball-end hex driver (130 mm long, IBM part number 02EA546) to loosen the screws. 122 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 127 Figure 100: Loosening the disk drive backplane screws c) Grasp the disk drive backplane with two hands as indicated by the blue squares in the following figure. Pull the disk drive backplane approximately 2.5 cm (1 in) straight out from the front of the system.
Page 128 Figure 101: Partially removing the disk drive backplane d) Pull the entire system unit out of the rack at most 20.3 cm (8 in), enough to access and disconnect the SAS cables and to remove the disk drive backplane. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 129 Figure 102: Partially sliding the system from the rack e) Label and unplug the SAS cables from the rear of the disk drive backplane as shown in the following figure. Press in on the clip to release the cable. Hold the disk drive backplane while you remove the SAS cables to prevent the disk drive backplane from tipping forward and out of the system.
Page 130 Figure 103: Unplugging the SAS cables f) After the SAS cables are disconnected from the rear of the disk drive backplane, using two hands, push the disk drive backplane back into place, ensuring that the alignment pins at (A) insert into the slots at (B).
Page 131 Figure 104: Replacing the disk drive backplane g) Push the system unit (A) back into the rack until both release latches of the system unit lock into position. Ensure that any cables do not catch or bind as you push in the system. SAS cables in the 9040-MR9 127...
Page 132 Figure 105: Pushing the system back into the rack h) Using two hands, fully remove the disk drive backplane from the system. 128 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 133 Figure 106: Fully removing the disk drive backplane i) Place the disk drive backplane on an ESD surface. 7. Move the system unit out of the rack at most 79 cm (31 in), enough to remove the top cover. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 134 Figure 107: Partially sliding the system from the rack 8. Remove the service access cover by completing the following. Attention: Operating the system without the cover for more than 10 minutes might damage the system components. For proper cooling and airflow, replace the cover before turning on the system.
Page 135 Figure 108: Removing the service access cover 9. Install the system-to-rail locking clips onto each rail. The system-to-rail locking clips keep the front end of the system from dislodging from the rails when you move the system into the service position. a) On the right side of the rail, pull the blue latch marked R (A).
Page 136 Figure 109: Pulling the blue rail latch b) Each side of each clip is stamped with an L and an R. For the right side of the rail, ensure that the side stamped R is facing outward. Figure 110: Right system-to-rail locking clip c) While holding the blue latch (A), rotate the clip (B) into the rail until it clicks into place.
Page 137 Figure 111: Installing the clip onto the rail d) Ensure that the clip (C) is flush with the rail and that the system chassis pin is seated in the clip, as shown in the following figure. e) Release the blue latch (D). SAS cables in the 9040-MR9 133...
Page 138 Figure 112: Releasing the blue latch a) Repeat these steps for the L slide rail, using the clip with the side stamped L facing outward. 10. Remove the memory voltage regulator modules from locations P1-C25, P1-C30, P1-C31, and P1- C36. Tip: As you remove parts from inside the system, take notes about the location for each part.
Page 139 Figure 113: Removing the memory voltage regulator modules 11. Remove the memory module riser cards from locations P1-C26, P1-C27, P1-C28, P1-C29, P1-C32, P1-C33, P1-C34, and P1-C35. As you remove the cards, take notes about the locations from which you are removing the memory module riser cards.
Page 140 Figure 114: Removing the memory module riser cards 12. Remove the trusted platform module (TPM) card from location P1-C21. a) Grasp the TPM card by the plastic housing. Refer to the following image. b) Pull the TPM card out of its slot on the system backplane. 136 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 141 Figure 115: Removing the TPM card 13. Remove the standby voltage regulator module from location P1-C22. a) Unlock the levers (A) to release the voltage regulator module from its connector. Refer to the following image. b) Rotate the levers in the direction shown. c) While holding the voltage regulator module by its levers, pull upward to remove the card from its slot.
Page 142 Figure 116: Removing the standby voltage regulator module 14. Remove the I/O voltage regulator module from location P1-C23. a) Unlock the levers (A) to release the voltage regulator module from its connector. Refer to the following image. b) Rotate the levers in the direction shown. c) While holding the voltage regulator module by its levers, pull upward to remove the card from its slot.
Page 143 Figure 117: Removing the I/O voltage regulator module 15. Disconnect the rear USB cable. a) Press the cable release (A) to disconnect the rear USB cable from the system backplane as shown in the following figure. SAS cables in the 9040-MR9 139...
Page 144 Figure 118: Disconnecting the rear USB cable from the system backplane b) Route the rear USB cable over the side of the system to prevent it from interfering with the removal of the system backplane. 16. Remove the vital product data (VPD) card from location P1-C24. a) Grasp the VPD card by the plastic housing.
Page 145 Figure 119: Removing the VPD card 17. Remove the processor voltage regulator modules or processor voltage regulator fillers from locations P1-C13, P1-C16, P1-C17, and P1-C20. a) Unlock the levers (A) to release the voltage regulator module or filler from its connector. Refer to the following image.
Page 146 Figure 120: Removing the processor voltage regulator modules or fillers 18. Remove the heat sink from the system processor in location P1-C18. As you face the front of the system, location P1-C18 is the third processor from the left. Note: Do not remove the system processor. It is necessary to remove the heat sink in this location so that you can unplug the cable that connects the power midplane to the system backplane in an upcoming step.
Page 147 Figure 121: Removing the heat sink 19. Remove the power midplane. a) Unplug the cable from its connector on the power midplane. SAS cables in the 9040-MR9 143...
Page 148 Figure 122: Unplugging the cable from its connector on the power midplane b) Using a 4mm Hex driver, loosen the four captive screws (A) on the power midplane bulkhead. The screws attach the power midplane to the system chassis. Refer to the following image. 144 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 149 Figure 123: Loosening the captive screws on the power midplane bulkhead c) Using a 4mm Hex driver, loosen the four thumbscrews (B) that secure the power midplane to the metal brackets inside the system. SAS cables in the 9040-MR9 145...
Page 150 Figure 124: Loosening the thumbscrews and removing the power midplane d) Lift the power midplane by its bulkhead (C) and pull it out of the system. Refer to the previous image. e) Place the power midplane on an appropriate ESD surface. 20.
Page 151 Figure 125: System backplane screw locations b) Grasp the system backplane by the front (A) or middle (B) metal bulkheads and the rear metal bulkhead (C). Lift straight up to disengage the four alignment pins from the bottom of the chassis. Figure 126: Grasping the system backplane and disengaging the pins c) Place the system backplane on an appropriate ESD surface.
Page 152 Figure 127: Removing the internally-secured SAS cable holder 22. To remove the internally-secured SAS cables from the chassis, complete the following steps. a) Guide the SAS cables into the system from the rear. Ensure that the SAS cables do not get caught in the chassis. b) Carefully pull the SAS cables that extend out of the rear of the server into the middle server area as shown in the following figure.
Page 153 Figure 128: Removing the internally-secured SAS cables 23. Replace the system backplane by completing the following steps. a) Grasp the system backplane by the front (A) and middle (B) or rear metal bulkheads (C). As you lower the backplane straight down into the chassis, take care to ensure that the pins on the bottom of the backplane align with the holes in the chassis.
Page 154 Figure 129: Lowering the system backplane into the chassis b) Using a 5.5 mm Phillips head screwdriver, tighten the four captive screws (A) that mount the backplane to the chassis. Refer to the following image for the location of the screws. Figure 130: System backplane screw locations 150 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 155 24. Replace the power midplane. a) Grasp the power midplane by its bulkhead (A) and lower it into the system chassis. Refer to the following image. Figure 131: Replacing the power midplane b) Using a 4mm Hex driver, tighten the four captive thumbscrews (B) on the power midplane bulkhead.
Page 156 Figure 132: Tightening the captive screws on the power midplane bulkhead d) Reconnect the cable to its connector on the power midplane. 152 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 157 Figure 133: Reconnecting the cable to its connector on the power midplane 25. Use this step to install a new silver-colored TIM and the heat sink. a) The thermal interface material (TIM) is typically adhered to the heat sink. • If the old TIM cannot be easily removed from the heat sink, use the supplied plastic putty knife to scrape the TIM from the heat sink.
Page 158 Figure 134: Installing the silver-colored TIM onto the system processor module e) Place the heat sink on the TIM as shown in Figure 135 on page 155. 154 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 159 Figure 135: Installing the heat sink on the silver-colored TIM 26. Secure the TIM and heat sink to the socket of the system processor module. a) Ensure that the heat sink load arms are engaged as shown by (A) in Figure 136 on page 156. b) Tighten the center load screw clockwise by using the supplied hex key as shown by (B) in Figure 136 on page 156 until a firm stop is reached.
Page 160 Figure 136: Tightening the center load screw on the heat sink 27. Replace the processor voltage regulator modules or processor voltage regulator module fillers in locations P1-C13, P1-C16, P1-C17, and P1-C20. a) With the levers (A) in the open position, hold the voltage regulator module or filler by its levers and lower the voltage regulator module or filler into its slot in the system.
Page 161 Figure 137: Replacing the processor voltage regulator modules or fillers 28. Replace the vital product data (VPD) card in location P1-C24. a) Align the VPD card in its slot on the system backplane. Refer to the following image. b) Press the VPD card firmly into place until it is fully seated. SAS cables in the 9040-MR9 157...
Page 162 Figure 138: Replacing the VPD card 29. Reconnect the rear USB cable (A) in the USB socket on the system backplane as shown in the following figure. 158 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 163 Figure 139: Reconnecting the rear USB cable in the USB socket on the system backplane 30. Replace the I/O voltage regulator module in location P1-C23. a) With the levers (A) in the open position, hold the voltage regulator module by its levers and lower the voltage regulator module into its slot in the system.
Page 164 Figure 140: Replacing the I/O voltage regulator module 31. Replace the standby voltage regulator module in location P1-C22. a) With the levers (A) in the open position, hold the voltage regulator module by its levers and lower the voltage regulator module into its slot in the system. Refer to the following image. b) Gently push the voltage regulator module into its connector.
Page 165 Figure 141: Replacing a standby voltage regulator module 32. Replace the trusted platform module (TPM) card in location P1-C21. a) Insert the TPM card into its slot on the system backplane. Refer to the following image. b) Push the TPM card into place until it is fully seated. SAS cables in the 9040-MR9 161...
Page 166 Figure 142: Replacing the TPM card 33. Replace the memory module riser cards in locations P1-C26, P1-C27, P1-C28, P1-C29, P1-C32, P1- C33, P1-C34, and P1-C35. a) Ensure the release latches (A) are fully open to a 90 degree angle as shown in the following figure. b) Align the memory module riser card with the connector.
Page 167 Figure 143: Replacing the memory module riser cards 34. Replace the memory voltage regulator modules in locations P1-C25, P1-C30, P1-C31, and P1-C36. a) With the levers (A) in the open position, hold the voltage regulator module by its levers and lower the voltage regulator module into its slot in the system.
Page 168 Figure 144: Replacing the memory voltage regulator modules 35. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis. b) Slide the cover (A) onto the system unit.
Page 169 Figure 145: Installing the service access cover 36. Remove the system-to-rail locking clips. a) On the right rail, pull the blue latch marked R. b) While holding the blue latch, rotate the clip off the rail. c) Release the blue latch. d) Repeat steps “36.a”...
Page 170 Figure 146: Placing the system into the operating position 38. Install the new replacement externally-secured SAS cable. Carefully insert the SAS cables into the rear of the system as shown in the following figure. Ensure that no connectors catch or bind on internal parts.
Page 171 Figure 147: Inserting the SAS cables and SAS cable holder 39. Move the system unit out of the rack at most 79 cm (31 in), enough to remove the top cover. Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack.
Page 172 Figure 148: Partially sliding the system from the rack 40. Remove the service access cover by completing the following. Attention: Operating the system without the cover for more than 10 minutes might damage the system components. For proper cooling and airflow, replace the cover before turning on the system.
Page 173 Figure 149: Removing the service access cover 41. Place the SAS cables (A) against the foam of the SAS cable support (B) as shown in the following figure. With your fingers holding the SAS cables against the foam, lower the SAS cable support (B) and SAS cables straight down between the alignment pins (C).
Page 174 Figure 150: Replacing the SAS cable holder 42. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis. b) Slide the cover (A) onto the system unit.
Page 175 Figure 151: Installing the service access cover 43. Route the SAS cables around to the front of the system. SAS cables in the 9040-MR9 171...
Page 176 Figure 152: Routing the SAS cables 44. To replace the disk drive backplane, complete the following steps: Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack. Do not pull out more than one drawer at a time. The rack might become unstable if you pull out more than one drawer at a time.
Page 177 Figure 153: Partially replacing the disk drive backplane b) Move the system unit (A) to be at most 20.3 cm (8 in) from the rack as shown in the following figure. Ensure that any cables do not catch or bind as you move the system. SAS cables in the 9040-MR9 173...
Page 178 Figure 154: Partially sliding the system into the rack c) Using the connector labels near the ends of the SAS cables, attach the SAS cables to the rear of the disk drive backplane as shown in the following figure. Hold the disk drive backplane while you attach the SAS cables to prevent the disk drive backplane from tipping forwards out of the system.
Page 179 Figure 155: Attaching the SAS cables d) Again using two hands, push the disk drive backplane back into place, ensuring that the alignment pins at (A) insert into the slots at (B). SAS cables in the 9040-MR9 175...
Page 180 Figure 156: Replacing the disk drive backplane e) Push the system unit (A) back into the rack until both release latches of the system unit lock into position. Ensure that any cables do not catch or bind as you push in the system. 176 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 181 Secure the disk drive backplane with two recessed screws at (A). Use a 4 mm ball-end hex driver (130 mm long, IBM part number 02EA546) to tighten the screws. First, set the screw threads on one side, then the other. Then, evenly tighten the screws on both sides until both sides are seated.
Page 182 Figure 158: Fastening the screws for the disk drive backplane 45. Replace all the fans in the disk drive backplane. a) Ensure that the fan handle (A) is open as shown in the following figure. b) Hold on to the fan handle and by using your hand to support the bottom of the fan, push the fan into its slot as shown in the following figure.
Page 183 Figure 159: Replacing the fans 46. Replace the front cover. For instructions, see Installing the front cover (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_950_front_bezel_on.htm). 47. Replace the power supplies: a) Slide the power supply into the system until the latch locks in place. b) Repeat step “47.a” on page 179 to replace the remaining power supplies.
Page 184 Figure 160: Replacing the power supplies 48. Replace the PCIe adapter cassettes. a) Slide the PCIe adapter cassette forward until the cassette is fully seated. b) To lock the cassette in its slot, squeeze the latch lever (A) toward the latch (B) and rotate the latch (B) in the direction that is shown.
Page 185 Figure 161: Replacing the PCIe adapter cassettes c) Repeat steps “48.a” on page 180 through “48.b” on page 180 to replace the remaining PCIe adapter cassettes. 49. Using the labels on the cables, based on your configuration, remove the protective SAS cable covers, and insert the SAS cables into the PCIe cards as shown in the following figure.
Page 186 Figure 162: Plugging the SAS cables for the base configuration 182 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 187 51. Reconnect the power cords to the system. For instructions, see Connecting the power cords (www.ibm.com/support/knowledgecenter/POWER9/p9haj/p9haj_950_power_cord_in.htm). 52. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 53. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm).
Page 188 184 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 189: Memory Modules And Memory Risers
Memory modules and memory risers for the 9040- Find information about memory modules and memory risers in the IBM Power System E950 (9040-MR9) server. Memory modules for the 9040-MR9 Find information about installing, removing, and replacing the memory modules in the IBM Power System E950 (9040-MR9) server.
Page 190 • This system might be equipped with two or more power supplies. If the removing and replacing procedures require the system power to be turned off, ensure that all power sources to the system are disconnected. • The power cord (B) is fastened to the system with a hook-and-loop fastener (A). If you are placing the system in a service position after you disconnect the power cords, ensure that you unstrap the fastener.
Page 191 Memory modules and memory risers for the 9040-MR9 187...
Page 192 5. Label and disconnect all external cables that are attached to the PCIe adapters. 6. Place the system into the service position. For instructions, see Placing a system into the service position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/p9haj_950_service_position.htm). 7. Attach the electrostatic discharge (ESD) wrist strap.
Page 193 Figure 165: Removing the service access cover 9. Remove the memory riser. a) Open the release latches (A) on the memory riser as shown in the following figure. Open the latches to the fully upright 90 degree position. b) Pull out the memory riser from the slot by holding onto the latches. Memory modules and memory risers for the 9040-MR9 189...
Page 194 Figure 166: Removing a memory riser Installing memory modules in the 9040-MR9 system To install memory module into a memory riser, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 195 Attention: Memory modules are keyed to prevent a memory module from being installed incorrectly. Note the location of the key tab within the memory module connector before you attempt to install the memory module. 5. Ensure that the locking tabs of the memory module are open. Slowly press the memory module straight down, firmly into the slot, until the locking tabs lock into place.
Page 196 Figure 168: Inserting a memory riser 3. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis. b) Slide the cover (A) onto the system unit.
Page 197 6. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 7. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 8. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 9. Verify the installed part.
Page 198: Removing And Replacing Memory Modules In The System
Find information about removing and replacing memory modules in the system. If your system is managed by the Hardware Management Console (HMC), use the HMC to repair a part in the system. For instructions, see Repairing a part by using the HMC (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_hmc_repair.htm).
Page 199 Figure 170: Removing the power cords (L003) Memory modules and memory risers for the 9040-MR9 195...
Page 200 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 5. Label and disconnect all external cables that are attached to the PCIe adapters. 196 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 201 6. Place the system into the service position. For instructions, see Placing a system into the service position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/ p9haj_950_service_position.htm). 7. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 202 Figure 171: Removing the service access cover 9. To activate the identify LED for the faulty part, press and hold push-button (A) on the trusted platform module card as shown in the following figure. Verify that the green LED (B) is lit, which indicates that sufficient power exists for the identify LED. If the LED (B) is not lit, use the location code to find the physical location by using the service label.
Page 203 Figure 172: Activating the identify LED 10. Locate the amber LED for the memory riser for the failed memory module. Make a note of which memory riser is lit; that indicates the memory module to replace. Figure 173 on page 200 shows the locations (A) of the memory riser LEDs. Memory modules and memory risers for the 9040-MR9 199...
Page 204 Figure 173: LEDs for a memory riser If the locator function does not work, you will need to use the event log information to locate the memory riser to remove. 11. To remove the memory riser that was identified, complete the following steps: a) Open the release latches (A) on the memory riser as shown in the following figure.
Page 205 Figure 174: Removing a memory riser 12. Place the memory riser on an electrostatic discharge (ESD) mat. Removing a memory module from the 9040-MR9 system To remove a memory module from the system, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 206 Figure 175: Identifying a memory module 3. To unlock the memory module from its connector, simultaneously push both of the locking tabs away from the module in the direction that is shown in Figure 176 on page 203. The lever action of the tabs pushes the memory module out of the connector. If you find it hard to open the tabs with your fingers, you may use the tips of ball point pens, or the eraser ends of pencils.
Page 207 Figure 176: Removing a memory module 4. Hold the memory module by the edges and pull it out of the system. 5. If the removed part is used again, place the part on an electrostatic discharge (ESD) mat. Replacing a memory module in the 9040-MR9 system To replace a memory module in the system, complete the steps in this procedure.
Page 208 Figure 177: Replacing a memory module Preparing the 9040-MR9 system for operation after removing and replacing a memory module To prepare the system for operation after you remove and replace a memory module, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 209 Figure 178: Inserting a memory riser 3. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis. b) Slide the cover (A) onto the system unit.
Page 210 6. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 7. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 8. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 9. Verify the installed part.
Page 211: Plugging Rules For Memory Modules In The System
Plugging rules for memory modules in the 9040-MR9 system Find information about the configurations and rules that apply to memory modules for the IBM Power System E950 (9040-MR9) server. This information describes the rules for memory modules in the system.
Page 212 3. Stop the system. For instructions, see Stopping a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustopsys.htm). 4. Label and disconnect the power source from the system by unplugging the power cords from the system. Notes: • This system might be equipped with two or more power supplies. If the removing and replacing procedures require the system power to be turned off, ensure that all power sources to the system are disconnected.
Page 213 Memory modules and memory risers for the 9040-MR9 209...
Page 214 5. Label and disconnect all external cables that are attached to the PCIe adapters. 6. Place the system into the service position. For instructions, see Placing a system into the service position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/p9haj_950_service_position.htm). 7. Attach the electrostatic discharge (ESD) wrist strap.
Page 215 Figure 181: Removing the service access cover 9. Remove the memory riser from which you will remove memory modules. a) Open the release latches (A) on the memory riser as shown in the following figure. Open the latches to the fully upright 90 degree position. b) Pull out the memory riser from the slot by holding onto the latches.
Page 216 Figure 182: Removing a memory riser Permanently removing a memory module from the 9040-MR9 system To permanently remove memory modules from the system, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 217 Figure 183: Removing a memory module 3. Hold the memory module by the edges and pull it out of the system. 4. If the removed part is used again, place the part on an electrostatic discharge (ESD) mat. 5. Insert a memory module filler. Note: The memory module slots must contain either a memory module or a filler to ensure proper cooling.
Page 218 d) Rotate the release latches into the closed position, and press the release latches down to ensure that the memory riser is fully seated into the connector. Figure 184: Inserting a memory riser 3. Replace the service access cover. a) Lower the cover (A) onto the system unit. Ensure that the cover alignment pins (C) on each side of the cover fit into the matching slots in the chassis.
Page 219 6. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 7. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 8. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). Memory modules and memory risers for the 9040-MR9 215...
Page 220: Memory Riser
Memory riser for the 9040-MR9 Find information about installing, removing, and replacing the memory riser in the IBM Power System E950 (9040-MR9) server. Installing a memory riser in the 9040-MR9 system To install a memory riser in a system, complete the steps in this procedure.
Page 221 Figure 186: Removing the power cords (L003) Memory modules and memory risers for the 9040-MR9 217...
Page 222 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 5. Label and disconnect all external cables that are attached to the PCIe adapters. 218 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 223 6. Place the system into the service position. For instructions, see Placing a system into the service position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/p9haj_950_service_position.htm). 7. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 224 Figure 187: Removing the service access cover Installing a memory riser in the 9040-MR9 system To install memory riser cards in a system, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 225 Figure 188: Removing a memory riser filler 4. To insert the memory riser, complete the following steps: a) Ensure the release latches (A) are fully open to a 90 degree angle as shown in the following figure. b) Align the memory riser with the connector. c) Press the memory riser firmly into the connector.
Page 226 Figure 189: Inserting a memory riser 5. Repeat steps “3” on page 220 - “4” on page 221 for each memory riser. Preparing the 9040-MR9 system for operation after installing a memory riser To prepare the system for operation after you install a memory riser, complete the steps in this procedure. 1.
Page 227 5. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 6. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 7. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 8. Verify the installed part.
Page 228: Removing And Replacing Memory Riser In The System
Find information about removing and replacing a memory riser in the system. If your system is managed by the Hardware Management Console (HMC), use the HMC to repair a part in the system. For instructions, see Repairing a part by using the HMC (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_hmc_repair.htm).
Page 229 Figure 191: Removing the power cords (L003) Memory modules and memory risers for the 9040-MR9 225...
Page 230 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 4. Label and disconnect all external cables that are attached to the PCIe adapters. 226 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 231 5. Place the system into the service position. For instructions, see Placing a system into the service position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/p9haj_950_service_position.htm). 6. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 232 Figure 192: Removing the service access cover 8. To activate the identify LED for the faulty part, press and hold push-button (A) on the trusted platform module card as shown in the following figure. Verify that the green LED (B) is lit, which indicates that sufficient power exists for the identify LED. If the LED (B) is not lit, use the location code to find the physical location by using the service label.
Page 233 Figure 193: Activating the identify LED 9. Locate the amber LED for the failed memory riser. Make a note of which memory riser is lit. Figure 194 on page 230 shows the locations (A) of the memory riser LEDs. Memory modules and memory risers for the 9040-MR9 229...
Page 234 Figure 194: LEDs for a memory riser If the locator function does not work, you will need to use the event log information to locate the memory riser to remove. Removing a memory riser from the 9040-MR9 system To remove a memory riser from the system, complete the steps in this procedure. 1.
Page 235 Figure 195: Removing a memory riser 3. If the removed part is used again, place the part on an electrostatic discharge (ESD) mat. Replacing a memory riser in the 9040-MR9 system To replace a memory riser in the system, complete the steps in this procedure. 1.
Page 236 Figure 196: Inserting a memory riser Preparing the 9040-MR9 system for operation after removing and replacing a memory riser To prepare the system for operation after you remove and replace a memory riser, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 237 5. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 6. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 7. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 8. Verify the installed part.
Page 238: Permanently Removing A Memory Riser From The System
Find information about permanently removing a memory riser from the system. If your system is managed by the Hardware Management Console (HMC), use the HMC to repair a part in the system. For instructions, see Repairing a part by using the HMC (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_hmc_repair.htm).
Page 239 Figure 198: Removing the power cords (L003) Memory modules and memory risers for the 9040-MR9 235...
Page 240 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 5. Label and disconnect all external cables that are attached to the PCIe adapters. 236 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 241 6. Place the system into the service position. For instructions, see Placing a system into the service position (www.ibm.com/support/knowledgecenter/POWER9/p9haj/p9haj_950_service_position.htm). 7. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 242 Figure 199: Removing the service access cover Permanently removing a memory riser from the 9040-MR9 system To permanently remove a memory riser from the system, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 243 Figure 200: Removing a memory riser 3. If the removed part is used again, place the part on an electrostatic discharge (ESD) mat. 4. For each memory riser that you are removing, insert a memory riser filler into that slot as shown in Figure 201 on page 240.
Page 244 Figure 201: Inserting a memory riser filler 5. Repeat steps “2” on page 238 - “4” on page 239 for each memory riser that you want to remove. Preparing the 9040-MR9 system for operation after permanently removing a memory riser To prepare the system for operation after you permanently remove a memory riser, complete the steps in this procedure.
Page 245 5. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. 6. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 7. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 8. Verify the installed part.
Page 246 242 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 247: Service Processor Card Assembly
Service processor card assembly for the 9040-MR9 Find information about removing and replacing the service processor card assembly in the IBM Power System E950 (9040-MR9) system. Removing and replacing the service processor card assembly in the 9040- Find information about removing and replacing the service processor card assembly in the IBM Power System E950 (9040-MR9) server.
Page 248 • This system might be equipped with two or more power supplies. If the removing and replacing procedures require the system power to be turned off, ensure that all power sources to the system are disconnected. • The power cord (B) is fastened to the system with a hook-and-loop fastener (A). If you are placing the system in a service position after you disconnect the power cords, ensure that you unstrap the fastener.
Page 249 Service processor card assembly for the 9040-MR9 245...
Page 250: Removing The Service Processor Card Assembly
DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 7. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an unpainted metal surface until the service procedure is completed, and if applicable, until the service access cover is replaced.
Page 251: Replacing The Service Processor Card Assembly
Figure 204: Removing the service processor card assembly 3. If the removed part is used again, place the part on an electrostatic discharge (ESD) mat. The service processor card assembly is both the PCIe cassette like holder and the service processor card within that holder.
Page 252 Figure 205: Installing the service processor card assembly into slot 3. Remove the time-of-day battery cover (A) as shown in the following figure. Remove the protective plastic insulator (B) from the time-of day battery, to allow the time-of-day battery to make contact with the service processor card. 248 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 253 Figure 206: Removing the protective plastic insulator from the battery 4. Replace the time-of-day battery cover as shown in the following figure. Service processor card assembly for the 9040-MR9 249...
Page 254: Preparing The System For Operation
Figure 207: Replacing the time-of-day battery cover Preparing the 9040-MR9 system for operation after removing and replacing the service processor card assembly To prepare the system for operation after you replace the service processor card assembly, complete the steps in this procedure. 1.
Page 255 Figure 208: Connecting the power cords 3. Access the Advanced System Management Interface (ASMI). For instructions, see Accessing the ASMI without an HMC (www.ibm.com/support/knowledgecenter/ POWER9/p9hby/connect_asmi.htm). 4. A new service processor card has the following settings: • Port 1 default IP: 169.254.2.147 •...
Page 256 7. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 8. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 9. Use the ASMI to ensure that the new service processor card has the same level of firmware as the original service processor card.
Page 257: System Processor Modules
System processor modules for the 9040-MR9 You can install, remove, and replace the system processor modules in the IBM Power System E950 (9040-MR9) server. Removing and replacing the system processor module in the 9040-MR9 Find information about removing and replacing a system processor module in the IBM Power System E950 (9040-MR9) server.
Page 258 Figure 209: Removing the power cords (L003) 254 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 259 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) 4. Complete the following steps to place the system in the service position. System processor modules for the 9040-MR9 255...
Page 260 Do not pull out or install any drawer or feature if the rack stabilizer brackets are not attached to the rack. Do not pull out more than one drawer at a time. The rack might become unstable if you pull out more than one drawer at a time.
Page 261 Attention: • Attach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack, or to an unpainted metal surface of your hardware to prevent the electrostatic discharge from damaging your hardware. • When you use an ESD wrist strap, follow all electrical safety procedures. An ESD wrist strap is used for static control.
Page 262 Figure 211: Removing the service access cover 7. To activate the identify LED for the faulty part, press and hold push-button (A) on the trusted platform module card as shown in the following figure. Verify that the green LED (B) is lit, which indicates that sufficient power exists for the identify LED. If the LED (B) is not lit, use the location code to find the physical location by using the service label.
Page 263 Figure 212: Activating the identify LED 8. Locate the amber LED for the failed system processor module. Make a note of which LED is on. Figure 213 on page 260 shows the locations of the system processor module LEDs. System processor modules for the 9040-MR9 259...
Page 264: Removing The System Processor Module
Figure 213: LEDs for a system processor module If the locator function does not work, you will need to use the event log information to locate the system processor module to replace. Removing the system processor module from the 9040-MR9 system To remove a system processor module, complete the steps in this procedure.
Page 265 Figure 214: Opening the system processor module packaging 3. Remove the heat sink from the system processor module. (L007) CAUTION: A hot surface nearby. (L007) a. Loosen the heat sink actuation screw by turning the supplied hex key counterclockwise (A). Loosen the screw until it moves freely.
Page 266 Figure 215: Removing the heat sink 4. Prepare the system processor module for removal by completing the following steps. a) Ensure that the removal tool (A) is in the open position as shown in Figure 216 on page 263. The middle ring (B) must be pushed down and blue tabs (C) must be turned inward.
Page 267 Figure 216: Ensuring that the removal tool is in the open position b) Align the tool over the system processor module. Ensure that the beveled edge on the tool aligns with the beveled edge of the system processor module (C) as shown in Figure 217 on page 264. c) Lower the tool over the system processor module.
Page 268 Figure 217: Lowering the removal tool onto the system processor module d) With the removal tool sitting on top of the system processor module, push down on the ring (A) slightly so that the blue tabs (B) snap outward and the jaws engage with the system processor module as shown in Figure 218 on page 265.
Page 269 Figure 218: Locking the system processor module into the tool 5. Hold the outside of the tool and lift the tool and system processor module from the socket. Lift the tool upward slowly to ensure that the jaws are fully engaged with the system processor module.
Page 270 Figure 219: Placing the tool at an angle on the top cover of the packaging 6. Release the system processor module by pushing the ring (B) downwards. Hold the ring (B) down while pushing the blue tabs (C) inwards as shown in Figure 220 on page 267. Ensure that the ring catches the openings on the blue tabs, and that the blue tabs are locked in a fixed position.
Page 271: Replacing The System Processor Module
Figure 220: Releasing the system processor module from the tool Replacing the system processor module in the 9040-MR9 system To replace a system processor module in the system, complete the steps in this procedure. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 272 Figure 221: Ensuring that the removal tool is in the open position b) Lower the tool over the system processor module as shown in Figure 222 on page 269. Ensure that the beveled edge on the tool aligns with the beveled edge of the system processor module. Ensure that the two guide pins (A) are inserted into the alignment holes (B) on each side of the tool.
Page 273 Figure 222: Lowering the removal tool onto the system processor module c) With the removal tool sitting on top of the system processor module, push down on the ring (A) slightly so that the blue tabs (B) snap outward and the jaws engage with the system processor module (C) as shown in Figure 223 on page 270.
Page 274 Figure 223: Locking the system processor module into the tool 3. Install the system processor module: a) If dust or debris is present on the system processor socket, use the supplied air pump to clean the socket. Blow small bursts of air from the center toward the sides of the socket, as shown in Figure 224 on page 271.
Page 275 Figure 224: Removing dust and debris from the system processor socket b) Hold the sides of the tool with system processor module and carefully lift the tool out of the system processor module tray. c) Lower the tool and system processor module onto the socket. Align the beveled corner of the tool with the beveled corner on the socket.
Page 276 Figure 225: Installing the system processor module d) Open the latches that hold the system processor module in the supplied removal tool (A) as shown in Figure 226 on page 273. Push down on the ring (B) while pressing in on the tabs (C). 272 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 277 Figure 226: Removing the system processor module tool e) Lift the tool off the system processor module. 4. Use this step to install a new silver-colored TIM and the heat sink. a) The thermal interface material (TIM) is typically adhered to the heat sink. •...
Page 278 Figure 227: Installing the silver-colored TIM onto the system processor module e) Place the heat sink on the TIM as shown in Figure 228 on page 275. 274 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 279 Figure 228: Installing the heat sink on the silver-colored TIM 5. Secure the TIM and heat sink to the socket of the system processor module. a) Ensure that the heat sink load arms are engaged as shown by (A) in Figure 229 on page 276. b) Tighten the center load screw clockwise by using the supplied hex key as shown by (B) in Figure 229 on page 276 until a firm stop is reached.
Page 280 Figure 229: Tightening the center load screw on the heat sink 6. Lightly grip the system processor module that you replaced by the edges and lift it off of the packaging cover. Align the beveled corner of the module (A) to the corner of the packaging with triangle (B) and place it in the packaging, as shown in Figure 230 on page 277.
Page 281: Preparing The System For Operation After Removing And Replacing A System Processor Module
Figure 230: Placing the system processor module into the packaging Preparing the 9040-MR9 system for operation after removing and replacing a system processor module Learn how to prepare the system for operation after removing and replacing a system processor module. 1.
Page 282 Figure 231: Installing the service access cover 3. Complete the following steps to place the system in the operating position. a. Unlock the blue rail safety latches (A) by pushing them towards the front as shown in the following figure. b.
Page 283 Figure 232: Placing the system into the operating position 4. Using your labels, reconnect the power cords (A) to the system unit as shown in the following figure. Fasten the power cords to the system by using the hook-and-loop fasteners (B) as shown in the following figure.
Page 284 Figure 233: Connecting the power cords 5. Start the system. For instructions, see Starting a system (www.ibm.com/support/knowledgecenter/ POWER9/p9haj/crustartsys.htm). 6. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/ knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm). 7. Verify the installed part. • If you replaced the part because of a service action, verify the installed part. For instructions, see https://www.ibm.com/support/knowledgecenter/POWER9/p9ect/...
Page 285: Common Things
Common things Placing a 9040-MR9 system into the service position Use this procedure to place an IBM Power System E950 (9040-MR9) system into the service position. Attention: • When you place the system into the service position, it is essential that all stability plates are firmly in position to prevent the rack from toppling.
Page 286: Placing A 9040-Mr9 System Into The Operating Position
Placing a 9040-MR9 system into the operating position Use this procedure to place an IBM Power System E950 (9040-MR9) system into the operating position. Attention: When you place the system in the operating position, ensure that the cables at the rear of the system do not catch or bind as you push the system unit back into the rack.
Page 287: Removing The Service Access Cover From A 9040-Mr9 System
3. Using your labels, reconnect all of the external cables that plug into the PCIe adapters. Removing the service access cover from a 9040-MR9 system Use this procedure to remove the service access cover from an IBM Power System E950 (9040-MR9) server.
Page 288: Installing The Service Access Cover On The 9040-Mr9 System
Installing the service access cover on the 9040-MR9 system Use this procedure to install the service access cover on the IBM Power System E950 (9040-MR9) server. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 289: Disconnecting The Power Cords From The 9040-Mr9 System
Disconnecting the power cords from the 9040-MR9 system Use this procedure to disconnect the power cords from an IBM Power System E950 (9040-MR9) server. 1. If applicable, open the rack door at the rear of the system unit that you are servicing.
Page 290 Figure 238: Removing the power cords (L003) 286 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 291 DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and power cables. (L003) Common things 287...
Page 292: Connecting The Power Cords To The 9040-Mr9 System
3. Close the rack door at the rear of the system. Removing the front cover from a 9040-MR9 system Use this procedure to remove the front cover from a IBM Power System E950 (9040-MR9) server so that you can access the components or perform service.
Page 293: Installing The Front Cover On A 9040-Mr9 System
Installing the front cover on a 9040-MR9 system Use this procedure to install the cover on a IBM Power System E950 (9040-MR9) server. 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface.
Page 294 Figure 241: Installing the front cover 290 Power Systems: Temple's Zeppelin procedures for install, remove, replace...
Page 296 IBM®...

This manual is also suitable for:

Power system e950 9040-mr9

IBM Power System Series Manual

Control Panel

Fans

Power Supplies

Front USB Cable

Rear USB Cable

Time-Of-Day Battery

SAS Cables

Memory Modules and Memory Risers

Service Processor Card Assembly

System Processor Modules

Common Things

Quick Links

Need help?

Questions and answers

Related Manuals for IBM Power System Series

Summary of Contents for IBM Power System Series

This manual is also suitable for:

Table of Contents
