2
Attach the battery pack (4)
: With the recycle mark side turned up, place the connector terminal of
the FOMA terminal to that of the battery pack and attach the battery
pack.
Connector terminal
With recycle mark
side up
Battery pack connector terminal
3
Place the back cover to the FOMA terminal slot with
the back cover open approximately 3 mm, push it (5)
and slide it to the direction of arrow to insert (6)
5
■ Removing battery pack
1
Follow step 1 of "Attaching battery pack" to remove
the back cover
2
Remove the battery pack
: The battery pack has a tab that makes it easy to remove. Hook a
finger on the tab to prevent excessive force on it and remove the
battery pack upward.
36
4
Battery pack
6
Tab
Using unnecessary force when attaching or removing the battery pack
may damage the connector terminal for the battery pack (charger
terminal) on the FOMA terminal.
Securely close the back cover. If not closed securely, the back cover
may come off and the battery pack may fall out due to vibration.

Charging

The battery pack is not fully charged at the time of purchase. Be
sure to charge the battery using the microUSB adapter for charge
(sample) or FOMA charging micro USB adapter T01 (sold separately)
and the exclusive AC or DC adapter (sold separately) before use.
Cautions while charging
■
Do not charge for long periods of time with the power left on. If the FOMA
terminal is left on after charging is complete, the battery pack charge
decreases.
In such cases, the AC or DC adapter charges the battery again.
However, depending on when the FOMA terminal is disconnected from
the AC or DC adapter, the battery charge level may be low, the battery
alert tone may sound, or the battery may only be usable for a short time.
When the battery is empty and terminal is recharging, charging lamp may
not illuminate immediately.
If the battery empty alert is displayed and the power cannot be turned on,
charge the battery for a while.
If charging begins within 60 seconds after the battery empty alert is
displayed, the status returns to normal.
