Move Sensor
Rotates the view of the edit
area.
Restart/ Allows you to either restart
Reboot
automatic configuration or
reboot the sensor.
Edit
Lets you edit the sensor's
Thresholds sensitivity thresholds.
Play/Pause Plays/pauses tracks in the
Traffic
edit area.
Shows a description of each
menu bar button.

Lane Setup

Auto-configuring lanes

Figure 45. Automatically configuring lanes
Change this to match the
software with the approach
being detected. Purely for
your convenience—does
not affect sensor
performance.
Click Restart Auto Lane
Cfg to start the auto
configuration over again.
Click Reboot Sensor to
clear all sensor thresholds.
Use this to increase or
decrease the sensitivity of
the sensor's detection.
Use this when a vehicle is in
a certain position you' d like
to use as a reference.
N/A
Chapter 6: Configuring Lanes & Stop Bars
45
•
