SmartSensor Matrix User Guide
•
Setting Description
Ch
Channel
T Channel Type
DI
Detector Input
Φ
Phase
Delay
Delay
Exend
Exend
Min. Pulse
The minimum duration
Width
a presence detection will
be signaled via the contact
closure rack cards.
Pulsed Chan.
The duration the contact
Width
closure message lasts for a
pulse or counting channel.
Details
N/A
N/A
Double-click on the row to
change this setting.
Double-click on the row to
change this setting.
Double-click on the row to
change this setting.
Double-click on the row to
change this setting.
This may be useful if you
are using the Matrix for
counts. Contact Wavetronix
Technical Support before
changing this setting.
This may be useful if you
are using the Matrix for
counts. Contact Wavetronix
Technical Support before
changing this setting.
