Lane Setup

In this chapter
6
Setting up lanes is simple in SmartSensor Manager because the software will do it for you
with the click of a button. Additionally, if SmartSensor Manager is unable to correctly con-
figure due to barriers, obstacles or irregular lanes, you can use the Manual Configuration
mode to adjust.
Note
Free-flowing traffic in each lane is required for proper configuration. Light or sporadic
traffic may result in slower configurations.
Lane Configuration – Automatic
Follow the steps below to automatically configure lanes in SmartSensor Manager:
1
Select Edit > Lane Configuration.
2
Once the Lane Configuration page opens, click on the Automatic button.
3 If you would like to set constraints on the configuration through the Edit Range Blind-
ers or Manage Gain buttons, do so now. For more information on these options see the
sections on them in the following pages.
˽ Lane Configuration – Automatic
˽ Lane Configuration – Manual
˽ Verifying Lane Configuration
