ANA-6911/UC Ultimate Combo

Bus Interface
Hardware Interrupts
Base I/O Addresses
Ethernet Node ID Number
Power Requirements
Environmental
Operating Temperature
Humidity
Altitude
Network Interface
Standards
Certifications
Network Speeds Supported
Network Connectors
Physical Dimensions
Diagnostic LEDs
PCI Ethernet and Fast Ethernet Adapters User's Guide
Stock Number: 511472-00, Rev. A
Print Spec Number: 496708-00
Current Date: 5/5/97
Adapter Specifications
PCI 32-bit bus master
PCI INTA, supports shared interrupts
Assigned by BIOS
000092xxxxxx
+ 5 volts @ 3 Amp. max, or
+3.3 volts @ 5 Amp. max
0× C to 50× C
5% to 85% non-condensing
3000m maximum
Ethernet IEEE 802.3 10BASE-T
Ethernet IEEE 802.3 10BASE-2
Ethernet IEEE 802.3 10BASE-5
Ethernet IEEE 802.3u 100BASE-T4
Ethernet IEEE 802.3u 100BASE-TX
FCC Class A
CE Class A
10 Mb/s
20 Mb/s Full Duplex
100 Mb/s
200 Mb/s Full Duplex (TX only)
RJ-45 female, BNC, AUI
6" x 3.9" (conforms to PCI Short Card
specification)
Link status 10/100 (yellow/green)
normally on
Network activity (yellow) on when
activity detected
Page: A-7
ECN Date: 5/97
A-7
