Pinout and Color Requirements

The following tables provide cable pinout and color information.
Straight-Through Cable - 10BASE-T, 100BASE-TX, or 100BASE-T4
Pin
1
2
3
4
5
6
7
8
PCI Ethernet and Fast Ethernet Adapters User's Guide
Stock Number: 511472-00, Rev. A
Print Spec Number: 496708-00
Current Date: 5/5/97
Colors - Both Ends
Orange White
Orange
Green White
Blue
Blue White
Green
Brown White
Brown
Page: B-3
ECN Date: 5/97
Cables
B-3
