Windows For Workgroups - Adaptec PCI Ethernet and Fast Ethernet Adapters User Manual

PCI Ethernet and Fast Ethernet Adapters

Windows for Workgroups

Note:
Consult the \readme\wfw.txt file for the latest driver
information and installation instructions. Some procedures
or information may have changed or may not have been
available when this user's guide was printed.
The Windows for Workgroups *.386 file supports all Adaptec PCI
single port adapters.
You can use any of the following drivers for Windows for Work-
groups:
DOS ODI ( empci.com )
DOS NDIS 2.0 ( empci.dos )
Windows 32-bit NDIS 3.0 ( empci.386 )
The oemsetup file located in the \windows subdirectory supports
installation and configuration of any of these three drivers.
1
In the Main program group, double-click the Windows Setup
icon.
2
From the Options menu, select Change Network Settings.
3
From the Network Setup dialog box, click the Drivers button.
4
Click the Add Adapter button.
5
From the list of adapters provided, select Unlisted or Updated
Network Adapter.
6
Select the drive where your Adaptec driver diskette is located
and select the \windows subdirectory as the install path.
Click OK.
7
Select your Adaptec PCI adapter from the list of adapters
provided, then click OK. You can use the NDIS 3.0 (32-bit), the
DOS ODI, or the DOS NDIS driver.
8
After clicking OK, you can highlight your Adaptec adapter in
the list of network drivers, and then select setup, to edit the
network adapter settings.
For the non-NDIS 3.0 drivers, use this setup option to select
between DOS ODI and DOS NDIS. The Driver Type option at
4-20
PCI Ethernet and Fast Ethernet Adapters User's Guide
