MAP Control Center
2.3.1
Arm All Areas
From the Arm menu, press the Arm All Areas button. As above, if all areas are Ready to Arm,
the Exit Delay screen is displayed; if not, the Arming Failure screen opens with the lock button
in the locked position and the armed status showing on the Arm All Areas button.
2.3.2
Arm Selected Areas
From the Arm menu (Figure 2.5 Arm menu, page 14), press the Arm All Areas button. The Arm
Selected Areas screen (Figure 2.8 Arm Selected Areas screen, page 15) opens. The text and
the lock button show status information on the button for each area. To arm an area, press
the button for an area that is not already armed; then press the Arm button.
Figure 2.8 Arm Selected Areas screen
To sort the list of areas before selecting some to arm, press the Sort / Filter button. Refer to
Table 2.3 Arming indicators, page 15 for the possible arming indicators.
Table 2.3 Arming indicators
Indicator
Disarmed
Ready to Arm
Not Ready to Arm
Armed
2.3.3
Arm Control Panel (Local) Area
From the Arm menu (Figure 2.5 Arm menu, page 14), press the Arm Control Panel Area
button.
Notice!
Depending on how your system is configured, the displayed button name on each control
center is unique for each installation.
The Arm menu opens with the lock button in the locked position and the area's armed status
showing on the Arm Control Panel Area button.
Bosch Sicherheitssysteme, GmbH
Description
Area currently disarmed
All points in the area are ready to arm
Some points in the area are faulted and not
ready to arm; all points must either be
returned to normal or bypassed.
Area currently armed
User Manual
Operation | en
15
2014.11 | 06 | F.01U.168.328
