PCI Ethernet and Fast Ethernet Adapters

ANA-6911A/TX and ANA-6911A/TX Combo PCI

Bus Interface
Hardware Interrupts
Base I/O or Memory
Address
Power Requirements
Environmental
Temperature
Relative Humidity
Altitude
Network Interface
Standards
Certifications
Network Speeds Supported
Network Connectors
Physical Dimensions
Diagnostic LEDs
A-6
PCI Ethernet and Fast Ethernet Adapters User's Guide
Stock Number: 511472-00, Rev. A
Print Spec Number: 496708-00
Current Date: 5/5/97
PCI 32-bit bus master
PCI interrupt A, supports shared
interrupts
Assigned by BIOS
+5 volts @ 1.5 Amp. max
0× C to 50× C
5% to 85% non-condensing
3000m maximum
IEEE 802.3 10BASE-2
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
FCC Class B
CE Class B
10 Mb/s
20 Mb/s Full Duplex
100 Mb/s
200 Mb/s Full Duplex
RJ-45 female, BNC
5.075" x 3.9" (conforms to PCI Short
Card specification)
Link status (green) normally on
Network activity (yellow) on when
activity detected
