Using Infrared Communication - Docomo LYNX SH-10B Instruction Manual

Precautions for using infrared communication
function
15°
15°
Face the Infrared ports of the receiver's and sender's FOMA terminal
each other and set the distance between them to approximately 20 cm or
less as shown.
While doing infrared communication, leave the Infrared ports facing each
other and do not move.
Infrared communication may not function properly in areas of direct
sunlight, directly under fluorescent lights, or near other equipment using
infrared signals.
If either of the Infrared ports is dirty, infrared communication will become
difficult. Take care not to scratch the ports, and wipe off any dirt with a
soft cloth.
When the other party could not be found or authentication failed, the
confirmation screen asking whether to continue appears. To try again,
select [Yes]. Move the FOMA terminals close and try again.
IrSS™ communication performs a transmission without confirming the
response of the receiver side since it uses a simplex communication. For
this reason, the sender side completes the communication normally even
if the receiver side does not.
178
Approx. 20 cm
or less
Infrared port
Sending and receiving data
To enter lock no. and authentication code is required for sending or
receiving all data items. The authentication code is a password
exclusively for infrared communication. Before starting data
transmission, the sender and receiver must enter the same
user-specified four-digit code.
Sending data
Sending data via normal infrared communication
■
<Send by Infrared>
Example: Phonebook
1
In the main menu, [Address Book]
2
Point the cursor to the name/z/[Send by
Infrared]
: Set the receiving FOMA terminal to receive data.
3
Select a sending method
;
[Send One]/[Yes]
;
[Send Selected]/select a name/[Do]/[Yes]
;
[Send All]/[Yes]/enter the lock no./[OK]/enter the
authentication code/[OK]
• Data sending begins if the entered authentication code matches an
authentication code entered by the receiver.
Sending data via IrSS™ communication
■
Example: Still picture
1
In the main menu, [Contents Manager]
2
Point the cursor to the still picture/[MENU]/[Send
by infrared]/[Send by IrSS]/[Yes]
<Send by IrSS>
