MAP Control Center
Figure 1.6 Main Menu – screen 2
Notice!
The buttons on your touch screen might be different from the buttons shown in Figure 1.5
Main Menu – screen 1, page 8 and Figure 1.6 Main Menu – screen 2, page 9.The buttons on
your touch screen are determined by your user authority level.
After the user presses a button, the touch screen shows the task buttons contained within
that folder. For example, Figure 2.45 Status menu, page 34 shows the Status tasks.
Table 1.1 Navigation Bar description
Button
Bosch Sicherheitssysteme, GmbH
Description
Back: Shows the previous screen.
Home: Shows the Main Menu.
Page up: Shows the previous page on screens with more than one page.
Page down: Shows the next page on screens with more than one page.
Help: Shows helpful information about the active screen.
Exit: Logs the user off and switches the display to the idle screen (Figure 1.2
Idle screen, page 6).
