MAP5000
8

Appendices

This chapter contains information and instructions for creating programming that complies
with the requirements of a specific standard.
Notice!
Use the default setting for parameters that are not explicitly mentioned in this description. In
addition, the instructions for panel validation in the RPS for MAP programming software
must be followed.
8.1

Requirements in Accordance with VdS Class C

8.1.1

Selection of the Default Setting Used

–
Also refer to Standard-Compliant Programming, page 59
8.1.2

Number of Areas

Refer to Number of Areas Section 1.4.3 System Parameters, page 7
8.1.3

Power Supply for Areas

Refer to note of Make the LSN Gateway Connections, page 44
8.1.4

Control Centers and Display Panel

Refer to planning and programming instructions in Plan the System with IPP-MAP0005 Power
Supply, page 8, Connect the Control Center, page 41, Operating and Display Panel, page 53 and
Programming Instructions for ISP-EMIL 120, page 54.
8.1.5

Connection to Management System BIS

Refer to Use of the IP Interface, page 56
8.1.6

Printer Connection

Connection of the DR2020T Printer is permitted only for service purposes.
8.1.7

Access Levels

The standard distinguishes between four access levels (AE).
AE 1 Access for everyone, no authorization/code required
AE 2 Access for users, user passcode required
AE 3 Access for installers via control center
1.
2.
3.
AE 3 Access for installers via RPS for MAP
1.
2.
Bosch Sicherheitssysteme GmbH
Select VdS Class C as the default property values set
Open the control panel enclosure
Switch on Installer Mode (Section Installer Button, page 67)
Enter installer passcode
Open the control panel enclosure
or
authorization from RPS by a AE 2 user with corresponding
permissions (control center: Main menu page 2 > RPS)
Establish connection of panel to RPS
