Using as a microSD reader/writer

You can use the FOMA terminal as a microSD reader/writer by
connecting it to a PC via the microUSB cable for PC (sample).
Insert a microSD Card in advance.
1
Connect the FOMA terminal to a PC via the microUSB
cable for PC
2
Touch the notification area/[%]/[Mount]
3
Use as a microSD reader/writer
4
Disconnect the microUSB cable for PC from the FOMA
terminal after use
While using as a microSD reader/writer, Offline mode is enabled. When
Offline mode is not disabled after using, disable it manually.
While using as a microSD reader/writer, microSD Card cannot be used
from other applications. In addition, microSD Card may not be used as
a microSD reader/writer while using it from other applications.
MTP mode

Transferring data from a PC

Connect the FOMA terminal to a PC via the microUSB cable for
PC (sample) and save music data, video data, and still picture
data to a microSD Card.
Playing copyrighted data is only possible with the FOMA terminal used
for transfer from a PC.
Some data may not be played due to copyright.
Data saved on devices other than SH-10B cannot be played even if they
are data without copyright.
When a microSD Card to which files are saved by devices other than
SH-10B is used, a PC may not recognize it even if the MTP mode is set.
In such cases, format the microSD Card with SH-10B (nP. 176). Note
that all the data are deleted when the microSD Card is formatted.
1
Activate Windows Media Player 11 on a PC
2
Connect the FOMA terminal to a PC via the microUSB
cable for PC
3
Set the USB connection mode to [MTP mode] and
activate MTP application
4
Add data to the synchronization list in Windows Media
Player 11 and start synchronization
5
Exit the MTP application after transfer
6
Disconnect the microUSB cable for PC from the FOMA
terminal
While activating MTP application, Offline mode is enabled. When
Offline mode is not disabled after exiting MTP application, disable it
manually.
File transfer
Up to 63 single/double-byte characters appear as a file name on the
FOMA terminal.
The data is overwritten if the data, whose name is the same in its first to
64th characters (including extensions), is transferred.
The license information of copyrighted data is saved in the microSD
Card. If you perform removing the microSD Card, deleting a license
information data or Reset all, the transferred data cannot be played.
251
