MAP Control Center
Figure 2.2 View Event Memory screen
Notice!
The system displays events with the newest event being displayed first.
If your passcode authorizes the clearing of alarms and other events, press Clear Events. If you
cannot clear certain events because you do not have the necessary access rights, then the Not
Authorized screen appears on the control center. In this case, please notify your installer or
maintenance engineer. For more information about viewing event memory, refer to Section
View Event Memory, page 10.
2.1.4
Clearing An Anti-masking Message
1.
2.
3.
2.2
Searching and Sorting / Filtering
Some functions in the MAP system user interface call for or require searching, sorting, or
filtering. Where these functions are possible, the Search and Sort / Filter (Table 2.1 Search
and Sort / Filter button descriptions, page 11) buttons appear on the screen.
Table 2.1 Search and Sort / Filter button descriptions
Button
Bosch Sicherheitssysteme, GmbH
Turn on the walk test for the area in which the point is located (refer to Section Motion
Detector Test, page 55).
Remove the object masking the point and then trigger the point using motion.
Turn off the walk test again. The anti-masking message is now cleared.
Description
Search: Shows the Alphanumeric Keypad screen (Figure 2.3 1. Alphanumeric
Keypad screen 1, page 12).
Sort/Filter: Shows a list of sort categories appropriate to the function, and
the A-Z and Z-A buttons.
A-Z: Sorts in alphabetical order.
User Manual
Operation | en
11
2014.11 | 06 | F.01U.168.328
